Side 1/36

Owner’s Manual

SMART700DV

Intelligent, Line-Interactive UPS System

(Series Number: AGSM5436)

• 120V/230V Auto-Sensing Input, 120V Output

Not suitable for mobile applications.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Important Safety Instructions 2

Quick Installation 4

Optional Installation 5

Basic Operation 6

Battery Replacement 10

Storage and Service 10

Specifications 11

Product Registration 12

Regulatory Compliance 12

Español 13 • Français 25

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains important instructions that should be followed during the

installation, operation and storage of all Tripp Lite UPS Systems. Failure to heed

these warnings will void your warranty.

UPS Location Warnings

• The UPS is heavy. Use caution when lifting it.

• Your UPS is intended to be used in a temperature/humidity controlled environment,

indoor area that is relatively free of conductive contaminants. Install your UPS

indoors, away from excess moisture, heat, conductive contaminants, dust and direct

sunlight.

• For best performance, the ambient temperature near your UPS should be between

0° C and 40° C (between 32° F and 104° F).

• Leave adequate space around all sides of the UPS for proper ventilation. Do not

obstruct its vents or fan openings.

UPS Connection Warnings

• CAUTION: Install in accordance with National Electrical Code standards ANSI/NFPA

70 and Canadian Electrical Code, Part I, C22.1.

• Short-circuit backup protection and overcurrent protection is provided by the building

installation.

• To reduce the risk of fire, connect only to a circuit-provided branch circuit overcurrent

protection in accordance with the National Electrical Code, ANSI/NFPA 70 and the

Canadian Electrical Code, Part I, C22.1. Be sure to use maximum 20A overcurrent

protection, in accordance with the plug/equipment rating, for the installation.

• The plug on the power supply cord is intended to serve as the disconnect device.

Be sure that the socket-outlet is installed near the equipment and is made easily

accessible.

• The UPS contains its own energy source (battery). The output terminals may be live

even when the UPS is not connected to an AC supply.

• Connect your UPS to a properly grounded AC power outlet. Do not modify the UPS’s

plug in a way that would eliminate the UPS’s connection to ground. Do not use

adapters that eliminate the UPS’s connection to ground.

• Do not plug your UPS into itself; this will damage the UPS and void your warranty.

• If you are connecting your UPS to a motor-powered AC generator, the generator must

provide filtered, frequency-regulated computer-grade output. Connecting your UPS to

a generator will void its Ultimate Lifetime Insurance.

Equipment Connection Warnings

• Use of this equipment in life support applications where failure of this equipment

can reasonably be expected to cause the failure of the life support equipment or to

significantly affect its safety or effectiveness is not recommended.

• Do not connect surge protectors or extension cords to the output of your UPS. This

might overload the UPS and will void the surge protector and UPS warranties.

Important Safety Instructions

Battery Warnings

• Batteries can present a risk of electrical shock and burn from high short-circuit

current. Observe proper precautions. Do not dispose of the batteries in a fire. Do

not open the UPS or batteries. Do not short or bridge the battery terminals with any

object. Unplug and turn off the UPS before performing battery replacement. Use tools

with insulated handles. There are no user-serviceable parts inside the UPS. Battery

replacement should be performed only by authorized service personnel using the

same number and type of batteries (Sealed Lead-Acid). The batteries are recyclable.

Refer to your local codes for disposal requirements or visit tripplite.com/support/

recycling-program for recycling information. Tripp Lite offers a complete line of UPS

system Replacement Battery Cartridges (R.B.C.). Visit Tripp Lite at tripplite.com to

locate the specific replacement battery for your UPS.

• During hot-swap battery replacement, the UPS will not provide backup power in the

event of a blackout or other power interruptions.

• Do not operate UPS without batteries.

• Do not attempt to add external batteries to the UPS.

UPS and Battery Recycling

Please recycle Tripp Lite Products. The batteries used in Tripp Lite products

are sealed Lead-Acid batteries. These batteries are highly recyclable. Please

refer to your local codes for disposal requirements.

You can call Tripp Lite for recycling info at 773.869.1234.

You can go the Tripp Lite Website for up-to-date information on recycling the

batteries or any Tripp Lite product. For more information, visit.tripplite.com/

en/support/recycling-program.cfm

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SMART700DV
Vekt:	28120 g
Bredde:	228.6 mm
Dybde:	317.5 mm
Høyde:	260.4 mm
LED-indikatorer:	Ja
Opprinnelsesland:	Taiwan
Pakkevekt:	35380 g
Antall USB 2.0-porter:	1
Sertifisering:	UL1778, CSA, CE, FCC,
Utgangseffekt:	450 W
Utgangsspenning (maks.):	- V
Effektivitet:	94
UPS topologi:	Linje-Interactive
Antall inngangsfaser:	1
Bølgeform:	Sinus
Batteriladetid:	4 timer
Inngangsspenning (maks.):	230 V
Kabellengde:	1.8 m
Produktfarge:	Sort
Pakkedybde:	450.8 mm
Pakkehøyde:	387.4 mm
Pakkebredde:	362 mm
RS-232-port:	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Formfaktor:	Tower
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Stål
Strømbeskyttelsesfunksjoner:	Over voltage, Under voltage
Relativ luftfuktighet under drift (H-H):	0 - 95
Form for nedkjøling:	Aktiv
Antall AC outlets:	6 AC-utganger
Masterkassens (ytterkassens) bruttovekt:	35380 g
Masterkassens (ytterkassens) lengde:	450.8 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	362 mm
Masterkassens (ytterkassens) høyde:	387.4 mm
Hørbare alarmer:	Ja
Strøm (maks.):	6 A
AC-utgangstyper:	NEMA 5–15R
Strømuttak:	NEMA 5-15P
Strømfaktor:	0.6
Nominell outputspenning:	120 V
Strømstøt energivurdering:	570 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	0.7 kVA
Inngangsspenning (min.):	83 V
Utgangsspenning (min.):	120 V
Nødstrøm av (EPO):	Ja
Modem (RJ-11)-porter:	1
Normal backuptid ved halv belastning:	54.5 min
Normal backuptid ved full belastning:	22.2 min
Kald oppstart:	Ja
Hot-swap-batterier:	Ja
Automatic Voltage Regulation (AVR):	Ja
Output spenningsforskrift:	-21, +8
