Table of Contents Rev. 6/21/2019 WTJ-HITCH MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 1 of 9
Hitch-Mounted Jib Crane Model WTJ-HITCH
Instruction Manual
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered, record a complete description of it on the bill of
lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service Department (TSD) and Replacement Parts:
For answers to questions not addressed in these instructions and to order replacement parts, labels, and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can also be
contacted online at http://www.vestilmfg.com/parts_info.htm
.
Table of Contents
Specifications……………...………….…………………..………………………………………………………………………. 2
Signal Words….……………………..……………………………………………………………………………………………. 2
Hazards……………………………………………………………………………………..……………………………………… 3
Labeling Diagram……...………………………………………………………………………………………………………….. 3
Exploded View & Bill of Materials…………..…………………………………………………………………………………… 4
Assembling the Crane……………………………………………………………………………………………………....
5, 6, 7
Post Angle Adjustments……...……….………………………………………………………………………………................ 7
Using the Crane..……………………………………………………………………………………………………………….
7, 8
Record of Normal Condition……………………………………………………………………………………………….......... 8
Inspections & Maintenance………………………………………………………………………………………………………. 8
Limited Warranty…...……………………………………………………………………………………………………………... 9
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com e-mail: info@vestil.com
