Owner’s Manual

1111 W. 35th Street Chicago, IL 60609 USA

Customer Support: (773) 869-1234 • www.tripplite.com

Important Safety Instructions

Quick Installation

Basic Operation

Storage & Service

Specifications

Models: OMNIVSINT800,

OMNIVSINT1000, OMNIVSINT1500XL*

230V Input, Line-Interactive UPS Systems (Tower Configuration)

* Extended runtime options

Español

Français

Póññêè

Important Safety Instructions

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, dust or direct sunlight.

• For best performance, keep the indoor temperature between between 32º F and 104º F

(0º C and 40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

UPS Connection Warnings

• Connect your UPS directly to a properly grounded AC power outlet. Do not plug the UPS

into itself; this will damage the UPS.

• Do not modify the UPS’s plug, and do not use an adapter that would eliminate the UPS’s

ground connection.

• Do not use extension cords to connect the UPS to an AC outlet. Your warranty will be

voided if anything other than Tripp Lite surge suppressors are used to connect your UPS

to an outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must

provide clean, filtered, computer-grade output.

Equipment Connection Warnings

• Do not use Tripp Lite UPS Systems for life-support applications in which a malfunction

or failure of a Tripp Lite UPS System could cause failure or significantly alter the

performance of a life-support device.

• Do not connect surge suppressors or extension cords to the output of your UPS.

Battery Warnings

• Except for battery replacement, your UPS does not require routine maintenance. Do not

open your UPS for any reason. There are no user-serviceable parts inside.

• Because batteries present a risk of electrical shock and burn from high short-circuit current,

qualified service personnel should observe proper precautions: Use tools with insulated

handles and replace the existing batteries with the same number and type of new batteries

(Sealed Lead-Acid). Do not open the batteries. Do not short or bridge the battery terminals

with any object. Tripp Lite offers a complete line of UPS System Replacement Battery

Cartridges (R.B.C.). Visit Tripp Lite on the Web at www.tripplite.com/support/battery/index.cfm

to locate the specific replacement battery for your UPS.

• During hot-swap battery replacement, the UPS will not provide backup power in the

event of a blackout or other power interruptions.

• Do not operate UPS without batteries.

• Do not dispose of the batteries in a fire. The UPS batteries are recyclable. Refer to local

codes for disposal requirements.

• When adding external battery packs to select models with external battery pack connectors,

connect only Tripp Lite-recommended battery packs of the correct voltage and type. Do

not connect or disconnect battery packs when the UPS is operating on battery power.

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the

installation, operation and storage of all Tripp Lite UPS Systems. Failure to heed these

warnings will void your warranty.

Quick Installation

Unplug the computer’s power

cord from both AC outlet and

the computer’s AC input.

Insert the female plug of the

computer’s cord into the UPS’s AC

input. Insert the male plug of the

computer’s cord into AC outlet.*

NOTE! After you plug the UPS into a live AC outlet, the UPS will

turn ON automatically. See “ON/OFF” Button description in the

Basic Operation section if you want to place the UPS in any mode

other than ON.

* See Specifications for circuit amperage requirements.

Using one of the jumper cords

supplied with the UPS, insert

the cord’s female plug into

computer’s AC input . Insert

the cord’s male plug into any of

UPS’s female output receptacles.

Plug additional equipment into

the UPS.*

Use one of the additional jumper cords supplied with

the UPS, or order additional jumper cords from

Tripp Lite. Call (773) 869-1234; order part # P004-006.

* Your UPS is designed to support only computer equipment. You

will overload the UPS if the total VA ratings for all the equipment you

connect exceeds the UPS’s output capacity (see Specifications). To

find your equipment's VA ratings, look on their nameplates. If the

equipment is listed in amps, multiply the number of amps by 230 to

determine VA. (Example: 1 amp × 230 = 230 VA). If you are unsure if

you have overloaded the UPS’s outlets, see “OUTPUT LOAD

LEVEL” LED description.

NORM DELAY

IEC320-C14 plug shown

Shown: OMNIVSINT1000

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	Omni VS
Vekt:	8850 g
Bredde:	133.4 mm
Dybde:	190.5 mm
Høyde:	273 mm
LED-indikatorer:	Ja
Opprinnelsesland:	China
Pakkevekt:	9940 g
Antall USB 2.0-porter:	1
Sertifisering:	UL1778, CE, GOST, SASO, IRAM
Utgangseffekt:	475 W
Utgangsspenning (maks.):	240 V
Effektivitet:	97
UPS topologi:	Linje-Interactive
Antall inngangsfaser:	1
Bølgeform:	Sinus
Batteriladetid:	4.5 timer
Inngangsspenning (maks.):	230 V
Kabellengde:	0.2 m
Produktfarge:	Sort
Pakkedybde:	348 mm
Pakkehøyde:	246.4 mm
Pakkebredde:	190.5 mm
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Harmonisert system (HS)-kode:	85078000
Formfaktor:	Tower
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Polyvinylklorid (PVC)
Overspenningsvern:	Ja
Strømbeskyttelsesfunksjoner:	Under voltage
Rack-kapasitet:	2U
Relativ luftfuktighet under drift (H-H):	0 - 95
Antall AC outlets:	4 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332120967
Masterkassens (ytterkassens) bruttovekt:	19870 g
Masterkassens (ytterkassens) lengde:	421.6 mm
Produkter per masterkasse (ytterkasse):	2 stykker
Masterkassens (ytterkassens) bredde:	279.4 mm
Masterkassens (ytterkassens) høyde:	378.5 mm
Hørbare alarmer:	Ja
Strøm (maks.):	2.4 A
AC-utgangstyper:	C13 kopling
Strømuttak:	C14 kopling
Strømstøt energivurdering:	340 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	0.8 kVA
Inngangsspenning (min.):	159 V
Utgangsspenning (min.):	220 V
Normal backuptid ved halv belastning:	11.5 min
Normal backuptid ved full belastning:	3.5 min
Kald oppstart:	Ja
Hot-swap-batterier:	Ja
Automatic Voltage Regulation (AVR):	Ja
Output spenningsforskrift:	5
