Side 1/36

UPS Systems

Models:

SMART750TSU, SMART1050TSU

(Series Numbers: AG-888F, AG-8890)

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Español 13 • Français 25

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $100 value!

www.tripplite.com/warranty

18-12-064-933901.indb 1 1/9/2019 5:01:22 PM

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the

installation, operation, maintenance and storage of the UPS and batteries. Failure

to heed these warnings may affect the warranty.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, conductive contaminants, dust

or direct sunlight.

• For best performance, keep the indoor temperature between 32º F and 104º F

(0º C and 40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

• Only set the UPS upright on a sturdy ﬂat surface. Do not block fans or ventilation holes, as

this will seriously inhibit the unit's internal cooling and cause product damage not covered

under warranty.

UPS Connection Warnings

• Connect your UPS directly to a properly-grounded AC power outlet. Do not plug the UPS into

itself; this will damage the UPS.

• Do not modify the UPS plug, and do not use an adapter that would eliminate the UPS

ground connection.

• Do not use extension cords to connect the UPS to an AC outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must provide

clean, ﬁltered, computer-grade output.

• The mains socket outlet that supplies the UPS should be easily accessible and located near

the UPS.

Equipment Connection Warnings

Install in accordance with National Electrical Code standards ANSI/NFPA

70 and Canadian Electrical Code, Part I, C22.1.

Short-circuit backup protection and overcurrent protection is provided by

the building installation.

To reduce the risk of ﬁre, connect only to a circuit provided branch circuit

overcurrent protection in accordance with the National Electrical Code,

ANSI/NFPA 70 and the Canadian Electrical Code, Part I, C22.1. The plug on

the power supply cord is intended to serve as the disconnect device. Be

sure that the socket-outlet is installed near the equipment and is made

easily accessible.

Important Safety Instructions

18-12-064-933901.indb 2 1/9/2019 5:01:23 PM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SmartPro SMART1050TSU
Vekt:	10480 g
Bredde:	139.7 mm
Dybde:	381 mm
Høyde:	190.5 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Innebygd vifte:	Ja
Opprinnelsesland:	Vietnam
Pakkevekt:	11020 g
Utgangseffekt:	900 W
Utgangsspenning (maks.):	120 V
UPS topologi:	Linje-Interactive
Antall inngangsfaser:	1
Utgangsfrekvens:	50/60 Hz
Hørbare alarmmoduser:	Alarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
Bølgeform:	Sinus
Inngangsspenning (maks.):	120 V
Kabellengde:	1.5 m
Produktfarge:	Sort
Pakkedybde:	495.3 mm
Pakkehøyde:	297.2 mm
Pakkebredde:	236.2 mm
Skjermtype:	LCD
Kabler inkludert:	RS-232, USB cable
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 45 °C
Lagringsrelativ fuktighet:	0 - 90
Formfaktor:	Tower
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Akrylonitril-butadien-styren (ABS)
Overspenningsvern:	Ja
Relativ luftfuktighet under drift (H-H):	0 - 90
Form for nedkjøling:	Aktiv
Antall AC outlets:	8 AC-utganger
Masterkassens (ytterkassens) bruttovekt:	11020 g
Masterkassens (ytterkassens) lengde:	495.3 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	236.2 mm
Masterkassens (ytterkassens) høyde:	297.2 mm
Hørbare alarmer:	Ja
Strøm (maks.):	12 A
AC-utgangstyper:	NEMA 5–15R
Strømfaktor:	0.86
Strømstøt energivurdering:	316 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	1.05 kVA
Inngangsspenning (min.):	110 V
Utgangsspenning (min.):	110 V
Normal backuptid ved halv belastning:	8.5 min
Normal backuptid ved full belastning:	3 min
Kald oppstart:	Ja
Serielt grensesnitt:	Ja
Automatic Voltage Regulation (AVR):	Ja
