Side 1/14
Rev. 6/12/2018 JIB-P, MANUAL
Copyright 2016 Vestil Manufacturing Co. Page 1 of 14
JIB-P-Series Multi-Station Jib Cranes
Instruction Manual
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, immediately record a complete
description of the damage on the bill of lading. If the product is undamaged, discard the packaging.
NOTICES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the
product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:
a) Instructions in this manual; or
b) Information provided on labels affixed to the product.
Vestil is not responsible for any consequential damages sustained while assembling, using, or maintaining this
product.
Table of Contents
Crane specifications…..……………………………………………………………………………………………………… 2
Signal words…………………………………………………………………………………………………………………… 2
Safe use recommendations……………………………………………………………..…………………………………… 3
Function tests………………………………………………………………………………………………………………….. 3
FIGS. 1-3: Exploded parts diagrams and bills of materials………..……………………………………………………... 4 - 6
Assembly instructions………………………………………………………………………………………………………… 7 - 9
Operation instructions………………………………………………………………………………………………………… 10-11
Inspections & Maintenance…………………………………………………………………………………………………... 11-12
Labeling diagram………………………………………………………..…………………………………………………….. 13
Limited warranty……………………………………………………………………………………………………………….. 14
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail:
HUsales@vestil.comU
Rev. 6/12/2018 JIB-P, MANUAL
Copyright 2016 Vestil Manufacturing Co. Page 2 of 14
SIGNAL WORDS:
This manual uses SIGNAL WORDS to call attention to uses of this product that are likely to result in personal
injuries or property damage. The signal words used in this manual appear below along with their definitions.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS
INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that might
damage the product or other property.
Crane Specifications:
Crane dimensions and net weight appear in the table below.
Model A B C D E F G H J K L M Net wt.
JIB-P-10-6-6
87
3
/
8
” 72” 8
5
/
8
” 6” 67
3
/
4
” 84
11
/
16
” 71
13
/
16
” 34
3
/
4
” 17” 17” 7” 1
1
/
2
” 552 lb.
JIB-P-10-6-8
87
3
/
8
” 72” 8
5
/
8
” 6” 67
3
/
4
” 108
11
/
16
” 95
13
/
16
” 34
3
/
4
” 17” 17” 7” 1
1
/
2
” 614 lb.
JIB-P-10-6-10
87
3
/
8
” 72” 8
5
/
8
” 6” 67
3
/
4
” 132
11
/
16
” 119
13
/
16
” 34
3
/
4
” 17” 17” 7” 1
1
/
2
” 676 lb.
JIB-P-10-8-6
111
3
/
8
” 96” 8
5
/
8
” 6” 91
3
/
4
” 84
11
/
16
” 71
13
/
16
” 34
3
/
4
” 17” 17” 7” 1
1
/
2
” 579 lb.
JIB-P-10-8-8
111
3
/
8
” 96” 8
5
/
8
” 6” 91
3
/
4
” 108
11
/
16
” 95
13
/
16
” 34
3
/
4
” 17” 17” 7” 1
1
/
2
” 641 lb.
JIB-P-10-8-10
111
3
/
8
” 96” 8
5
/
8
” 6” 91
3
/
4
” 132
11
/
16
” 119
13
/
16
” 34
3
/
4
” 17” 17” 7” 1
1
/
2
” 703 lb.
JIB-P-10-10-6
135
3
/
8
” 120” 8
5
/
8
” 6” 115
3
/
4
” 84
11
/
16
” 71
13
/
16
” 34
3
/
4
” 17” 17” 7” 1
1
/
2
” 606 lb.
JIB-P-10-10-8
135
3
/
8
” 120” 8
5
/
8
” 6” 115
3
/
4
” 108
11
/
16
” 95
13
/
16
” 34
3
/
4
” 17” 17” 7” 1
1
/
2
” 668 lb.
JIB-P-10-10-
10
135
3
/
8
” 120” 8
5
/
8
” 6” 115
3
/
4
” 132
11
/
16
” 119
13
/
16
” 34
3
/
4
” 17” 17” 7” 1
1
/
2
” 703 lb.
