Installation instructions
Induction hob
GK11TIXFKZ | CTI6T75FKTFHD
1064512-05
25/11/2020
1064512-05
1
The appliance should be installed by qualified personnel only. Each step must be carried out and checked in full in
the order specified.
Validity
These installation instructions apply to the following models:
Model designation Model number Type Frameless,
for surface-mounted installa-
tion
Frameless,
for flush installation
GK11TIXFK FullFlex 31093 GK11TIXFKZ GK11TIXFKZ GK11TIXFKZ
CookTopInduction V6000 FullFlex
CookTop V6000 I705 FullFlex
31132 CTI6T-31132 CTI6T75FKTFHD CTI6T75FKTFHD
General notes
If installing into a combustible material, the guidelines and standards for low-voltage installations and fire protection
must be strictly observed.
Identification plate
1
1 Identification plate with serial number (SN)
▸ Affix the second identification plate (supplied) in an accessible position behind the front of the fitted cabinet beneath the appliance.
Installation accessories supplied
Flush installation:
Designation Art. no.
Cementing-in instructions J004133
Sealing strip set H63283
Spacer set H60330
Accessories
Flush installation:
Designation Art. no.
Ventilation protective plate set for niche width 600mm H61083
Ventilation protective plate set for niche width 825mm H61084
Ventilation protective plate set for niche width 900mm H61085
Steel angle set, installation dimension 70 H63773
Intermediate support kit for the flush-mounted combination of several hobs (contains two intermediate supports) H63789
Instant adhesive for installation of the steel angle (50ml) B11657
Straight mixing nozzle B11656
TREMCLEAN isopropyl alcohol (1000ml) 1056609
Black silicone FA880 (310ml) B11555
Anthracite silicone FA880 (310ml) B11556
White silicone FA880 (310ml) 1031313
Stone grey silicone FA880 (310ml) 1031314
Marble smoothing agent AA320 (1000ml) B11557
Fugenboy (silicone finishing tool) B75158
Installation instructions
Induction hob
GK11TIXFKZ | CTI6T75FKTFHD
1064512-05
25/11/2020
1064512-05
2
Ventilation
A protective plate with seal must be installed with models 31093 and 31132.
In order to guarantee good ventilation, a space of ≥10mm
height is necessary beneath the appliance.
1. The rear panel of the base unit must be open around the
work surface cut-out to guarantee continuous air circula-
tion through the ventilation slits.
The air must be drawn in from outside the cabinet and be
able to circulate freely from inside the cabinet to the hob.
2. Alternatively, a concealed fresh air supply can ensure air
circulation inside the cabinet.
In order that enough cold air can be drawn in, there must
be a continuous circulation of fresh air that extends outside
the cabinet.
The air must be drawn in from outside the cabinet and be
able to circulate freely from inside the cabinet to the hob.
≥15
21
≥3
Installation instructions
Induction hob
GK11TIXFKZ | CTI6T75FKTFHD
1064512-05
25/11/2020
1064512-05
3
Electrical connection
Electrical connections must be carried out by qualified personnel in accordance with the guidelines and standards
for low-voltage installations and the specifications of the local electricity supply companies.
Refer to the identification plate for information on the required mains voltage and current type.
A plug-in appliance may only be connected to a socket outlet with earthing contact, installed according to specifications. An
all-pole mains isolating device with 3 mm contact opening should be provided in the house wiring system. Switches, plug and
socket devices, circuit breakers and fusible cut-outs which are accessible after installation and which have all-poles switching
are permissible as isolating devices. Effective earthing and separately installed neutral and earth conductors ensure safe and
fault-free operation. After installation, live parts and cables with basic insulation must not be accessible. Check old installa-
tions.
▸ If the hobs are used at an altitude of over 2,000metres,a reduced performance must be expected.
The appliance is equipped with a connection cable which must be connected to an on-site junction box.
Installation pipe Distribution boxClamp
brown
blue
yellow/green
blue
yellow/green
brown
L1
N
N
L1
PE/
PE/
black
L2
400 V 2N~ / 16 A
230 V~ / 32 A
3109300.../3109360.../3109366...
3113200001–3113200003
3109361.../3109365.../3109367...
3113200004
E35/U0 error message
Incorrect connection:
Pole conductor connected to connection terminal for neutral conductor.
Quickly disconnect the appliance from the mains!
General information about installation
The distance from the appliance cut-out to flammable walls (left, right and rear) must be ≥50mm. Parts such as side
walls and reinforcing strips which protrude into the installation space under the cooking zone must be made of non-
combustible materials.
It is recommended that a distance of 20mm be maintained between the underside of the appliance tray and any part
of the cabinet beneath that is made of combustible material. If a drawer is installed directly underneath – and if the
tray can be reached from below without the aid of tools – touch protection must be used. The ventilation protective
plate set (see Accessories) is recommended for this purpose.
▪ The worktop must be flat so that it is sufficiently sealed against the ingress of liquids.
▪ In order to guarantee good ventilation, a space of at least 10mm in height is necessary beneath the appliance.
