Side 1/48

Owner’s Manual

Smart and OmniSmart

Medical-Grade UPS Systems

Models:

OMNISMART350HG

(Series Number: AGOM350KSR57HG)

Important Safety Instructions 2

Package Contents 5

Quick Installation 6

Basic Operation 8

Guidance and Manufacturer’s Declaration 14

Storage & Service 15

Regulatory Compliance & 16

Product Registration

Español 17

Français 33

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

SMART700HG

(Series Number: AGSM700PSR3HG)

SMART1200XLHG

(Series Number: AGSM1200PSR3HG)

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

15-11-178-9332C2.indb 1 12/4/2015 9:20:10 AM

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the installation,

operation and storage of all Tripp Lite UPS Systems. Failure to heed these warnings may affect

your warranty.

Statement of Intended Use

Tripp Lite Medical-Grade UPS Systems are intended to support and protect non-medical and

medical computer equipment and medical devices that require leakage current reduction, surge

protection, voltage regulation, line noise ﬁltering and battery backup during power outages and

generator testing, both inside and outside patient care areas. Tripp Lite’s Medical-Grade UPS

Systems come with hospital-grade plugs and receptacles that reduce leakage to below 100μA.

Product Information

AGOM350KSR57HG AGSM700PSR3HG AGSM1200PSR3HG

AC Input Voltage 120 120 120

AC Input Voltage Range 83–147 81–143 81–143

Input Amp(s) 2.3 5.5 9.2

Output Amps(s) 1.9 5.8 6.25

Rated Power (VA/Watts) 330VA/225W 700VA/450W 1000VA/750W

Frequency 50/60 Hz 50/60 Hz 50/60 Hz

No. of Phases Single Single Single

Class Type Class I Class I Class I

Plug/Connector Type NEMA 5-15P NEMA 5-15P NEMA 5-15P

Operation Continuous Continuous Continuous

AC Input Protection (Qty./type/rating) Input breaker

(2 x 3.5A), thermal

Input breaker

(2 x 10A), thermal

Input breaker

(2 x 15A), thermal

Max Leakage Current (uA) Less than 100uA Less than 100uA Less than 100uA

Weight 25.0 lbs 44.2 lbs 46.4 lbs

Known Contraindication None None None

UPS Location Warnings

Relevant Symbols

Denotes that information in the manual should be reviewed before use.

Used to signal a warning that a statement is particularly important and could pose a safety

risk.

Warning-Dangerous Voltage No sitting

Denotes general warning sign No stepping on surface

Refer to Instruction Manual/Booklet No pushing

15-11-178-9332C2.indb 2 12/4/2015 9:20:10 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SmartPro
Vekt:	7400 g
Bredde:	439.9 mm
Dybde:	286 mm
Høyde:	43.9 mm
LED-indikatorer:	Ja
Opprinnelsesland:	China
Pakkevekt:	8030 g
Antall USB 2.0-porter:	1
Sertifisering:	CE, GOST, SASO, IRAM
Utgangseffekt:	300 W
Utgangsspenning (maks.):	240 V
Effektivitet:	95
UPS topologi:	Linje-Interactive
Bølgeform:	Sinus
Batteriladetid:	4 timer
Inngangsspenning (maks.):	230 V
Produktfarge:	Sort
Pakkedybde:	533.4 mm
Pakkehøyde:	106.7 mm
Pakkebredde:	401.3 mm
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Formfaktor:	Rackmontering
Inngangsfrekvens:	- Hz
Overspenningsvern:	Ja
Kommunikasjonsserieporter:	1
Relativ luftfuktighet under drift (H-H):	0 - 95
Oppdateringsresponstid:	4 ms
Antall AC outlets:	8 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	10037332119251
Masterkassens (ytterkassens) bruttovekt:	17460 g
Masterkassens (ytterkassens) lengde:	551.2 mm
Produkter per masterkasse (ytterkasse):	2 stykker
Masterkassens (ytterkassens) bredde:	408.9 mm
Masterkassens (ytterkassens) høyde:	254 mm
Hørbare alarmer:	Ja
AC-utgangstyper:	C13 kopling
Strømuttak:	C14 kopling
Strømstøt energivurdering:	480 J
Output strømkapasitet (VA):	0.5 kVA
Inngangsspenning (min.):	230 V
Utgangsspenning (min.):	220 V
Nødstrøm av (EPO):	Ja
Normal backuptid ved halv belastning:	14.6 min
Normal backuptid ved full belastning:	3.2 min
Hot-swap-batterier:	Ja
