Vestil CBFC-2000-DC Bruksanvisning
Les nedenfor 📖 manual på norsk for Vestil CBFC-2000-DC (13 sider) i kategorien Kran. Denne guiden var nyttig for 3 personer og ble vurdert med 4.7 stjerner i gjennomsnitt av 2 brukere
Side 1/13
TABLE OF CONTENTS Rev. 3/28/2022 CBFC, MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Co. Page 1 of 13
CBFC Counterbalanced Floor Crane
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description
of it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department
can also be contacted online at http://www.vestilmfg.com/parts_info.htm
.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php.
V
ESTIL
M
ANUFACTURING
C
ORP
.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com info@vestil.com
Table of Contents
Page
Signal Words….………………………………………………………………………………………………….
2
Safety Instructions………………………………………………..……………………………...………………
2
CBFC-500 & CBFC-1000 Exploded View & Bill of Materials……………………..………………………
3
CBFC-500 Rated Loads for Specified Boom Lengths…….………………………………………………
4
CBFC-1000 Rated Loads for Specified Boom Lengths …….……………………….……….………….
5
CBFC-2000 Exploded View & Bill of Materials………………….…..………………………..……………
6
CBFC-2000 Rated Loads for Specified Boom Lengths…………..………………………....……………
7
Manual Hydraulic Pump Exploded View & Bill of Materials.……………………………………...……
8
Operating the Manual Hydraulic Pump………………..………………………………………..…………
9
Using the Crane………………………………………………………………………...…………………….…
9
Air Purging Procedure…………………………………………………………………………………………
10
Boom Length Adjustment…………………..…………………………………………………………………
10
Record of Satisfactory Condition……………………………………………………………………………
10
Inspections & Maintenance………………………………………………………………………………….
10 - 11
Troubleshooting…………………………………………………………………………………………………
11 - 12
Labeling Diagram……...……………………………………..…………………………………………..……
12
Limited Warranty…...……………………………………………………………………………………………
13
TABLE OF CONTENTS Rev. 3/28/2022 CBFC, MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Co. Page 2 of 13
SIGNAL WORDS
SIGNAL WORDS appear in this manual to draw the reader’s attention to important safety-related
messages. The following are signal words used in this manual and their
definitions.
SAFETY INSTRUCTIONS
Vestil strives to identify foreseeable hazards associated with the use of its products, but no manual can
address every conceivable risk. Minimize the likelihood of injury by observing the hazards identified below
and by inspecting and maintaining the product as instructed in INSPECTIONS & MAINTENANCE
on p. 6.
WARNING
Risks of serious personal injuries or death.
• Read and understand the entire manual before assembling, using or servicing the crane. Read the
manual to refresh your understanding of proper use and maintenance procedures whenever necessary.
• DO NOT use the crane unless the required ballast is installed in the counterbalance box. Ballast
specifications appear on your SPECIFICATIONS document. See page 4, 5, or 7.
• DO NOT attempt to lift items that weigh more than the capacity of your crane. The capacity of the
crane decreases as boom length increases. Capacities of each model for all 3 boom lengths are provided
on your SPECIFICATIONS document as well as on labels 1157. See LABELING DIAGRAM on p. 12.
• ONLY use the crane on even, level, compacted surfaces capable of supporting the combined weight of
the crane and a full capacity load. DO NOT attempt to move the crane up or down sloped surfaces.
• DO NOT stand or sit on either the crane or the load. Avoid contact with the casters.
• Stand clear of the load while raising and lowering it.
• DO NOT perform maintenance on this crane UNLESS it is unloaded and both caster brakes are applied. If
the crane requires repair, ONLY install manufacturer-approved replacement parts.
• DO NOT attempt to raise a load unless the load hook is centered above it.
• ALWAYS observe the boom while raising or lowering a load.. Watch for binding or jerky movement. Listen
for unusual noises. Tag the unit "Out of Service". Do not use it if you observe anything abnormal.
• DO NOT use the crane unless it is in satisfactory condition. Inspect the unit before each use and as
instructed in the INSPECTIONS section on p. 10-11 to determine whether it is in SATISFACTORY CONDITION.
• Always watch the load carefully while raising and lowering the boom.
• DO NOT continue to move the pump handle back-and-forth if the boom is fully elevated.
• Before leaving the crane unattended, unload it and relieve hydraulic pressure by lowering the boom.
• DO NOT alter the pressure relief valve setting!
• DO NOT use the crane UNLESS every label is present and readable. See LABELING DIAGRAM on p. 12.
• DO NOT modify this crane in any way. Modifications automatically void the LIMITED WARRANTY and
might make the crane unsafe to use.
• Always make sure that the shackle pin is secure before applying a load to the load hook. Tighten the
shackle pin before each use. See USING THE CRANE, diagrams on p. 9.
• Failing to maintain, or repair, the crane could make the crane unsafe to use and result in serious personal
injuries or death. Only qualified personnel should perform maintenance and repairs.
NOTICE
Proper use and maintenance are essential for this product to function properly.
• Always use this product in accordance with the instructions in this manual and consistent with any
training relevant to devices used in conjunction with this product (e.g. rigging).
• Periodically lubricate pivot points.
• Keep the product clean & dry.
• Only use approved replacement parts. Contact TECHNICAL SERVICE to order replacement parts.
DANGER
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
WARNING
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
CAUTION
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
NOTICE
Identifies practices likely to result in product/property damage, such as operation
that might damage the product.
!
!
!
!
