Flysheet First Pitching
1. Assemble the three poles and lay them on the ground.
2. Open ysheet on ground and position tent in desired direction. Check that the TBS straps are un-tensioned.
3. Locate black at external pole sleeves on outside of ysheet and insert poles. The pole sleeve ends are colour
matched to the poles.
4. On one side, locate the end of each pole into corresponding eyelets on pole anchor straps.
5. Push poles into an arch from opposite side and locate pole ends into corresponding eyelets.
6. Tighten the pole anchor straps and attach the ysheet clips to the poles.
7. Peg out adjustable anchor straps at both corners of the rear of the tent, using alloy pin pegs.
8. Pull tent forwards, away from pegged points, until tent takes shape. Peg the two anchor straps at the front
of the tent.
9. Peg down the 6 pole anchor straps and remaining ysheet pegging points.
10. Tighten the ysheet by adjusting the tension straps to suit.
11. Peg out ALL guy lines using the Y alloy pegs.
Inner Tents (if previously removed)
1. Open inner tents inside ysheet and position doorways. The larger inner extends from the middle pole to the
rear of the tent. In the Equinox 450 and 600 the smaller inner ts into the front of the tent, beside the windows.
2. Starting from the rear corners of each inner, attach the elasticated hooks on the groundsheet to
corresponding rings on the ysheet anchor straps.
3. Suspend each inner by attaching elastic of inner tent with clips on inside of ysheet.
Tension Band System
The Tension Band System in this tent is congurable to suit the wind conditions.
a. CALM CONDITIONS
Straps disconnected and stored
No additional support desired.
b. WINDY CONDITIONS
Straps connected to upper sockets
Better stability and easy movement within tent.
c. STORM CONDITIONS
Straps connected to lower sockets
Maximum stability
To set up:
1. Remove Tension Band System from pockets and clip into the desired sockets at both sides of the pole.
Adjust the straps until they are taut. The rear TBS straps are threaded through the access points on the inner.
2. DO NOT OVERTENSION. Excess tension will alter the shape of the tent and may permanently distort the poles.
Equinox 350 & 450
Pitching Instructions
IF YOU HAVE ANY PROBLEMS PLEASE CONTACT YOUR LOCAL RETAILER
or
AMG Group Ltd., Kelburn Business Park, Port Glasgow, Scotland. PA14 6TD.
UK Consumer Hotline: 0844 811 0535 E-Mail: info@vango.co.uk
Calls to our Customer Hotline cost 5p per minute.
Calls from mobile phones, cable networks or public payphones will generally cost more.
