Vango Beta 350XL Bruksanvisning
Les nedenfor 📖 manual på norsk for Vango Beta 350XL (1 sider) i kategorien Full. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/1
IF YOU HAVE ANY PROBLEMS PLEASE CONTACT YOUR LOCAL RETAILER or
AMG Group Ltd., Kelburn Business Park, Port Glasgow, Scotland. PA14 6TD.
UK Consumer Hotline: 0844 811 0535 E-Mail: info@vango.co.uk
Calls to our Customer Hotline cost 5p per minute.
Calls from mobile phones, cable networks or public payphones will generally cost more.
Flysheet First Pitching
1. Assemble poles and lay them parallel on the ground.
(3 poles; 2 long and 1 short The poles are colour )
coded to match the corresponding pole sleeve.
2. Open flysheet on ground and position tent in desired
direction.
3. Locate pole sleeves on the flysheet and insert poles,
one at a time. Locate one end of each pole into
corresponding pin system on flysheet.
4. Push poles into an arch from opposite side and locate
pole ends into corresponding pin system on flysheet.
5. Peg out pegging points at both corners of one end of
tent using pin-pegs supplied.
6. Pull flysheet taut, away from pegged points, until tent
takes shape. Peg the opposite two elasticated pegging
points using the pin-pegs. Ensure the tent is in a
straight line.
7. Peg down poles through metal rings and remaining
flysheet pegging points using alloy pin-pegs.
8. Peg out ALL guy lines using the pin-pegs.
Inner
1. Open out inner tent inside flysheet and position
doorway to correspond with the porch entrance of the
flysheet.
2. Starting from the rear corners of the tent, attach the
hooks on the groundsheet to corresponding rings on
the base of the flysheet.
3. Suspend the inner by attaching hooks of inner tent
with rings on inside of flysheet. Start at the rear and
work forwards.
4. Attach hooks on front of groundsheet, to
corresponding rings on base of flysheet.
5. Attach porch groundsheet using the hooks to attach to
the rings at the base of the poles and at the front of
the tent.
The inner tent and flysheet can remain attached when
pitching or packing. However, in humid or very wet
weather, the underside of the flysheet may be coated with
condensation. If this occurs, it may be advisable to detach
the inner and pack it separately to avoid the inner tent
becoming wet.
Tent Pitching Instructions
Beta XL
Figure 1
Figure 2
Produkspesifikasjoner
| Merke: | Vango |
| Kategori: | Full |
| Modell: | Beta 350XL |
