Vango Dunkeld 500 Bruksanvisning
Les nedenfor 📖 manual på norsk for Vango Dunkeld 500 (6 sider) i kategorien Full. Denne guiden var nyttig for 3 personer og ble vurdert med 4.4 stjerner i gjennomsnitt av 2 brukere
Side 1/6
TENT PITCHING INSTRUCTIONS – DUNKELD (UK)
FLYSHEET FIRST PITCHING
Assemble poles and lay them on the ground
Open out flysheet and position in required direction
Locate pole sleeves on the flysheet and insert poles. The poles are colour coded to the pole sleeves.
Locate one end of each pole at one side of the tent into the metal pin system attached to the groundsheet
Make sure poles locate into correct pin system, all poles follow corresponding flysheet seams to pin system
Push poles into an arch from opposite ends and locate pole ends into corresponding metal pin
Tighten all the tensions straps at the base of the poles.
Securely peg out the rear corners of the tent
Ensure the tent is in a straight line
Peg out the remaining poles and pegging points using pin pegs at the base of poles
Attach all flysheet pole clips onto poles
Peg out ALL guy lines using pin-pegs ensuring that guy line fabric attachment points are evenly tensioned.
PRE-ATTACHED FRONT EXTENSION
To erect the pre-attached canopy, insert the pole into the sleeve, connect to Ring and Pin system, tighten the
tension straps and attach pole clips to pole.
Pull canopy away from tent until roof of canopy is taut
Peg out ALL guy lines using pin-pegs ensuring that guy line fabric attachment points are evenly tensioned.
INNER ATTACHMENT
Suspend the inner by attaching toggles of inner tent through rings on inside of flysheet
Do the rear first and work forward
It is advisable to remove the inner when taking down the tent when wet.
TENSION BAND SYSTEM:
Remove Tension Band System from pockets and attach into the corresponding clips at the apex of the pole
Adjust the straps until they are taut
DO NOT OVERTENSION. Excess tension will alter the shape of the tent
Tension bands are designed to stabilise the tunnel structure of the tent
The bands are not required to be used in calm weather
RING & PIN SYSTEM
Locate one end of pole onto the corresponding metal pin (figure 1)
Peg the corners of the tent through the metal rings using pin-pegs (figure 2)
Pegs should be positioned at a 45 degree angle to ensure maximum grip
Produkspesifikasjoner
| Merke: | Vango |
| Kategori: | Full |
| Modell: | Dunkeld 500 |
