Side 1/64

Owner’s Manual

Español 22

Français 43

SmartPro

2U Rack-Mount

Intelligent, Line-Interactive UPS Systems

120V Sine Wave Output • 2200VA—3000VA Capacities

SMART2200RM2U,

SMART2200RM2UN

(Series Number: AGSM8207)

SMART2000RMXL2U,

SMART2200RMXL2U,

SMART2200RMXLN

(Series Number: AGSM8208)

SM2200RMXL2UP

(Series Number: AGSM7012)

SMART3000RM2U,

SMART3000RM2UN

(Series Number: AGSM8209)

SMART3000RMXL2U,

SMART3000RMXLN

(Series Number: AGSM7010)

SMART2600RM2U

(Series Number: AGSM7012)

Not suitable for mobile applications.

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

www.tripplite.com/warranty

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains important instructions that should be followed during the installation,

operation and storage of this product. Failure to heed these warnings may affect the warranty.

UPS Location Warnings

• Use caution when lifting the UPS. Because of the considerable weight of all rack-mount UPS

systems, at least two people should assist in lifting and installing them.

• Install the UPS indoors, away from excess moisture or heat, dust or direct sunlight.

• For best performance, the ambient temperature near the UPS should be between 0° C and 40° C

(between 32° F and 104° F).

• Leave adequate space around all sides of the UPS for proper ventilation. Do not obstruct its vents

or fan openings.

• When mounting the UPS system in a tower orientation, make sure the LCD panel is at the top of

the UPS, not at the bottom.

• Do not mount unit with its front or rear panel facing down (at any angle). Mounting in this manner

will seriously inhibit the unit’s internal cooling, eventually causing product damage not covered

under warranty.

UPS Connection Warnings

• The UPS contains its own energy source (battery). The output terminals may be live even when

the UPS is not connected to an AC supply.

• Connect the UPS to a properly grounded AC power outlet. Do not modify the UPS’s plug in a way

that would eliminate the UPS’s connection to ground. Do not use adapters that eliminate the

UPS’s connection to ground.

• Do not plug the UPS into itself; this will damage the UPS and void your warranty.

• If you are connecting the UPS to a motor-powered AC generator, the generator must provide

filtered, frequency-regulated computer-grade output. Connecting the UPS to a generator will void

its Ultimate Lifetime Insurance.

• Install in accordance with National Electrical Code standards ANSI/NFPA 70 and Canadian

Electrical Code, Part I, C22.1.

• Short Circuit backup protection and overcurrent protection is provided by the building installation

for permanently connected models.

• To reduce the risk of fire, connect only to a circuit provided branch circuit overcurrent protection

in accordance with the National Electrical Code, ANSI/NFPA 70 and the Canadian Electrical Code,

Part I, C22.1. Be sure to use maximum 20A overcurrent protection for model AGSM7012,

and maximum 30A overcurrent protection for model AGSM7010, in accordance with the plug/

equipment rating, for the installation.

• The plug on the power supply cord is intended to serve as the disconnect device. Be sure that the

socket-outlet is installed near the equipment and is made easily accessible.

Caution! This UPS receives power from more than one source. Disconnection of the

AC and DC sources is required to de-energize the unit before servicing.

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SmartPro SMART2000RMXL2U
Vekt:	26130 g
Bredde:	439.9 mm
Dybde:	490 mm
Høyde:	87.9 mm
Støynivå:	45 dB
Bruksanvisning:	Ja
USB-port:	Ja
Innebygd vifte:	Ja
Opprinnelsesland:	China
Pakkevekt:	32340 g
Antall USB 2.0-porter:	1
Sertifisering:	FCC Part 15 Category A, CSA, NOM, UL1778
Utgangseffekt:	1920 W
Utgangsspenning (maks.):	120 V
Effektivitet:	96
UPS topologi:	Linje-Interactive
Antall inngangsfaser:	1
Utgangsfrekvens:	60 Hz
Hørbare alarmmoduser:	Alarm when on battery, Fault, Low battery alarm, Overload alarm
Bølgeform:	Ren sinus
Inngangsspenning (maks.):	145 V
Kabellengde:	3.1 m
Produktfarge:	Sort
Pakkedybde:	548.6 mm
Pakkehøyde:	215.9 mm
Pakkebredde:	617.2 mm
Skjermtype:	LCD
Kabler inkludert:	Serial, USB cable
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	0 - 95
Bærekraftsertifikater:	RoHS
Formfaktor:	Rackmontering
Inngangsfrekvens:	60 Hz
Kroppsmateriale:	Stål
Strømbeskyttelsesfunksjoner:	Over voltage, Under voltage
Rack-kapasitet:	2U
Kommunikasjonsserieporter:	1
Relativ luftfuktighet under drift (H-H):	0 - 95
Form for nedkjøling:	Aktiv
Antall AC outlets:	8 AC-utganger
Masterkassens (ytterkassens) bruttovekt:	32340 g
Masterkassens (ytterkassens) lengde:	548.6 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	617.2 mm
Masterkassens (ytterkassens) høyde:	215.9 mm
Hørbare alarmer:	Ja
Strøm (maks.):	16 A
AC-utgangstyper:	NEMA 5–15R, NEMA 5–20R
Strømuttak:	NEMA 5-20P
Strømfaktor:	0.96
Rack-montert sett:	Ja
Strømstøt energivurdering:	570 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	2 kVA
Inngangsspenning (min.):	83 V
Utgangsspenning (min.):	110 V
Nødstrøm av (EPO):	Ja
Normal backuptid ved halv belastning:	12 min
Normal backuptid ved full belastning:	4.5 min
Kald oppstart:	Ja
USB port type:	USB Type-B
Serielt grensesnitt:	Ja
Nød Kraft Av kontakt (EPO) (Emergency Power Off):	Ja
Hot-swap-batterier:	Ja
Automatic Voltage Regulation (AVR):	Ja
Output spenningsforskrift:	-14 - 6
