Tripp Lite SU1000XLCD Bruksanvisning

Tripp Lite uforstyrret strømtilførsel (UPS) SU1000XLCD

Les nedenfor 📖 manual på norsk for Tripp Lite SU1000XLCD (52 sider) i kategorien uforstyrret strømtilførsel (UPS). Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/52

p/n: 614-21326

Revision 01

SU700XLCD

SU1000XLCD

SU2200XLCD

SU3000XLCD

BP36V

BP48V

BP96V

SU1500XLCD

Tower Advanced Users Guide

Eaton Tripp Lite SmartOnline Series

express written approval of Eaton.

SSaaffeettyy IInnssttrruuccttiioonnss

SAVE THESE INSTRUCTIONS. This manual contains important instructions that should be

followed during installation and maintenance of the UPS and batteries.

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

This is a category C2 UPS product. In a residential environment, this product may cause radio

interference, in which case the user may be required to take additional measures.

Supplier's Declaration of Conformity of Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. this device may not cause harmful interference, and

2. this device must accept any interference received, including interference that may cause

undesired operation.

For questions regarding this FCC SDoC declaration, contact Eaton Corporation by telephone or

through the Internet.

Eaton Corporation 8609 Six Forks Road,

Raleigh, NC 27615, USA

Telephone: 800-356-5794

SSppeecciiaall SSyymmbboollss

The following are examples of symbols used on the product to alert you to important information:

RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of

electric shock symbol.

CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's

manual for additional information, such as important operating and maintenance

instructions.

This symbol indicates that you should not discard the UPS or the UPS batteries in

the trash. This product contains sealed lead acid batteries and must be disposed

of properly. For more information, contact your local recycling/reuse or hazardous

waste center.

Special Symbols

The following are examples of symbols used on the UPS or accessories to alert you to important

information:

RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of

electric shock symbol.

CAUTION: REFER TO OPERATOR'S MANUAL - Refer to your operator's manual for

additional information, such as important operating and maintenance

instructions.

This symbol indicates that you should not discard the UPS or the UPS batteries

in the trash. This product contains sealed, lead‐acid batteries and must be

disposed of properly. For more information, contact your local recycling/reuse or

hazardous waste center.

This symbol indicates that you should not discard waste electrical or electronic

equipment (WEEE) in the trash. For proper disposal, contact your local

recycling/reuse or hazardous waste center.

Eaton, Powerware, and BladeUPS are registered trademarks of Eaton Corporation or its subsidiaries and affiliates.

Phillips and Pozidriv are registered trademarks of Phillips Screw Company.

reproduced in any way without the express written approval of Eaton Corporation.

This symbol indicates that waste electrical and electronic equipment as well as

waste batteries and accumulators should not be discarded together with

unseparated household waste, but must be collected separately. The product

should be handed in for recycling in accordance with the local environmental

regulations for waste disposal. By separating waste electrical and electronic

equipment as well as waste batteries and accumulators, you will help reduce the

volume of waste sent for incineration or land-fills and minimize any potential

negative impact on human health and environment.

SSaaffeettyy ooff PPeerrssoonnss

• The system has its own power source (the battery). Consequently, the power outlets may be

energized ven if the systems is disconnected from the AC power source. Dangerous voltage

levels are resent within the system. It should be opened exclusively by qualified service

personnel.

• The system must be properly grounded at all times.

• The battery supplied with the system contains small amounts of toxic materials. To avoid

accidents, the directives listed below must be observed:

– Servicing of batteries should be performed or supervised by personnel knowledgeable about

batteries and the required precautions.

– When replacing batteries, replace with the same type and number of batteries or battery

packs.

– Do not dispose of batteries in a fire. The batteries may explode.

– Batteries constitute a danger (electrical shock, burns). The short-circuit current may be very

high.

• Precautions must be taken for all handling:

– Wear rubber gloves and boots.

– Do not lay tools or metal parts on top of batteries.

– Disconnect charging source prior to connecting or disconnecting battery terminals.

– Determine if battery is inadvertently grounded. If inadvertently grounded, remove source

from ground. Contact with any part of a grounded battery can result in electrical shock. The

likelihood of such shock can be reduced if such grounds are removed during installation and

maintenance (applicable to equipment and remote battery supplies not having a grounded

supply circuit).

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SU1000XLCD
Vekt:	13020 g
Bredde:	172.7 mm
Dybde:	337.8 mm
Høyde:	254 mm
Støynivå:	50 dB
LED-indikatorer:	Ja
Innebygd vifte:	Ja
Opprinnelsesland:	China
Pakkevekt:	15200 g
Antall USB 2.0-porter:	1
Sertifisering:	UL1778 , CSA, NOM, FCC
Utgangseffekt:	900 W
Utgangsspenning (maks.):	127 V
Effektivitet:	93
UPS topologi:	Dobbeltkonvertering (Online)
Bølgeform:	Sinus
Automatisk batteritest:	Ja
Inngangsspenning (maks.):	127 V
Kabellengde:	3 m
Produktfarge:	Sort
Pakkedybde:	457.2 mm
Pakkehøyde:	353.1 mm
Pakkebredde:	248.9 mm
Skjermtype:	LED
RS-232-port:	1
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Bærekraftsertifikater:	RoHS
Formfaktor:	Tower
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Stål
Strømbeskyttelsesfunksjoner:	Over voltage, Under voltage
Relativ luftfuktighet under drift (H-H):	0 - 95
Form for nedkjøling:	Aktiv
Antall AC outlets:	6 AC-utganger
Masterkassens (ytterkassens) bruttovekt:	15200 g
Masterkassens (ytterkassens) lengde:	457.2 mm
Produkter per masterkasse (ytterkasse):	1 stykker
Masterkassens (ytterkassens) bredde:	248.9 mm
Masterkassens (ytterkassens) høyde:	353.1 mm
Hørbare alarmer:	Ja
AC-utgangstyper:	NEMA 5–15R
Strømuttak:	NEMA 5-15P
Strømstøt energivurdering:	570 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	1 kVA
Inngangsspenning (min.):	100 V
Utgangsspenning (min.):	100 V
Nødstrøm av (EPO):	Ja
Normal backuptid ved halv belastning:	15 min
Normal backuptid ved full belastning:	4.8 min
Kald oppstart:	Ja
Crest-faktor:	3:1
Hot-swap-batterier:	Ja
Utgangsstrømfaktor:	0.9
Output spenningsforskrift:	4
