Side 1/2

EN | Instruction Manual

WWW

• This appliance shall not be used by

children aged less than 8 years. This

appliance can be used by children

from 8 years and above and persons

with reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if they

have been given supervision or

instruction concerning use of the

appliance in a safe way and

understand the hazards involved.

Children shall not play with the

appliance. Keep the appliance and

its cord out of reach of children aged

less than 8 years. Cleaning and user

maintenance shall not be made by

children unless older than 8 and

is supervised.

• By ignoring the safety instructions,

the manufacturer cannot be held

responsible for the damage.

• If the supply cord is damaged, it must

be replaced by the manufacturer, its

service agent or similarly qualied

persons in order to avoid a hazard.

• Never move the appliance by pulling

the cord and make sure the cord

cannot become entangled.

• The appliance must be placed on a

stable, level surface.

• The user must not leave the device

unattended while it is connected to

the supply.

• This appliance is only to be used for

household purposes and only for the

purpose it is made for.

• To protect yourself against an electric

shock, do not immerse the cord, plug

or appliance in the water or any other

liquid.

CONTROLS

1. Oscillation knob

2. Head adjustment screw

3. Speed adjustment buttons

ASSEMBLY

• Fit the base by pushing it into place on

the underside of the fan and secure in

place by using the screws provided.

• Unscrew the rear locking ring from the

motor shaft in anti-clockwise direction.

• Set the rear cage and t it well on the

two position holes and make sure

these holes are properly put through

the holes on the rear cage.

• Hold the rear cage and screw the rear

locking ring into the motor front cover

in a clockwise direction.

• Install the fan blade onto motor shaft

and t the fan blade lock cap.

• Loosen the screw and nut on the

bottom of the rear cage.

• Open front cage clips and position

onto rear cage ensuring the screw at

bottom is aligned between both.

• Tighten screw and nut.

• Close the cage clips over both front

and rear cage.

VE-5834UK / VE-5835UK

CONTROLS

ASSEMBLY

SAFETY

Produkspesifikasjoner

Merke:	Tristar
Kategori:	husholdningsvifte
Modell:	VE-5834UK
Vekt:	1200 g
Håndtak:	Ja
Støynivå:	50.52 dB
Plassering:	Bord
Strømkildetype:	AC
Pakkevekt:	1450 g
Luftstrøm:	1392.6 m³/t
Produkter per pall:	128 stykker
AC-inngangsspenning:	240 V
Produkter per intermodal container (20 fot):	1638 stykker
Produkter per intermodal container (40 fot):	3248 stykker
Antall vifteblader:	3
Viftehastighet (maks.):	2400 RPM
Høydejustering:	Nei
Produktfarge:	Hvit
Pakkedybde:	195 mm
Pakkehøyde:	290 mm
Pakkebredde:	280 mm
Produkter per intermodal container (40 fot, HC):	3712 stykker
Kontrolltype:	Knapper
Overopphetingsbeskyttelse:	Ja
Pakketype:	Boks
Strømforbruk (vanlig bruk):	30 W
vippevinkel:	25 °
Modell/Type:	Husholdningsvifte
Kroppsmateriale:	Plast
Internasjonal beskyttelses (IP)-kode:	IP00
Av/på-bryter:	Ja
Vippjustering:	Ja
Antall hastighetsnivåer:	2
Viftediameter:	230 mm
Automatisk oscillerende:	Ja
Oscilleringsområde:	85 °
Masterkassens (ytterkassens) bruttovekt:	3200 g
Masterkassens (ytterkassens) lengde:	290 mm
Produkter per masterkasse (ytterkasse):	2 stykker
Masterkassens (ytterkassens) bredde:	405 mm
Masterkassens (ytterkassens) høyde:	300 mm
Beskyttelses grid:	Ja
