Side 1/44

Owner’s Manual

SmartPro

Medical-Grade UPS Systems

(with Lithium Iron Phosphate Batteries)

Models:

Important Safety Instructions 2

Package Contents 5

Connecting the Batteries 6

Quick Installation 7

Basic Operation 9

Guidance and Manufacturer’s Declaration 12

Storage and Service 13

Regulatory Compliance and 14

Product Registration

Español 15

Français 30

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

SMART700HGL

(Series Number: AG-8863)

SMART1200XLHGL

(Series Number: AG-8862)

PROTECT YOUR INVESTMENT!

and ultimate peace of mind.

You could also win an

ISOBAR6ULTRA surge protector—

a $100 value!

www.tripplite.com/warranty

16-07-004-933608.indb 1 8/31/2016 9:59:30 AM

Important Safety Instructions

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the installation,

operation and storage of all Tripp Lite UPS Systems. Failure to heed these warnings may affect

your warranty.

Statement of Intended Use

Tripp Lite Medical-Grade UPS Systems are intended to support and protect non-medical and

medical computer equipment and medical devices that require leakage current reduction, surge

protection, voltage regulation, line noise ﬁltering and battery backup during power outages and

generator testing, both inside and outside patient care areas. Tripp Lite Medical-Grade UPS Systems

come with hospital-grade plugs and receptacles that reduce leakage to below 100μA.

Product Information

SMART700HGL SMART1200XLHGL

AC Input Voltage 120 120

AC Input Voltage Range 81–143 81–143

Input Amp(s) 5.5 9.2

Output Amp 5.8 6.25

Rated Power (VA/Watts) 700VA/450W 1000VA/750W

Frequency 60 Hz 60 Hz

No. of Phases Single Single

Class Type Class I Class I

Plug/Connector Type NEMA 5-15P NEMA 5-15P

Operation Continuous Continuous

AC Input Protection (Qty./type/rating) Input breaker

(2 x 10A), thermal

Input breaker

(2 x 15A), thermal

Max Leakage Current (uA) Less than 100uA Less than 100uA

Weight 33.7 lb. (15.3 kg) 33.6 lb. (15.2 kg)

Known Contraindication None None

UPS Location Warnings

Relevant Symbols

Denotes that information in the manual should be reviewed before use.

Used to signal a warning that a statement is particularly important and could pose a safety

risk.

Warning—Dangerous Voltage No sitting

Denotes general warning sign No stepping on surface

Refer to Instruction Manual/Booklet No pushing

16-07-004-933608.indb 2 8/31/2016 9:59:31 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SmartPro SMART700HGL
Vekt:	14260 g
Bredde:	230.1 mm
Dybde:	190.5 mm
Høyde:	323.1 mm
LED-indikatorer:	Ja
USB-port:	Ja
Opprinnelsesland:	China
Pakkevekt:	16070 g
Utgangseffekt:	450 W
Utgangsspenning (maks.):	120 V
Batteriteknologi:	Lithium Iron Phosphate (LiFePO4)
UPS topologi:	Linje-Interactive
Inngangsspenning (maks.):	- V
Produktfarge:	Hvit
Pakkedybde:	344.9 mm
Pakkehøyde:	435.1 mm
Pakkebredde:	305.1 mm
Antall støttede batterier:	1
Batterispenning:	36 V
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Formfaktor:	Tower
Inngangsfrekvens:	- Hz
Kommunikasjonsserieporter:	1
Relativ luftfuktighet under drift (H-H):	0 - 95
Antall AC outlets:	4 AC-utganger
Masterkassens (ytterkassens) bruttovekt:	16070 g
Masterkassens (ytterkassens) lengde:	344.9 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	305.1 mm
Masterkassens (ytterkassens) høyde:	435.1 mm
Strøm (maks.):	10 A
AC-utgangstyper:	NEMA 5–15R
Strømfaktor:	0.6
Strømstøt energivurdering:	480 J
Output strømkapasitet (VA):	0.7 kVA
Inngangsspenning (min.):	- V
Utgangsspenning (min.):	115 V
Normal backuptid ved halv belastning:	42 min
Normal backuptid ved full belastning:	18 min
Serielt grensesnitt:	Ja
Hot-swap-batterier:	Ja
Automatic Voltage Regulation (AVR):	Ja
