Owner’s Manual

SMX

Medical-Grade UPS Systems

with Lithium Iron Phosphate Batteries

Models:

Important Safety Instructions 2

Package Contents 5

Connecting the Batteries 6

Quick Installation 7

Basic Operation 8

Guidance and Manufacturer’s Declaration 11

Storage & Service 13

Battery Warranty Information 14

Regulatory Compliance 14

Español 15

Français 29

Русский 43

Deutsch 57

SMX700HGL

(Series Number: AG-031B)

SMX1200XLHGL

(Series Number: AG-031C)

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

18-10-326-933821.indb 1 11/7/2018 11:17:04 AM

Important Safety Instructions

Statement of Intended Use

Tripp Lite Medical-Grade UPS Systems are intended to support and protect non-medical computer

equipment and medical devices that require leakage current reduction, surge protection, voltage

regulation, line noise ﬁltering and battery backup during power outages and generator testing, both

inside and outside patient care areas. Tripp Lite’s Medical-Grade UPS Systems come with hospital-

grade plugs and receptacles that reduce leakage to below 100μA.

Product Information

SMX700HGL SMX1200XLHGL

AC Input Voltage 230V 230V

Input Amp(s) 3.6 5

Output Amp(s) 2 3.3

Rated Power (VA/Watts) 700VA, 450W 1000VA, 750W

Frequency 50/60 Hz 50/60 Hz

No. of Phases Single Single

Class Type Class I Class I

Plug/Connector Type Inlet C14 with dongle Inlet C14 with dongle

Operation Continuous Continuous

AC Input Protection (Qty/type/rating) Input breaker (2 x 5A) thermal Input breaker (2 x 6A) thermal

Max Leakage Current (uA) Less than 100uA Less than 100uA

Weight 14.3 kg 15.9 kg

Known Contraindication None None

SAVE THESE INSTRUCTIONS

This manual contains important instructions that should be followed during the installation,

operation and storage of all Tripp Lite UPS Systems. Failure to heed these warnings may affect

your warranty.

Note: Your UPS incorporates overcurrent protection in both the L1 and L2 input conductors.

UPS Location Warnings

Relevant Symbols

Denotes that information in the manual should be reviewed before use.

Used to signal as a warning that a statement is particularly important and could pose a safety

risk.

Warning-Dangerous Voltage No sitting

Denotes general warning sign No stepping on surface

Refer to Instruction Manual/Booklet No pushing

18-10-326-933821.indb 2 11/7/2018 11:17:05 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SmartPro SMX700HGL
Vekt:	14350 g
Bredde:	190.5 mm
Dybde:	229.9 mm
Høyde:	322.6 mm
USB-port:	Ja
Opprinnelsesland:	China
Pakkevekt:	15840 g
Sertifisering:	CE, UL60601-1
Utgangseffekt:	450 W
Utgangsspenning (maks.):	240 V
UPS topologi:	Linje-Interactive
Antall inngangsfaser:	1
Bølgeform:	Sinus
Inngangsspenning (maks.):	230 V
Produktfarge:	Grå
Pakkedybde:	339.9 mm
Pakkehøyde:	469.9 mm
Pakkebredde:	309.9 mm
Driftstemperatur (T-T):	32 - 104 °C
Oppbevaringstemperaturomåde (Celsius):	5 - 122 °C
Harmonisert system (HS)-kode:	85078000
Formfaktor:	Tower
Inngangsfrekvens:	- Hz
Kroppsmateriale:	Polyvinylklorid (PVC)
Relativ luftfuktighet under drift (H-H):	0 - 95
Antall AC outlets:	6 AC-utganger
Masterkassens (ytterkassens) GTIN (EAN/UPC):	00037332224804
Masterkassens (ytterkassens) bruttovekt:	15840 g
Masterkassens (ytterkassens) lengde:	339.9 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	309.9 mm
Masterkassens (ytterkassens) høyde:	469.9 mm
Strøm (maks.):	10 A
AC-utgangstyper:	C13 kopling
Strømuttak:	C14 kopling
Strømstøt energivurdering:	340 J
Output strømkapasitet (VA):	0.7 kVA
Inngangsspenning (min.):	230 V
Utgangsspenning (min.):	220 V
Normal backuptid ved halv belastning:	36 min
Normal backuptid ved full belastning:	14.5 min
Serielt grensesnitt:	Ja
