CDE6500-L/CDE4200-L/CDE3200-L

Full HD Professional LED Display

User Guide

Model No. VS15817/VS15405/VS15629

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specic languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Contents

Compliance Information

FCC Compliance Statement ................................................................ i

Industry Canada Statement ................................................................. i

CE Conformity for European Countries ...............................................ii

Declaration of RoHS2 Compliance .....................................................iii

Product Registration ...........................................................................iv

For Your Records ...............................................................................iv

Important Safety Instructions .............................................................. v

Getting Started

Package Contents .............................................................................. 1

Installing the Display .......................................................................... 2

Installing the Stand (For 65”) .............................................................. 2

Disconnecting the Stand (For 65”) ..................................................... 2

Installing the Stand (For 42”) .............................................................. 3

Installing the Stand (For 32”) .............................................................. 3

Disconnecting the Stand (For 42”/32”) ............................................... 3

Mounting ViewSonic display to the wall ............................................. 4

Wall Mount Kit Specifications (VESA) ................................................ 5

FRONT View & SIDE View of the Product ......................................... 6

Rear View of the Product ................................................................... 7

Connecting the Display ...................................................................... 8

HD Cable Box/HD Satellite Box ......................................................... 8

Personal Computer .......................................................................... 10

Using the Display Features

Remote Control and Display Controls .............................................. 12

Inserting Remote Control Batteries .................................................. 12

Remote Control and Display Controls .............................................. 12

Operation .......................................................................................... 14

Other Information

Troubleshooting ................................................................................ 24

Specifications ................................................................................... 26

RS232 Protocol ................................................................................ 28

1. Introduction ................................................................................... 28

2. Description ................................................................................... 28

3. Protocol ........................................................................................ 29

Customer Support ............................................................................ 36

Limited Warranty .............................................................................. 37

Mexico Limited Warranty .................................................................. 39

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	Fjernsyn
Modell:	CDE6500-L
Timer:	Ja
Vekt:	37200 g
Bredde:	1462.8 mm
Dybde:	74.3 mm
Høyde:	857.1 mm
Synsvinkel, horisontal:	176 °
Pakkevekt:	57000 g
Antall HDMI-porter:	3
DVI-port:	Ja
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Sertifisering:	FCC, CE, CB, UL, Mexico-UL CoC
RS-232C:	Ja
Skjermteknologi:	LED
Støyreduksjon:	Ja
On Screen Display (OSD):	Ja
Kontrastforhold:	5000:1
Produktdesign:	Digital skiltingstavle (flatskjerm)
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	- W
Rammebredde:	15 mm
Produktfarge:	Sort
Antall USB-porter:	1
HD-type:	Full HD
Pakkedybde:	225 mm
Pakkehøyde:	1000 mm
Pakkebredde:	1540 mm
Skjermdiagonal:	65 "
Naturlig sideforhold:	16:9
Kabler inkludert:	AC, VGA
Strømforbruk (vanlig bruk):	160 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 720p
Komponentvideo (YPbPr/YCbCr) inn:	1
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	RoHS
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Orientering:	Horisontal
Synsvinkel, vertikal:	176 °
PC-lydinngang:	Ja
Diagonal skjermstørrelse:	165.1 cm
Ethernet/bredbåndsforbindelse:	Nei
Relativ luftfuktighet under drift (H-H):	20 - 80
Lysstyrke for skjerm:	350 cd/m²
Oppdateringsresponstid:	6.5 ms
Pikselbredde:	- mm
Panelliv:	50000 timer
Inngangsporter for VGA (D-Sub):	1
Panelmonterbart grensesnitt:	400 x 400 mm
RMS-rangert strøm/utgangseffekt:	20 W
Batterier medfølger:	Ja
Antall medfølgende produkter:	1 stykker
Plugg inn og spill:	Ja
Aktivt skjermområde (B x H):	1427 x 802.6 mm
Bezel bredde (L/T, R/B):	15; 34.5
