EN | Instruction Manual

WWW

• This appliance shall not be used by

children aged less than 8 years. This

appliance can be used by children

from 8 years and above and persons

with reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if they

have been given supervision or

instruction concerning use of the

appliance in a safe way and

understand the hazards involved.

Children shall not play with the

appliance. Keep the appliance and

its cord out of reach of children aged

less than 8 years. Cleaning and user

maintenance shall not be made by

children unless older than 8 and

is supervised.

• By ignoring the safety instructions,

the manufacturer cannot be held

responsible for the damage.

• If the supply cord is damaged, it must

be replaced by the manufacturer, its

service agent or similarly qualied

persons in order to avoid a hazard.

• Never move the appliance by pulling

the cord and make sure the cord

cannot become entangled.

• The appliance must be placed on a

stable, level surface.

• The user must not leave the device

unattended while it is connected to

the supply.

• This appliance is only to be used for

household purposes and only for the

purpose it is made for.

• To protect yourself against an electric

shock, do not immerse the cord, plug

or appliance in the water or any other

liquid.

CONTROLS

1. Oscillation knob

2. Head adjustment screw

3. Speed adjustment buttons

ASSEMBLY

• Fit the base by pushing it into place on

the underside of the fan and secure in

place by using the screws provided.

• Unscrew the rear locking ring from the

motor shaft in anti-clockwise direction.

• Set the rear cage and t it well on the

two position holes and make sure

these holes are properly put through

the holes on the rear cage.

• Hold the rear cage and screw the rear

locking ring into the motor front cover

in a clockwise direction.

• Install the fan blade onto motor shaft

and t the fan blade lock cap.

• Loosen the screw and nut on the

bottom of the rear cage.

• Open front cage clips and position

onto rear cage ensuring the screw at

bottom is aligned between both.

• Tighten screw and nut.

• Close the cage clips over both front

and rear cage.

VE-5834UK / VE-5835UK

CONTROLS

ASSEMBLY

SAFETY

• This appliance shall not be used by

children aged less than 8 years. This

appliance can be used by children

from 8 years and above and persons

with reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if they

have been given supervision or

instruction concerning use of the

appliance in a safe way and

understand the hazards involved.

Children shall not play with the

appliance. Keep the appliance and

its cord out of reach of children aged

less than 8 years. Cleaning and user

maintenance shall not be made by

children unless older than 8 and

is supervised.

• By ignoring the safety instructions,

the manufacturer cannot be held

responsible for the damage.

• If the supply cord is damaged, it must

be replaced by the manufacturer, its

service agent or similarly qualied

persons in order to avoid a hazard.

• Never move the appliance by pulling

the cord and make sure the cord

cannot become entangled.

• The appliance must be placed on a

stable, level surface.

• The user must not leave the device

unattended while it is connected to

the supply.

• This appliance is only to be used for

household purposes and only for the

purpose it is made for.

• To protect yourself against an electric

shock, do not immerse the cord, plug

or appliance in the water or any other

liquid.

CONTROLS

1. Oscillation knob

2. Head adjustment screw

3. Speed adjustment buttons

ASSEMBLY

• Fit the base by pushing it into place on

the underside of the fan and secure in

place by using the screws provided.

• Unscrew the rear locking ring from the

motor shaft in anti-clockwise direction.

• Set the rear cage and t it well on the

two position holes and make sure

these holes are properly put through

the holes on the rear cage.

• Hold the rear cage and screw the rear

locking ring into the motor front cover

in a clockwise direction.

• Install the fan blade onto motor shaft

and t the fan blade lock cap.

• Loosen the screw and nut on the

bottom of the rear cage.

• Open front cage clips and position

onto rear cage ensuring the screw at

bottom is aligned between both.

• Tighten screw and nut.

• Close the cage clips over both front

and rear cage.

VE-5834UK / VE-5835UK

Tristar Europe B.V. | Jules Verneweg 87 |

5015 BH Tilburg | The Netherlands

BEFORE THE FIRST USE

• Take the appliance and accessories

out of the box. Remove the stickers,

protective foil or plastic from the

device.

