Side 1/2

EN | Instruction Manual

WWW

• This appliance shall not be used by

children aged less than 8 years. This

appliance can be used by children

from 8 years and above and persons

with reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if they

have been given supervision or

instruction concerning use of the

appliance in a safe way and

understand the hazards involved.

Children shall not play with the

appliance. Keep the appliance and

its cord out of reach of children aged

less than 8 years. Cleaning and user

maintenance shall not be made by

children unless older than 8 and

is supervised.

• By ignoring the safety instructions,

the manufacturer cannot be held

responsible for the damage.

• If the supply cord is damaged, it must

be replaced by the manufacturer, its

service agent or similarly qualied

persons in order to avoid a hazard.

• Never move the appliance by pulling

the cord and make sure the cord

cannot become entangled.

• The appliance must be placed on a

stable, level surface.

• The user must not leave the device

unattended while it is connected to

the supply.

• This appliance is only to be used for

household purposes and only for the

purpose it is made for.

• To protect yourself against an electric

shock, do not immerse the cord, plug

or appliance in the water or any other

liquid.

CONTROLS

1. Speed adjustment knobs

2. Timer knob

3. Fan

4. Base

ASSEMBLY

• Snap the two base halves together by

sliding the posts of one base half into

the slots of the second base half.

• Pull the power cord through the

centre hole of the assembled base.

• Use screws provided to attach the

assembled base to the pedestal.

Secure the screws with a screwdriver.

Turn the fan right side up and place on a

dry and level surface before operating.

VE-5837UK

CONTROLS

ASSEMBLY

SAFETY

Screws

Fig 1

Fig 2

Fig 3

Produkspesifikasjoner

Merke:	Tristar
Kategori:	husholdningsvifte
Modell:	VE-5837UK
Timer:	Ja
Vekt:	1700 g
Høyde:	730 mm
Håndtak:	Ja
Støynivå:	54 dB
Plassering:	Gulv
Strømkildetype:	AC
Pakkevekt:	2080 g
Luftstrøm:	810 m³/t
Produkter per pall:	126 stykker
AC-inngangsspenning:	230 V
Produkter per intermodal container (20 fot):	1314 stykker
Produkter per intermodal container (40 fot):	3000 stykker
Viftehastighet (maks.):	2200 RPM
Kabellengde:	1.6 m
Høydejustering:	Nei
Produktfarge:	Hvit
Pakkedybde:	130 mm
Pakkehøyde:	750 mm
Pakkebredde:	170 mm
Produkter per intermodal container (40 fot, HC):	3714 stykker
Kontrolltype:	Rotasjon
Overopphetingsbeskyttelse:	Ja
Pakketype:	Boks
Strømforbruk (vanlig bruk):	30 W
Modell/Type:	Husholdningstårnvifte
Kroppsmateriale:	Plast
Internasjonal beskyttelses (IP)-kode:	IP00
Av/på-bryter:	Ja
Antall hastighetsnivåer:	3
Viftediameter:	220 mm
Automatisk oscillerende:	Ja
Oscilleringsområde:	75 °
Masterkassens (ytterkassens) bruttovekt:	4250 g
Masterkassens (ytterkassens) lengde:	130 mm
Produkter per masterkasse (ytterkasse):	2 stykker
Masterkassens (ytterkassens) bredde:	360 mm
Masterkassens (ytterkassens) høyde:	765 mm
