Side 1/128

IFP9850-3

Commercial Touch Display

User Guide

Model No. VS17853

P/N: IFP9850-3

IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in

a safe manner, as well as registering your product for future service. Warranty information contained in this User

Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at

http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right

corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic®

As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding

the world’s expectations for technological evolution, innovation, and simplicity.

At ViewSonic®, we believe that our products have the potential to make a positive

impact in the world, and we are confident that the ViewSonic® product you have

chosen will serve you well.

Once again, thank you for choosing ViewSonic®!

Safety Precauons

Please read the following Safety Precauons before you start using the device.

• Keep this user guide in a safe place for later reference.

• Read all warnings and follow all instructions.

• Do not use the device near water. To reduce the risk of fire or electric shock, do

not expose the device to moisture.

• Never remove the rear cover. This display contains high-voltage parts. You may

be seriously injured if you touch them.

• Avoid exposing the device to direct sunlight or other sources of sustained heat.

• Do not install near any heat sources such as radiators, heat registers, stoves, or

other devices (including amplifiers) that may increase the temperature of the

device to dangerous levels.

• Use a soft, dry cloth to clean the external housing. For more information, refer

to the "Maintenance" section on page 116.

• When moving the device, be careful not to drop or bump the device on

anything.

• Do not place the device on an uneven or unstable surface. The device may fall

over resulting in an injury or a malfunction.

• Do not place any heavy objects on the device or connection cables.

• If smoke, an abnormal noise, or a strange odor is present, immediately turn the

device off and call your dealer or ViewSonic®. It is dangerous to continue using

the device.

• The device is a monitor with an LED backlight intended for general office use.

• Do not attempt to circumvent the safety provisions of the polarized or

grounding-type plug. A polarized plug has two blades with one wider than the

other. A grounding-type plug has two blades and a third grounding prong. The

wide blade and the third prong are provided for your safety. If the plug does not

fit into your outlet, obtain an adapter and do not attempt to force the plug into

the outlet.

• When connecting to a power outlet, DO NOT remove the grounding

prong. Please ensure grounding prongs are NEVER REMOVED.

• Protect the power cord from being treaded upon or pinched,

particularly at the plug, and at the point where it emerges from

the equipment. Ensure that the power outlet is located near the

equipment so that it is easily accessible.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	whiteboard
Modell:	IFP9850-3
Vekt:	101500 g
Bredde:	2245 mm
Dybde:	91 mm
Høyde:	1323 mm
Energieffektivitetsklasse (gammel):	A++
Berøringsskjerm:	Ja
Prosessorfrekvens:	1.5 GHz
RAM-kapasitet:	3 GB
RAM-type:	DDR4
USB-kontakttype:	USB Type-A, USB Type-B
Synsvinkel, horisontal:	178 °
Opprinnelsesland:	China
Pakkevekt:	138800 g
Antall USB 2.0-porter:	3
Antall HDMI-porter:	3
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Sertifisering:	FCC, cTUVus
Prosessorarkitektur:	ARM Cortex-A73
HDMI-versjon:	2.0
Kontrastforhold (dynamisk):	5000:1
Antall per pakke:	1 stykker
Antall RGB-porter:	1
Maksimalt internminne:	16 GB
Forhåndsinstallert programvare:	Basic Annotation Software: myViewBoard\nPro Annotation Software: myViewBoard for Windows (Embedded in Windows Slot-in PC)
Antall samtidige berøringspunkter:	20
Kontrastforhold:	1200:1
AC-inngangsspenning:	100 - 240 V
Arbeidsområde:	2172 x 1232 mm
Skjermoppløsning:	3840 x 2160 piksler
Innebygd projektor:	Nei
Berøringsoppløsning:	32767 x 32767 piksler
Produktfarge:	Sort
HD-type:	4K Ultra HD
Pakkedybde:	376 mm
Pakkehøyde:	1493 mm
Monteringssett:	Ja
Pakkebredde:	2483 mm
Prosessorkjerner:	4
Skjermdiagonal:	98 "
Berøringsteknologi:	Multi-touch
Berøringsskjermtype:	Infrarød
Operativsystemprogramvare 04:	Android 8 Oreo
Hodetelefontilkobling:	2,5 mm
Kabler inkludert:	AC, HDMI, USB
RS-232-port:	1
Strømforbruk (vanlig bruk):	171 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Hurtigstartsguide:	Ja
VESA-montering:	Ja
Paneltype:	LCD
Synsvinkel, vertikal:	178 °
Innebygd prosessor:	Ja
Ethernet LAN dataoverføringshastigheter:	10, 100 Mbit/s
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 90
Videoopptaksgrensesnitt:	HDMI
Lysstyrke for skjerm:	350 cd/m²
Oppdateringsresponstid:	6 ms
Antall HDMI-utgangsporter:	1
Panelmonterbart grensesnitt:	800 x 600 mm
Monteringsbeslag inkludert:	Ja
Display antall farger:	1.073 milliarder farger
Gjennomsnittstid mellom feil (MTBF):	30000 timer
Strømforbruk, av:	0.5 W
LED-baklystype:	Direct-LED
Høyttalerstrøm:	24 W
OPS spor:	1
Pekepenn medfølger:	Ja
Berøringssystemets responstid:	10 ms
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports:	3
USB 3.2 Gen 1 (3.1 Gen 1) antall type A Touch-porter:	2
