Side 1/32

Standby UPS Systems

Models:

BC350, BC450, BC500, INTERNET350U, INTERNET350SER,

INTERNET550SER, INTERNET550U, INTERNET600U,

INTERNET650U1

(Series Numbers: AG-030D, AG-030E, AG-030F, AG-0311,

AG-0312, AG-87AF, AG-0305, AG-0307, AG-0394)

Important Safety Instructions ............ 2

Quick Installation .............................. 4

Optional Installation .......................... 5

Basic Operation ................................ 5

UPS On/Off ................................... 5

LED Indicator ................................ 6

Features ........................................... 7

UPS Features ................................ 7

Battery Replacement ....................... 8

Storage and Service ......................... 9

Product Registration and................... 9

Regulatory Compliance

Español........................................... 11

Français .......................................... 21

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

18-11-058-933864.indb 1 11/20/2018 8:28:42 AM

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the

installation, operation and storage of this product. Failure to heed these warnings

may affect the warranty.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, conductive contaminants,

dust or direct sunlight.

• For best performance, keep the indoor temperature between 32º F and 104º F (0º C and

40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

• Only set the UPS upright on a sturdy ﬂat surface.

UPS Connection Warnings

• Connect your UPS directly to a properly grounded AC power outlet. Do not plug the UPS into

itself; this will damage the UPS.

• Do not modify the UPS plug, and do not use an adapter that would eliminate the UPS

ground connection.

• Do not use extension cords to connect the UPS to an AC outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must provide

clean, ﬁltered, computer-grade output.

• The mains socket outlet that supplies the UPS should be easily accessible and located near

the UPS.

Equipment Connection Warnings

Install in accordance with National Electrical Code standards ANSI/NFPA

70 and Canadian Electrical Code, Part I, C22.1.

Short-circuit backup protection and overcurrent protection is provided by

the building installation.

To reduce the risk of ﬁre, connect only to a circuit provided branch circuit

overcurrent protection in accordance with the National Electrical Code,

ANSI/NFPA 70 and the Canadian Electrical Code, Part I, C22.1. The plug on

the power supply cord is intended to serve as the disconnect device. Be

sure that the socket-outlet is installed near the equipment and is made

easily accessible.

• Use of this equipment in life support applications where failure of this equipment can

reasonably be expected to cause the failure of the life support equipment or to signiﬁcantly

affect its safety or effectiveness is not recommended.

• Do not connect surge protectors or extension cords to the output of your UPS. This might

damage the UPS and may affect the surge protector and UPS warranties.

• Connect the UPS to an outlet that is adequately protected against excess currents, short

circuits and earth faults as part of the building installation.

Important Safety Instructions

18-11-058-933864.indb 2 11/20/2018 8:28:42 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	Internet650U1
Vekt:	1800 g
Bredde:	110 mm
Dybde:	184.9 mm
Høyde:	104.9 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-port:	Ja
Opprinnelsesland:	Vietnam
Pakkevekt:	2220 g
Antall USB 2.0-porter:	2
Utgangseffekt:	330 W
Utgangsspenning (maks.):	120 V
UPS topologi:	Standby (Offline)
Antall inngangsfaser:	1
Utgangsfrekvens:	50/60 Hz
Hørbare alarmmoduser:	Battery replacement, Fault, Low battery alarm, Overload alarm
Bølgeform:	Sinus
Inngangsspenning (maks.):	120 V
Kabellengde:	1.5 m
Produktfarge:	Sort
Pakkedybde:	275.8 mm
Pakkehøyde:	180.3 mm
Pakkebredde:	144 mm
Kabler inkludert:	USB-kabel
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 45 °C
Lagringsrelativ fuktighet:	0 - 90
Bærekraftsertifikater:	RoHS
Formfaktor:	Kompakt
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Overspenningsvern:	Ja
Driftshøyde:	0 - 3000 m
Relativ luftfuktighet under drift (H-H):	0 - 90
Antall AC outlets:	8 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332211054
Masterkassens (ytterkassens) bruttovekt:	18460 g
Masterkassens (ytterkassens) lengde:	591.8 mm
Produkter per masterkasse (ytterkasse):	8 stykker
Masterkassens (ytterkassens) bredde:	286 mm
Masterkassens (ytterkassens) høyde:	393.7 mm
Hørbare alarmer:	Ja
Strøm (maks.):	6 A
AC-utgangstyper:	NEMA 5-15R
Strømuttak:	NEMA 5-15P
Strømstøt energivurdering:	316 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	0.65 kVA
Inngangsspenning (min.):	120 V
Utgangsspenning (min.):	110 V
Normal backuptid ved halv belastning:	4.5 min
Kald oppstart:	Ja
Output spenningsforskrift:	±5%