• Follow the assembly diagram to

assemble the product.

• Place the device on a at stable surface

and ensure a minimum of 10cm free

space around the device. This device

is not suitable for installation in a

cabinet or for outside use.

• Put the power cable into the socket.

(Note: Make sure the voltage which is

indicated on the device matches the

local voltage before connected the

device. Voltage 220V-240V 50/60Hz).

USE

• Set the speed adjustment buttons to

the desired position.

• To make the fan head oscillate, push

down the oscillation knob.

• To stop the fan head from oscillating,

pull up the oscillation knob.

• The head of the fan can be adjusted up

or down. To do this, loosen the head

adjustment screw, adjust the fan to the

desired angle and tighten the head

adjustment screw.

CLEANING AND MAINTENANCE

• Clean the appliance with a damp cloth.

Never use harsh and abrasive cleaners,

scouring pads or steel wool which can

damage the device.

• Never immerse the electrical device in

water or any other liquid. The device is

not dishwasher proof.

GUARANTEE

This product is provided with a 24

months guarantee. Your guarantee is

valid if the product is used in accordance

to the instructions and for the purpose for

which it was created. In addition, the

original purchase (invoice, sales slip or

receipt) needs to be retained and to be

submitted on request with the date of

purchase, the name of the retailer and

the item number of the product. The

guarantee does not cover damage

caused by:

• Accident or unanticipated events (e.g.

lightning, water, re).

• Improper use or transport.

• Disregard of safety and maintenance

instructions.

• Other improper treatment or

modication.

ENVIRONMENT

This appliance should not be put into

the domestic garbage at the end of its

durability but must be oered at a

central point for the recycling of electric

and electronic domestic appliances. This

symbol on the appliance, instruction

manual and packaging directs your

attention to this important issue. The

materials used in this appliance can be

recycled. By recycling used domestic

appliances, you contribute an important

push to the protection of our

environment. Ask your local authorities

regarding the point of recollection.

SUPPORT

You can nd all available information

and spare parts at www.tristar.eu

EN | Instruction manual

Produkspesifikasjoner

Merke:	Tristar
Kategori:	husholdningsvifte
Modell:	VE-5835UK
Vekt:	1700 g
Håndtak:	Ja
Støynivå:	49.36 dB
Plassering:	Tak
Strømkildetype:	AC
Pakkevekt:	2100 g
Luftstrøm:	2414.4 m³/t
Produkter per pall:	72 stykker
AC-inngangsspenning:	230 V
Produkter per intermodal container (20 fot):	1104 stykker
Produkter per intermodal container (40 fot):	2280 stykker
Antall vifteblader:	3
Viftehastighet (maks.):	1300 RPM
Kabellengde:	1.6 m
Høydejustering:	Nei
Produktfarge:	Hvit
Pakkedybde:	195 mm
Pakkehøyde:	350 mm
Pakkebredde:	345 mm
Produkter per intermodal container (40 fot, HC):	2660 stykker
Kontrolltype:	Knapper
Overopphetingsbeskyttelse:	Ja
Pakketype:	Boks
Strømforbruk (vanlig bruk):	40 W
vippevinkel:	25 °
Modell/Type:	Husholdningsvifte
Kroppsmateriale:	Plast
Internasjonal beskyttelses (IP)-kode:	IP00
Av/på-bryter:	Ja
Vippjustering:	Ja
Antall hastighetsnivåer:	3
Viftediameter:	300 mm
Automatisk oscillerende:	Ja
Oscilleringsområde:	85 °
Masterkassens (ytterkassens) bruttovekt:	4600 g
Masterkassens (ytterkassens) lengde:	400 mm
Produkter per masterkasse (ytterkasse):	2 stykker
Masterkassens (ytterkassens) bredde:	355 mm
Masterkassens (ytterkassens) høyde:	360 mm
Beskyttelses grid:	Ja
