Side 1/36

UPS Systems

Models:

BC800U, INTERNET750U, INTERNET900U

(Series Numbers: AG-0314, AG-0317, AG-0390)

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

Español 13 • Français 24

18-11-059-93388E.indb 1 12/7/2018 5:46:25 PM

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the

installation, operation and storage of this product. Failure to heed these warnings

may affect the warranty.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, conductive contaminants, dust

or direct sunlight.

• For best performance, keep the indoor temperature between 32º F and 104º F

(0º C and 40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

• Optional mounting: The UPS may be securely mounted in a horizontal or vertical position.

To mount, use two screws (not provided) to secure the UPS rear keyholes to a ﬂat surface.

UPS Connection Warnings

• Connect your UPS directly to a properly-grounded AC power outlet. Do not plug the UPS into

itself; this will damage the UPS.

• Do not modify the UPS plug and do not use an adapter that would eliminate the UPS

ground connection.

• Do not use extension cords to connect the UPS to an AC outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must provide

clean, ﬁltered, computer-grade output.

• The mains socket outlet that supplies the UPS should be easily accessible and located near

the UPS.

Equipment Connection Warnings

Install in accordance with National Electrical Code standards ANSI/NFPA

70 and Canadian Electrical Code, Part I, C22.1.

Short-circuit backup protection and overcurrent protection is provided by

the building installation.

To reduce the risk of ﬁre, connect only to a circuit with a maximum 20A

provided branch circuit overcurrent protection in accordance with the

National Electrical Code, ANSI/NFPA 70 and the Canadian Electrical Code,

Part I, C22.1. The plug on the power supply cord is intended to serve as

the disconnect device. Be sure that the socket-outlet is installed near the

equipment and is made easily accessible.

The UPS is intended for use on a TN power distribution system.

Important Safety Instructions

18-11-059-93388E.indb 2 12/7/2018 5:46:25 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	BC800U
Vekt:	3090 g
Bredde:	130 mm
Dybde:	320 mm
Høyde:	85.1 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-port:	Ja
Opprinnelsesland:	Vietnam
Pakkevekt:	3390 g
Antall USB 2.0-porter:	1
Utgangseffekt:	450 W
Utgangsspenning (maks.):	120 V
UPS topologi:	Standby (Offline)
Antall inngangsfaser:	1
Utgangsfrekvens:	50/60 Hz
Hørbare alarmmoduser:	Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Bølgeform:	Ren sinus
Inngangsspenning (maks.):	120 V
Kabellengde:	1.5 m
Produktfarge:	Sort
Pakkedybde:	379 mm
Pakkehøyde:	198.9 mm
Pakkebredde:	151.9 mm
Kabler inkludert:	USB-kabel
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 45 °C
Lagringsrelativ fuktighet:	0 - 90
Bærekraftsertifikater:	RoHS, ENERGY STAR
Formfaktor:	Tower
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Overspenningsvern:	Ja
Driftshøyde:	0 - 3000 m
Relativ luftfuktighet under drift (H-H):	0 - 90
Antall AC outlets:	12 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332238662
Masterkassens (ytterkassens) bruttovekt:	21360 g
Masterkassens (ytterkassens) lengde:	475 mm
Produkter per masterkasse (ytterkasse):	6 stykker
Masterkassens (ytterkassens) bredde:	395 mm
Masterkassens (ytterkassens) høyde:	428 mm
Hørbare alarmer:	Ja
Strøm (maks.):	10 A
AC-utgangstyper:	NEMA 5-15R
Strømuttak:	NEMA 5-15P
Strømstøt energivurdering:	316 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	0.8 kVA
Inngangsspenning (min.):	120 V
Utgangsspenning (min.):	110 V
Normal backuptid ved halv belastning:	8.6 min
Normal backuptid ved full belastning:	2 min
Kald oppstart:	Ja
USB port type:	USB Type-B
