Viewsonic CDP3235 Bruksanvisning

Viewsonic Fjernsyn CDP3235

Les nedenfor 📖 manual på norsk for Viewsonic CDP3235 (46 sider) i kategorien Fjernsyn. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/46

CDP3235

CDP4235

CDP4235-T

CDP4635

CDP4635-T

CDX5550-L

User Guide

Model No. VS14694/VS14693/VS14709/VS14692/VS14710/VS14691

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specic languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Compliance Information

For U.S.A.

This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in

a residential installation.

This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modications not expressly approved by the party responsible for

compliance could void your authority to operate the equipment.

For Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CE Conformity for European Countries

The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment

Directive 2002/96/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment as unsorted municipal waste, but

use the return and collection systems according to local law.

Important Safety Instructions

1. Read these instructions completely before using the equipment.

2. Keep these instructions in a safe place.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this equipment near water. Warning: To reduce the risk of re or electric shock, do not expose this

apparatus to rain or moisture.

6. Do not block any ventilation openings. Install the equipment in accordance with the manufacturer’s instructions.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other devices (including

ampliers) that produce heat.

8. Do not attempt to circumvent the safety provisions of the polarized or grounding-type plug. A polarized plug

has two blades with one wider than the other. A grounding type plug has two blades and a third grounding

prong. The wide blade and the third prong are provided for your safety. If the plug does not t into your outlet,

consult an electrician for replacement of the outlet.

9. Protect the power cord from being tread upon or pinched, particularly at the plug, and the point where if

emerges from the equipment. Be sure that the power outlet is located near the equipment so that it is easily

accessible.

10. Only use attachments/accessories specied by the manufacturer.

11. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with

the equipment. When a cart is used, use caution when moving the cart/equipment combination to

avoid injury from tipping over.

12. Unplug this equipment when it will be unused for long periods of time.

13. Refer all servicing to qualied service personnel. Service is required when the unit has been damaged in any

way, such as: if the power-supply cord or plug is damaged, if liquid is spilled onto or objects fall into the unit,

if the unit is exposed to rain or moisture, or if the unit does not operate normally or has been dropped.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	Fjernsyn
Modell:	CDP3235
Bruksanvisning:	Ja
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	178 °
Pakkevekt:	18500 g
Antall HDMI-porter:	1
Innebygde høyttalere:	Ja
Antall høyttalere:	2
Sertifisering:	FCC, ICES003, UL, cUL, CE, CB, C-Tick, BSM
HDCP:	Nei
3D:	Nei
Lydutgang:	Ja
HDMI:	Ja
Innebygd kamera:	Nei
Vekt (med stativ):	15000 g
On Screen Display (OSD):	Ja
Pakkedimensjoner (B x D x H):	44.8 x 12 x 29.3 "
Dimensjoner (B x D x H):	772.6 x 116.1 x 584 mm
Kontrastforhold:	3000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	- W
Produktfarge:	Sort
HD-type:	Full HD
Bredde (uten stativ):	772.6 mm
Høyde (uten stativ):	584 mm
Vekt (uten stativ):	14600 g
Bredde (med stativ):	772.6 mm
Dybde (med stativ):	238.8 mm
Høyde (med stativ):	621 mm
Pakkedybde:	252 mm
Pakkehøyde:	670 mm
Pakkebredde:	880 mm
Skjermdiagonal:	32 "
Naturlig sideforhold:	16:9
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Antall DVI-D-porter:	1
Kabler inkludert:	AC
Strømforbruk (vanlig bruk):	140 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 720p
Antall VGA (D-Sub)-porter:	2
Komponentvideo (YPbPr/YCbCr) inn:	1
Strøminngang/AC (strøm) inn:	Ja
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Dybde (uten stativ):	116.1 mm
Synsvinkel, vertikal:	178 °
Oppdateringsresponstid:	6.5 ms
Panelmonterbart grensesnitt:	200 x 200,400 x 200 mm
RMS-rangert strøm/utgangseffekt:	20 W
Markedsplassering:	Forretning
Skjermlysstyrke (typisk):	450 cd/m²
Størrelseforhold:	16:9
Display:	LCD
Innebygd TV-mottaker:	Nei
Kabellåsport:	Nei
Lydkontakter:	Ja
Pakningsstørrelse (BxDxH):	880 x 252 x 670 mm
Dimensjoner (B x D x H) med stativ:	772.6 x 238.8 x 621 mm
