IF YOU HAVE ANY PROBLEMS PLEASE CONTACT YOUR LOCAL RETAILER or
AMG Group Ltd., Kelburn Business Park, Port Glasgow, Scotland. PA14 6TD.
UK Consumer Hotline: 0844 811 0535 E-Mail: info@vango.co.uk
Calls to our Customer Hotline cost 5p per minute.
Calls from mobile phones, cable networks or public payphones will generally cost more.
Inner First Pitching
1. Assemble poles and lay them parallel on the ground (2
poles 1 long, 1 short) –.
2. Open out inner and position in required direction.
3. Insert the poles through the pole sleeves on the
outside of the inner .
4. Locate one end of each pole on one side of inner into
the metal pin system at the end of the pole sleeves.
Push poles into an arch from opposite ends and locate
pole ends into corresponding metal pin.
5. Peg the rear point of the inner tent.
6. Carefully extend the tent forwards, then peg the two
front corners.
7. Peg both of the poles through the ring of the ring and
pin system (see figure 2).
Flysheet
1. Open out flysheet and position so that the inner
doorway and the flysheet doorway correspond.
2. A number of velcro strips are located on the underside
of the flysheet. These must be secured around the
poles of the inner tent.
3. Peg down each side of flysheet through the shock-cord
pegging points, adjacent to the metal rings of the
inner tent.
4. Pull porch taut, away from main body of tent and peg
down the corners of the porch through the shock-cord
pegging points using pin-pegs.
5. Peg out the rear point of the flysheet.
6. Peg out ALL guy lines using pin-pegs ensuring that guy
line fabric attachment points are evenly tensioned.
Tent Pitching Instructions
Soul
Figure 1
Figure 2
Produkspesifikasjoner
| Merke: | Vango |
| Kategori: | Full |
| Modell: | Soul 300 |
