Owner’s Manual

SmartOnline

Single-Phase Rack-Mount Online UPS

with Built-in LCD Monitoring & Control Screen

Not suitable for mobile applications.

1. Overview 2

Parts List 2

Additional Accessory Options 2

2. Important Safety Instructions 2

3. UPS Circuit Block Diagram 5

4. Installation 6

Internal Battery Rotation 6

Rack Mounting 8

Tower Mounting 9

Hardwire Input and Output 10

Wiring Instructions

(Optional with Select Models)

UPS Input and Output Overview 11

5. Features 11

Front Panel Controls, LEDs and 11

LCD Screen

Rear Panel Features 12

6. Operations 14

LCD Front Panel Display and Controls 14

LED Front Panel Indicators 14

Front Panel Button Functions 15

Home Screen Layout 15

Basic Connection and Start-Up 16

Power Strategy Selection Options 19

Front Panel LCD Selection and 21

Configuration Options

Configuring External Battery Packs 24

7. Optional Connections 25

8. Troubleshooting and Event Log 28

9. Internal Battery Replacement 30

10. Fan Replacement 32

11. Storage and Service 33

12. Warranty and Product Registration 33

Español 35

Français 69

Русский

103

NOTE: External battery pack options require conﬁguration using front panel LCD interface or via Tripp Lite’s EXTERNAL BATTERY CONFIGURATION software.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

is a trademark of Tripp Lite. For latest updates, please visit tripplite.com

WARRANTY REGISTRATION

automatically entered to win an ISOBAR

surge protector in our monthly drawing!

tripplite.com/warranty

Important Safety Instructions

Overview

SAVE THESE INSTRUCTIONS

This manual contains important instructions and warnings that should be followed during the installation, operation, maintenance and

storage of all Tripp Lite UPS Systems and Batteries. Failure to heed these warnings may affect your warranty.

Explanation of Symbols

Caution—risk of danger

Hot—overheating may occur

Electrical shock hazard

Protective earth ground

Bonding ground

Recyclable—contains lead

Tripp Lite SmartOnline rack-mount UPS systems with interactive LCD interface feature on-line, double-conversion UPS protection with full-

time sinewave output and zero transfer time, making them suitable for all advanced networking applications. Each UPS provides long

running battery support with optional extended-run and Web communications ability. Built-in interfaces include Micro-USB, RS-232 serial,

Emergency Power Off (EPO), Remote On/Off (ROO) and an RJ-11 smart battery port. The interactive front panel LCD screen provides

detailed UPS status, preset and control options. Optional max efficiency and auto-adaptive power strategy options enable high-efficiency

operation with reduced power consumption and BTU heat output.

Parts List

UPS System Bolt-on Mounting Ears (2) 4-Post Rail Kit Hardwire Strain Reliefs (2)

USB Cable (1) RS-232 Cable (1) (Select models) AC Input Power

Cord with L6-30P Plug (1)

Owner’s Manual

Optional Accessories (Not Included)

• 2POSTRMKITWM: Supports rack-mount UPS and battery packs in 2-post rack-mount or wall-mount configurations

• 2-9USTAND: Supports rack-mount UPS and battery packs in upright tower configuration

• BP192V12RT3US External “SMART” Battery Pack: Extends the runtime of the UPS system

Produkspesifikasjoner

Merke:	Tripp Lite
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	SU5KRT3UHW
Vekt:	52340 g
Bredde:	444.5 mm
Dybde:	726.2 mm
Høyde:	130.6 mm
Støynivå:	67.1 dB
LED-indikatorer:	Ja
Bruksanvisning:	Ja
USB-port:	Ja
Innebygd vifte:	Ja
Opprinnelsesland:	Taiwan
Pakkevekt:	72260 g
Antall USB 2.0-porter:	1
Utgangseffekt:	5000 W
Utgangsspenning (maks.):	240 V
Batteriteknologi:	Forseglet blysyre (VRLA)
UPS topologi:	Dobbeltkonvertering (Online)
Antall inngangsfaser:	1
Utgangsfrekvens:	50/60 Hz
Bølgeform:	Ren sinus
Inngangsspenning (maks.):	240 V
Produktfarge:	Sort
Pakkedybde:	847.1 mm
Pakkehøyde:	175 mm
Pakkebredde:	602 mm
Skjermtype:	LCD
Kabler inkludert:	RS-232, USB cable
RS-232-port:	1
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 50 °C
Lagringsrelativ fuktighet:	5 - 95
Formfaktor:	Rackmontering/tårn
Inngangsfrekvens:	50/60 Hz
Kroppsmateriale:	Metall
Driftshøyde:	0 - 2000 m
Rack-kapasitet:	3U
Relativ luftfuktighet under drift (H-H):	5 - 95
Form for nedkjøling:	Aktiv
Produkter per masterkasse (ytterkasse):	1 stykker
Hørbare alarmer:	Ja
AC-utgangstyper:	Hardwire
Strømuttak:	Hardwire
Rack-montert sett:	Ja
Strømstøt energivurdering:	1680 J
EMI/RFI-lydfiltrering:	Ja
Output strømkapasitet (VA):	5 kVA
Inngangsspenning (min.):	200 V
Utgangsspenning (min.):	200 V
Modem (RJ-11)-porter:	1
Normal backuptid ved halv belastning:	14 min
Normal backuptid ved full belastning:	5 min
Kald oppstart:	Ja
USB port type:	Micro-USB
Inngangsstrømfaktor:	0.98
Crest-faktor:	3:1
Nød Kraft Av kontakt (EPO) (Emergency Power Off):	Ja
Hot-swap-batterier:	Ja
Utgangsstrømfaktor:	1
