Range hood

DW-SE/DI-SE

Operating instructions

V-ZUG Ltd

Thank you for choosing to buy one of our products. Your appliance is made

to high standards and is easy to use. Nevertheless, please take the time to

read these operating instructions in order to familiarize yourself with the

appliance and get the best use out of it.

Please follow the safety precautions.

Modifications

Text, diagrams and data correspond to the technical standard of the appli-

ance at the time these operating instructions went to press. The right to make

technical modifications for the purpose of the further development of the

appliance is reserved.

Symbols used

A Indicates step-by-step instructions.

– Describes how the appliance reacts to the steps taken.

䡲 Indicates a list.

Validity

The model number corresponds to the first 3 digits on the identification plate.

These operating instructions apply to the models:

Variations depending on the model are noted in the text.

Denotes important safety precautions. Failure to observe said pre-

cautions can result in injury or damage to the appliance or fittings!

Denotes useful tips for the user.

Type Model no. Size system Type Model no. Size system

DW-SE6 048 60 DI-SE10 076 100

DW-SE7 054 70 DI-SE12 077 120

DW-SE9 059 90

DW-SE12 068 120

Contents

Safety precautions 5

Before using for the first time . . . . . . . . . . . . . . . . . . . . . . . . 5

Correct use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Children in the home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Note on use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Appliance description 9

Extraction model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Recirculation model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Operating and display elements . . . . . . . . . . . . . . . . . . . . . 11

Use 12

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

After-running time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Intensive level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Care and maintenance 15

Cleaning the housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Cleaning the grease filters . . . . . . . . . . . . . . . . . . . . . . . . . 16

Replacing the standard activated charcoal filter . . . . . . . . . 17

Cleaning and replacing the long-life activated

charcoal filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Changing the halogen light . . . . . . . . . . . . . . . . . . . . . . . . . 20

Trouble-shooting 21

What to do if ... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Produkspesifikasjoner

Merke:	V-Zug
Kategori:	eksoshette
Modell:	DI-SE 10
Vekt:	24000 g
Bredde:	1000 mm
Dybde:	600 mm
Høyde:	- mm
Støynivå:	44 dB
Antall motorer:	1
Type fettfilter:	Metall
Antall filtre:	3 stykker
Produktfarge:	Rustfritt stål
Kontrolltype:	Knapper
Strømforbruk (vanlig bruk):	255 W
Modell/Type:	Øy
Antall pærer:	4 ampuller
Type utvinning:	Ducted
Krav til strømforsyning:	230V, 10A
Motoreffekt:	175 W
Maksimal utvinningskraft:	550 m³/t
Intensiv hastighet:	Ja
Filter til oppvaskmaskin:	Ja
Antall hastighetsnivåer:	4
Lyspæretype:	Halogen
Diameter på avtrekkstilkobling:	150 mm
Innebygd evne:	Nei
Filterrengjøringsindikator:	Ja
