Side 1/208

Owner’s Manual

Extended-Run Battery Cabinet

Models: BP240V65, BP240V65-NIB, BP240V65L, BP240V65L-NIB,

BP240V100, BP240V100-NIB, BP240V100L, BP240V100L-NIB

Not suitable for mobile applications.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Español 69 • Français 137

Table of Contents

1. Introduction 3

1.1 Features 3

1.2 UPS and Battery Cabinet 4

Compatibility Chart

2. Important Safety Instructions 5

2.1 Installation and Location Warnings 5

2.2 Connection Warnings 5

2.3 Battery Warnings 6

2.4 Standards Compliance 6

3. Battery Cabinet Installation 7

3.1 Preparation 7

3.2 Transportation 7

3.3 Mechanical Check 7

3.4 Package Contents 8

3.5 Internal Wiring (Typical) 8

3.6 Battery Cabinet Placement 9

3.7 Electrical Connection 9

3.8 Final Electrical Check 10

4. Mechanical Data 10

4.1 Physical Measurements 10

4.1.1 Dimensions for BP240V65, 10

BP240V65-NIB, BP240V100,

BP240V100-NIB

4.1.2 Dimensions for BP240V65L, 12

BP240V65L-NIB, BP240V100L,

BP240V100L-NIB

4.2

Physical Requirements (All Models)

5. Installation 15

5.1 Unpacking and Inspection 15

5.2 Selecting Installation Position 16

5.3 Power Cables 17

5.3.1 Cable Sizes 17

5.4 Battery Cabinet Connections – 17

Models BP240V65, BP240V65-NIB,

BP240V100, BP240V100-NIB

5.4.1 Remove the Chassis Shell 18

5.4.2 Battery Installation 18

and Connection

5.4.2.1 Battery Installation 22

and Setup: Models

BP240V65-NIB,

BP240V100-NIB

5.5 Battery Cabinet Connections – 32

Models BP240V65L,

BP240V65L-NIB, BP240V100L,

BP240V100L-NIB

5.5.1 Remove the Chassis Shell 32

5.5.2 Battery Installation and 33

Connection

5.5.2.1 Battery Installation 37

and Setup: Models

BP240V65L-NIB,

BP240V100L-NIB

5.6

Multiple Battery Pack Connections

6. Operation and Conﬁguration 52

of S3M UPS Models

and Battery Cabinets

6.1 S3M UPS Compatibility with 52

BP240V65 to BP240V100L

Battery Cabinets

6.2 Conﬁguring 10-20K UPS for 53

Speciﬁc Battery Cabinets using

the LCD Display

6.2.1 S3M 10-20K UPS Home Display 53

6.2.2 Setting 55

6.2.3 Battery Setup 56

6.2.4 Conﬁuring the S3M 10-20-NIB 57

and Optimizing Charging of

BP240V65/V65L and

BP240V100/V100L

Battery Cabinets

6.3 Conﬁguring 25-100K UPS for 59

Speciﬁc Battery Cabinets

Using the LCD Display

6.3.1 S3M 25-100K UPS Home Display 60

6.3.2 Setting 60

6.3.3 Battery Setup: Click BATT Setup 62

6.3.4 Conﬁguring the S3M25-100K UPS

and Optimizing Charging of the

BP240V65/V65L and

BP240V100/V100L Battery Cabinets

6.4 Conﬁguring Reference Tables 66

7. Speciﬁcations 67

7.1 Battery Cabinet Speciﬁcations 67

8. Storage 67

9. Service and Warranty 68

1. Introduction

Tripp Lite’s Extended-Run Battery Cabinets connect to SmartOnline® UPS Systems to provide long-lasting battery backup

for data centers, telecommunications, networks, industrial facilities, security, emergency systems and other mission-critical

applications that require high capacity, high availability and extended runtime.

Battery cabinets are available in seven models, with pre-installed batteries and without: BP240V65, BP240V65-NIB,

BP240V65L, BP240V65L-NIB, BP240V100, BP240V100-NIB, BP240V100L-NIB.

The “-NIB” sufﬁx battery cabinet models BP240V65-NIB, BP240V65L-NIB, BP240V100-NIB and BP240V40L-NIB do not include

pre-installed batteries. However, they include all of the jumper cables, fuses and breakers, enabling the ﬂexibility to purchase

batteries separately for the battery cabinets. The BP240V65-NIB and BP240V65L-NIB battery cabinets are designed for CSB

GP12650i batteries. The BP240V100-NIB and BP240V100L-NIB battery cabinets are designed for CSB GP121000 batteries.

1.1 Features

• The battery cabinets are designed for battery string voltages of ± 120V DC and battery capacities of 65Ah or 100Ah,

@ C20 to 1.67VPC.

• Battery cabinets contain multiple 12V DC AGM batteries connected in series to achieve higher voltages.

• Each battery cabinet contains several shelves to achieve the required battery string voltages:

o BP240V65 / BP240V65-NIB: Holds 20 x 65Ah AGM batteries

o BP240V100 / BP240V100-NIB: Holds 20 x 100Ah AGM batteries

o BP240V65L / BP240V65L-NIB: Holds 40 x 65Ah AGM batteries

o BP240V100L / BP240V100L-NIB: Holds 40 x 100Ah AGM batteries

• A hinged, lockable door facilitates access to batteries for periodic maintenance.

• A minimum of 4 in. (100 mm) clearance is located above the individual batteries for access to terminals.

• The battery cabinet is constructed of heavy-gauge steel for durability.

• A baked powder-coat ﬁnish provides corrosion resistance.

• The battery cabinet ships bolted to a pallet with a double layer of protective stretch wrap and integrated corner and top

protection.

• Appropriate ventilation and convection cooling of individual batteries is provided via spacing between batteries. Front and

rear vents allow the free ﬂow of warmer air out of the battery cabinet.

• A molded case circuit breaker is provided for overcurrent protection.

• User-supplied power output cables can be fed into the battery cabinet via built-in conduit knockouts on the bottom of

the cabinet.

• For improved safety, higher power density and minimized maintenance, the cabinet systems use Valve-Regulated Lead-Acid

(VRLA) recombinant batteries. The electrolyte in these batteries is immobilized in either an absorbent mat separator or a

gelling medium, eliminating the spilling hazards and maintenance requirements of free liquid electrolyte. There is no need

to add water or measure speciﬁc gravity.

• Because the batteries are recombinant cells that employ an oxygen recombination cycle, minimal gasses are emitted during

normal ﬂoat charging. Each cell contains an individual valve, which releases the gas products from overcharge and prevents

pressure build-up within the cell.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	BP240V100L
Vekt:	1638380 g
Bredde:	800.1 mm
Dybde:	1102.4 mm
Høyde:	1600.2 mm
Bruksanvisning:	Ja
Batterikapasitet:	100 Ah
Opprinnelsesland:	China
Pakkevekt:	1708460 g
Kompatible produkter:	S3M50K, S3M60K, S3M80K, S3M100K
Batteriteknologi:	Forseglet blysyre (VRLA)
Produktfarge:	Sort
Pakkedybde:	1247.1 mm
Pakkehøyde:	1800.9 mm
Pakkebredde:	919.5 mm
Antall støttede batterier:	40
Bærekraftsertifikater:	RoHS
Formfaktor:	Tower
Kroppsmateriale:	Stål
Masterkassens (ytterkassens) bruttovekt:	1708460 g
Masterkassens (ytterkassens) lengde:	1247.1 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	919.5 mm
Masterkassens (ytterkassens) høyde:	1800.9 mm
Antall:	1
