Side 1/44

LCDT-Series UPS System

Model: SMX1500LCDT

(AG-00A7)

Important Safety Instructions 2

Quick Installation 3

Basic Operation 4

UPS On/Off 4

LCD Display 5

Display UPS/Power Conditions 6

Enable/Disable Alarm 6

Self-Test 7

Error Messages 7

Features 8

Battery Replacement 9

Storage and Service 10

Product Registration 11

Español 12

Français 23

Русский 34

Owner’s Manual

TE ST

MU TE

TEST

MUTE

PROTECT YOUR INVESTMENT!

You could also win an ISOBAR6ULTRA surge protector—a $50 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

is a registered trademark of Tripp Lite.

15-02-071-9332B0.indb 1 2/18/2015 10:17:50 AM

SAVE THESE INSTRUCTIONS

This manual contains instructions and warnings that should be followed during the installation, operation

and storage of this product. Failure to heed these warnings may affect the warranty.

UPS Location Warnings

• Install your UPS indoors, away from excess moisture or heat, conductive contaminants, dust or direct sunlight.

• For best performance, keep the indoor temperature between 32º F and 104º F (0º C and 40º C).

• Leave adequate space around all sides of the UPS for proper ventilation.

• Only set the UPS upright on a sturdy ﬂat surface. Do not block fans or ventilation holes, as this will seriously inhibit the unit's

internal cooling and cause product damage not covered under warranty.

UPS Connection Warnings

• Connect your UPS directly to a properly grounded AC power outlet. Do not plug the UPS into itself; this will damage the UPS.

• Do not modify the UPS’s plug, and do not use an adapter that would eliminate the UPS’s ground connection.

• Do not use extension cords to connect the UPS to an AC outlet.

• If the UPS receives power from a motor-powered AC generator, the generator must provide clean, ﬁltered, computer-grade

output.

• The mains socket outlet that supplies the UPS should be easily accessible and located near the UPS.

Equipment Connection Warnings

• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the

failure of the life support equipment or to signiﬁcantly affect its safety or effectiveness is not recommended. Do not use this

equipment in the presence of a ﬂammable anesthetic mixture with air, oxygen or nitrous oxide.

• Do not connect surge suppressors or extension cords to the output of your UPS. This might damage the UPS and may affect

the surge suppressor and UPS warranties.

• Connect the UPS to an outlet that is adequately protected against excess currents, short circuits and earth faults as part of

the building installation.

WARNING: This is a category C2 UPS product. In a residential environment, this product may cause radio interference,

in which case, the user may be required to take additional measures.

Battery Warnings

• Batteries can present a risk of electrical shock and burn from high short-circuit current. Observe proper precautions. Do not

dispose of the batteries in a ﬁre. Do not open the UPS or batteries. Do not short or bridge the battery terminals with any

object. Unplug and turn off the UPS before performing battery replacement. Use tools with insulated handles. There are

no user-serviceable parts inside the UPS. Battery replacement should be performed only by authorized service personnel

using the same number and type of batteries (Sealed Lead-Acid). The batteries are recyclable. Refer to your local codes for

disposal requirements or visit http://www.tripplite.com/support/recycling-program for recycling information. Tripp Lite

offers a complete line of UPS System Replacement Battery Cartridges (R.B.C.).Visit Tripp Lite on the Web at

http://www.tripplite.com/products/battery-ﬁnder/ to locate the speciﬁc replacement battery for your UPS.

Important Safety Instructions

15-02-071-9332B0.indb 2 2/18/2015 10:17:50 AM

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SMX1500LCDT
Vekt:	11200 g
Bredde:	146 mm
Dybde:	393.7 mm
Høyde:	203.2 mm
LED-indikatorer:	Ja
Opprinnelsesland:	China
Pakkevekt:	12340 g
Utgangseffekt:	900 W
Utgangsspenning (maks.):	240 V
Effektivitet:	95
Inngangsspenning (maks.):	230 V
Kabellengde:	1.8 m
Produktfarge:	Sort
Pakkedybde:	490.2 mm
Pakkehøyde:	287 mm
Pakkebredde:	231.1 mm
Skjermtype:	LCD
Batterispenning:	12 V
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
Formfaktor:	Kompakt
Inngangsfrekvens:	- Hz
Overspenningsvern:	Ja
Form for nedkjøling:	Aktiv
Antall AC outlets:	8 AC-utganger
Masterkassens (ytterkassens) bruttovekt:	12340 g
Masterkassens (ytterkassens) lengde:	490.2 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	231.1 mm
Masterkassens (ytterkassens) høyde:	287 mm
Strøm (maks.):	10 A
AC-utgangstyper:	C13 kopling
Strømuttak:	C14 kopling
Strømstøt energivurdering:	455 J
Output strømkapasitet (VA):	1.5 kVA
Inngangsspenning (min.):	230 V
Utgangsspenning (min.):	220 V
Normal backuptid ved halv belastning:	10 min
Normal backuptid ved full belastning:	- min
Hot-swap-batterier:	Ja
