Side 1/14
Table of Contents Rev. 10/22/2021 FHA MANUAL
Table of Contents Copyright 2021 Vestil Manufacturing Corp. Page 1 of 14
FHA-series Fixed Height Aluminum Gantry Cranes
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of it
on the bill of lading. If the product is undamaged, discard the packaging.
NOTE:
The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels, and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The Department can also
be contacted online at https://www.vestil.com/page-parts-request.php
.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php
TABLE OF CONTENTS
PAGE
Specifications…………...……………………………………….……………………………………………….…….….
2
Signal Words……….………………................................................................................................................
3
Safety Instructions…..…………………………………………………………………………….……...…………….…
3
Exploded View: FHA-2 & FHA-4…………………………………………………………………………………………
4
Bill of Materials: FHA-2 & FHA-4 (Exploded View on p. 4)………………………………………………………...
5
Bill of Materials: FHA-6 (Exploded View on p. 6)…………………………………………………………………….
5
Exploded View: FHA-6………………………………………………………………………………..…………………..
6
Assembly Instructions……………………………………………………………………………..……………………...
7 - 10
Using the Crane……………………………………………………………………………………………………………
11
Loading the Crane.………………………………………………………………………………………………….……
11
Record of Satisfactory Condition………………………………………………………………………………………
11
National Standards……………………………………………………………………………………………………….
12
Inspections & Maintenance..……………………………………………………………………………………………
12 - 13
Labeling Diagram…………………………………………………………………………………………………………
13
Limited Warranty………………………………………………………………………………………………………...…
14
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com e-mail: info@vestil.com
Table of Contents Rev. 10/22/2021 FHA MANUAL
Table of Contents Copyright 2021 Vestil Manufacturing Corp. Page 2 of 14
SPECIFICATIONS
Dimensions, net weight, and capacity information for each FHA-series crane are provided in the
following tables. However, specifications are subject to change from time to time, particularly dimensions
and net weight. Specifications documents for FHA-series cranes are provided on Vestil’s website. To
access the appropriate specifications document, navigate to the relevant webpage:
https://www.vestil.com/product.php?FID=524
. Click the “Product Specifications Table” drop-down menu
bar partway down the page. Scroll down to the entry for the model you purchased and click the button
in the column titled “PDF’s” that looks like a pencil inside a box. A PDF file will open. This file is the
specifications document. Print a copy of the document and keep it with your copy of this manual. The
following is an exemplar specifications document.
Model
A B C D E F G Capacity Net Weight
FHA-2-8-10
3
5
/
16
”
8.4cm
96”
244cm
6”
15.2cm
72
1
/
4
”
184cm
80
1
/
8
”
204cm
126”
320cm
53
3
/
4
”
136.5cm
2,000 lb.
909 kg
277 lb.
126 kg
FHA-2-10-10
3
5
/
16
”
8.4cm
120”
304.8cm
6”
15.2cm
96
1
/
4
”
244.5cm
104
1
/
8
”
264.4cm
126”
320cm
53
3
/
4
”
136.5cm
2,000 lb.
909 kg
293 lb.
133.2 kg
FHA-2-12-10
4”
10.2cm
144”
365.8cm
8”
20.3cm
120
1
/
4
”
305.4
128
1
/
8
”
325.4cm
128”
325.1cm
53
3
/
4
”
136.5cm
2,000 lb.
909 kg
315 lb.
143.2 kg
FHA-2-15-10
4
3
/
16
”
10.6cm
180”
457.2cm
8”
20.3cm
156
1
/
4
”
396.9cm
164
1
/
8
”
417.9cm
128”
325.1cm
53
3
/
4
”
136.5cm
2,000 lb.
909 kg
405 lb.
184.1 kg
FHA-4-8-10
4”
10.2cm
96”
244cm
8”
20.3cm
72
1
/
4
”
184cm
79
5
/
8
”
202.2
128”
325.1cm
53
15
/
16
”
137.0cm
4,000 lb.
1,818 kg
346 lb.
157.3 kg
FHA-4-10-10
4
3
/
16
”
10.6cm
120”
304.8cm
8”
20.3cm
96
1
/
4
”
244.5cm
103
5
/
8
”
263.2cm
128”
325.1cm
53
15
/
16
”
137.0cm
4,000 lb.
1,818 kg
348 lb.
158.2 kg
FHA-4-12-10
4
3
/
16
”
10.6cm
144”
365.8cm
8”
20.3cm
120
1
/
4
”
305.4
127
5
/
8
”
324.2cm
128”
325.1cm
53
15
/
16
”
137.0cm
4,000 lb.
1,818 kg
366 lb.
166.4 kg
FHA-4-15-10
4
11
/
16
”
11.9cm
180”
457.2cm
10”
25.4cm
156
1
/
4
”
396.9cm
163
5
/
8
”
415.6cm
130”
330.2cm
53
15
/
16
”
137.0cm
4,000 lb.
1,818 kg
411 lb.
186.8 kg
FHA-6-8-10
4
11
/
16
”
11.9cm
96”
244cm
10”
25.4cm
72
1
/
4
”
184cm
79
1
/
8
””
201.0cm
130”
330.2cm
64
11
/
16
”
164.3cm
6,000 lb.
2,727 kg
476 lb.
216.4 kg
FHA-6-10-10
4
11
/
16
”
11.9cm
120”
304.8cm
10”
25.4cm
96
1
/
4
”
244.5cm
103
1
/
8
”
261.9cm
130”
330.2cm
64
11
/
16
”
164.3cm
6,000 lb.
2,727 kg
494 lb.
224.5 kg
FHA-6-12-10
7”
17.8cm
144”
365.8cm
12”
30.5cm
120
1
/
4
”
305.4
127
1
/
8
”
322.9cm
132”
335.3cm
64
11
/
16
”
164.3cm
6,000 lb.
2,727 kg
775 lb.
352.3 kg
FHA-6-15-10
7”
17.8cm
180”
457.2cm
12”
30.5cm
156
1
/
4
”
396.9cm
163
1
/
8
”
414.3cm
132”
335.3cm
64
11
/
16
”
164.3cm
6,000 lb.
2,727 kg
874 lb.
397.3 kg
Optional equipment Description
FHA-STLO Stationary leg option, set of 4 (factory installed)
FHA-STLO-RF Stationary leg option, set of 4 (field installation)
E
