Side 1/56

UPS Systems

Models:

OMNIVSX850, OMNIVSX850D, OMNIVSX1000,

OMNIVSX1000D, OMNIVSX1500, OMNIVSX1500D

(Series Numbers: AG-02FC, AG-02F5, AG-87E4, AG-02FD, AG-87E6, AG-02FE)

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Español 12 • Français 23 • Русский 34 • Deutsch 45

18-07-252-93388F.indb 1 10/3/2018 10:10:23 AM

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the

installation, operation and storage of this product. Failure to heed these warnings may

affect the warranty.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, conductive contaminants, dust or

direct sunlight.

• For best performance, keep the indoor temperature between 32º F and 104º F

(0º C and 40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

• Only set the UPS upright on a sturdy ﬂat surface. Do not block fans or ventilation holes, as this will

seriously inhibit the unit's internal cooling and cause product damage not covered under warranty.

UPS Connection Warnings

• Connect your UPS directly to a properly grounded AC power outlet. Do not plug the UPS into itself;

this will damage the UPS.

• Do not modify the UPS plug, and do not use an adapter that would eliminate the UPS ground

connection.

• Do not use extension cords to connect the UPS to an AC outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must provide clean,

ﬁltered, computer-grade output.

• The mains socket outlet that supplies the UPS should be easily accessible and located near the

UPS.

Equipment Connection Warnings

Short Circuit backup protection and overcurrent protection is provided by the

building installation.

To reduce the risk of ﬁre, connect only to a circuit provided branch circuit

overcurrent protection. The plug on the power supply cord is intended to serve

as the disconnect device. Be sure the socket-outlet is installed near the

equipment and is made easily accessible.

• Use of this equipment in life support applications where failure of this equipment can reasonably

be expected to cause the failure of the life support equipment or to signiﬁcantly affect its safety or

effectiveness is not recommended.

• Do not connect surge protectors or extension cords to the output of your UPS. This might damage

the UPS and may affect the surge protector and UPS warranties.

• Connect the UPS to an outlet that is adequately protected against excess currents, short circuits

and earth faults as part of the building installation.

Important Safety Instructions

18-07-252-93388F.indb 2 10/3/2018 10:10:23 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	OmniVSOMNIVSX850
Vekt:	5990 g
Bredde:	121.9 mm
Dybde:	345.4 mm
Høyde:	160 mm
Støynivå:	40 dB
Bruksanvisning:	Ja
USB-port:	Ja
Opprinnelsesland:	China
Pakkevekt:	6490 g
Sertifisering:	IEC 62040-1:2008+A1:2013; EN62040-2:2006, IEC62040-2:2016, Category C2
Utgangseffekt:	480 W
Utgangsspenning (maks.):	240 V
Effektivitet:	95
UPS topologi:	Linje-Interactive
Antall inngangsfaser:	1
Hørbare alarmmoduser:	Alarm when on battery, Low battery alarm
Bølgeform:	Sinus
Overføringstid (linjemodus til batterimodus):	6 ms
Inngangsspenning (maks.):	240 V
Produktfarge:	Sort
Pakkedybde:	599.4 mm
Pakkehøyde:	248.9 mm
Pakkebredde:	360.7 mm
Skjermtype:	LCD
Kabler inkludert:	USB-kabel
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Formfaktor:	Tower
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Relativ luftfuktighet under drift (H-H):	0 - 90
Oppdateringsresponstid:	0 ms
Antall AC outlets:	6 AC-utganger
Masterkassens (ytterkassens) bruttovekt:	6490 g
Masterkassens (ytterkassens) lengde:	599.4 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	360.7 mm
Masterkassens (ytterkassens) høyde:	248.9 mm
Hørbare alarmer:	Ja
Strøm (maks.):	5 A
AC-utgangstyper:	C13 kopling
Strømuttak:	C14 kopling
Strømstøt energivurdering:	312 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	0.85 kVA
Inngangsspenning (min.):	220 V
Utgangsspenning (min.):	220 V
Normal backuptid ved halv belastning:	5 min
Kald oppstart:	Ja
Automatic Voltage Regulation (AVR):	Ja
Batteriladetid (90 %):	8 timer
