Operating instructions

DFN 5/6

Range hood

Thank you for choosing to buy one of our products. Your appliance is made to

high standards and is easy to use. Nevertheless, please take the time to read

these operating instructions in order to familiarise yourself with the appliance

and get the best use out of it.

Please follow the safety precautions.

Modifications

Text, diagrams and data correspond to the technical standard of the appliance

at the time these operating instructions went to press. The right to make tech-

nical modifications for the purpose of the further development of the appliance

is reserved.

Validity

The product family (model number) corresponds to the first alphanumerics on

the identification plate. These operating instructions apply to:

Type Product family Size system

DFN5 61026 55

DFN6 61027 60

Variations depending on the model are noted in the text.

Inhaltsverzeichnis

2

1 Safety precautions 5

1.1 Symbols used ........................................................................................................ 5

1.2 General safety precautions ................................................................................. 6

1.3 Before using for the first time ............................................................................. 7

1.4 Correct use............................................................................................................. 7

1.5 Children in the home............................................................................................ 7

1.6 Note on use ........................................................................................................... 8

2 Disposal 10

3 Appliance description 11

3.1 Appliance description ........................................................................................11

3.2 Extraction mode ..................................................................................................11

3.3 Recirculation mode.............................................................................................11

3.4 Features ................................................................................................................11

3.5 Construction.........................................................................................................12

3.6 Operating elements ............................................................................................12

4 Operating the appliance 13

4.1 Switching the appliance on...............................................................................13

4.2 Extractor fan.........................................................................................................13

4.3 Illumination ...........................................................................................................13

4.4 Switching the appliance off...............................................................................14

5 Care and maintenance 15

5.1 Cleaning the housing .........................................................................................15

5.2 Metal grease filters .............................................................................................15

5.3 Long-life activated charcoal filter .....................................................................16

5.4 Standard activated charcoal filter ....................................................................18

5.5 Replacing the LED light bulbs..........................................................................19

6 Trouble-shooting 20

6.1 What to do if…......................................................................................................20

7 Accessories and spare parts 21

8 Technical data 22

8.1 Product fiche........................................................................................................22

9 Index 24

10 Notes 25

11 Service & Support 27

Produkspesifikasjoner

Merke:	V-Zug
Kategori:	eksoshette
Modell:	DFN6c
Innebygd skjerm:	Nei
Vekt:	12500 g
Bredde:	598 mm
Dybde:	302 mm
Høyde:	396 mm
Årlig energiforbruk:	40 kWh
Støynivå:	67 dB
Antall motorer:	1
Støynivå (lav hastighet):	46 dB
Type fettfilter:	Fleece
Vaskbart filter:	Ja
Antall filtre:	2 stykker
AC-inngangsspenning:	220-240 V
AC-inngangsfrekvens:	50 - 60 Hz
Kabellengde:	1.5 m
Produktfarge:	Kromfarget
Kontrolltype:	Knapper
Modell/Type:	Semi-innebygd (uttrekkbar)
Antall pærer:	2 ampuller
Strøm:	10 A
Belysning:	54 lx
Tilkoblet nettbelastning:	206 W
Avtagbart filter:	Ja
Type utvinning:	Ducted/Resirkulerende
Motoreffekt:	200 W
Maksimal utvinningskraft:	647 m³/t
Intensiv hastighet:	Nei
Filter til oppvaskmaskin:	Ja
Dybde installasjonskammer:	305 mm
Bredde installasjonskammer:	600 mm
Lyspæretype:	LED
Lampestyrke:	6 W
Fluid dynamisk effektivitet klasse:	A
Belysning efiktivitets klasse:	E
Fettfiltrering effektivitetsklasse:	D
Støynivå (høy hastighet):	67 dB
Trykk (T):	434
Diameter på avtrekkstilkobling:	150 mm
Avgassplassering:	Topp
Minimum avstand fra gas-komfyr:	750 mm
Minimum avstand fra elektrisk-komfyr:	430 mm
Maksimum resirkulasjonskraft:	490 m³/t
Kontrollventil:	Ja
