Viewsonic M1+ Bruksanvisning

Viewsonic videoprosjektor M1+

Les nedenfor 📖 manual på norsk for Viewsonic M1+ (93 sider) i kategorien videoprosjektor. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/93

M1+_G2

Portable LED Projector

User Guide

Model No. VS18242

P/N: M1+_G2

IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in

a safe manner, as well as registering your product for future service. Warranty information contained in this User

Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at

http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right

corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic®

As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding

the world’s expectations for technological evolution, innovation, and simplicity.

At ViewSonic®, we believe that our products have the potential to make a positive

impact in the world, and we are confident that the ViewSonic® product you have

chosen will serve you well.

Once again, thank you for choosing ViewSonic®!

Safety Precautions

Please read the following Safety Precauons before you start using the projector.

• Keep this user guide in a safe place for later reference.

• Read all warnings and follow all instrucons.

• Allow at least 20“ (50 cm) clearance around the projector to ensure proper

venlaon.

• Place the projector in a well-venlated area. Do not place anything on the

projector that prevents heat dissipaon.

• Do not place the projector on an uneven or unstable surface. The projector may

fall over, causing personal injury or projector malfuncon.

• Do not use if the projector is lted at an angle of more than 10° degrees le or

right, nor at an angle of more than 15° degrees forwards or backwards.

• Do not look straight at the projector lens during operaon. The intense light

beam may damage your eyes.

• Always open the lens shuer or remove the lens cap when the projector lamp is

on.

• Do not block the projecon lens with any objects when the projector is under

operaon as this could cause objects to become heated and deformed or even

cause a re.

• The lamp becomes extremely hot during operaon. Allow the projector to

cool for approximately 45 minutes prior to removing the lamp assembly for

replacement.

• Do not use lamps beyond the rated lamp life. Excessive use of lamps beyond the

rated life could cause them to break on rare occasions.

• Never replace the lamp assembly or any electronic component unless the

projector is unplugged.

• Do not aempt to disassemble the projector. There are dangerous high voltages

inside which may cause death if you should come into contact with live parts.

• When moving the projector, be careful not to drop or bump the projector on

anything.

• Do not place any heavy objects on the projector or connecon cables.

• Do not stand the projector on end vercally. Doing so may cause the projector to

fall over, causing personal injury or projector malfuncon.

• Avoid exposing the projector to direct sunlight or other sources of sustained

heat. Do not install near any heat sources such as radiators, heat registers,

stoves, or other devices (including ampliers) that may increase the temperature

of the projector to dangerous levels.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	videoprosjektor
Modell:	M1+
Produkttype:	Bærbar projektor
Innebygd skjerm:	Nei
Vekt:	700 g
Bredde:	151 mm
Dybde:	126 mm
Høyde:	40 mm
Støynivå:	- dB
Antall lamper:	1 lamper
Strømkilde:	AC / batteri
Bruksanvisning:	Ja
Batterikapasitet:	12000 mAh
Bluetooth:	Ja
Plassering:	Tripod
Intern lagringskapasitet:	16 GB
Wi-Fi:	Ja
Pakkevekt:	1700 g
Antall farger:	1.073 milliarder farger
Matrisestørrelse:	0.2 "
Antall USB 2.0-porter:	1
Antall HDMI-porter:	1
DVI-port:	Nei
Smart TV:	Nei
Fokus:	Manuell
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	2
Hodetelefonutganger:	1
Full HD:	Nei
3D:	Ja
HDMI-versjon:	1.4
On Screen Display (OSD):	Ja
Kontrastforhold:	120000:1
AC-inngangsspenning:	100 - 240 V
Interaktiv:	Nei
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	300 ANSI lumen
Projektoroppløsning:	WVGA (854x480)
Produktfarge:	Sort, sølv
Pakkedybde:	190 mm
Pakkehøyde:	119 mm
Pakkebredde:	219 mm
Minnekortenhet:	MicroSD (TransFlash)
Naturlig sideforhold:	16:9
Batteriliv (maks.):	3 timer
AC-adapter utgangsspenning:	19 V
Støttede grafikkoppløsninger:	640 x 480 (VGA), 1920 x 1080 (HD 1080)
Kabler inkludert:	AC, USB Type-C
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	24 - 100 "
Projeksjonsavstand:	1 - 1 m
Hjørnesteinsrettelse, vertikal:	-40 - 40 °
Horisontalt frekvensområde:	15 - 135 kHz
Støynivå (økonomisk funksjon):	25 dB
Brennviddeområde:	- mm
Zoom-type:	Fiksert
Lyskildens tjenestetid:	30000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	55 W
Støttede videofunksjoner:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
HDMI-kontakttype:	Full-size
Driftstemperatur (T-T):	0 - 40 °C
Innebygd kortleser:	Ja
Fjernkontroll medfølger:	Ja
Harmonisert system (HS)-kode:	85286200
DC-inngangskontakt:	Ja
OSD-språk:	ARA, CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, IND, ITA, JPN, KOR, POL, POR, RUS, SWE, THA, TUR, VIE
PC-lyd ut:	Ja
Ethernet/bredbåndsforbindelse:	Nei
Relativ luftfuktighet under drift (H-H):	0 - 90
Antall OSD språk:	23
RMS-rangert strøm/utgangseffekt:	6 W
Markedsplassering:	Bærbar
Lampens effekt:	10 W
Blenderåpning rekkevidde:	1.7 - 1.7
Projeksjonsfaktor:	1.2
Mobil HD-lenke (MHL):	Nei
Bæretaske:	Ja
Vertikal scanningsratio:	23 - 120 Hz
Maksimal størrelse på hukommelseskort:	32 GB
Støttede forhold:	16:9
Antall USB 3.2 Gen 1 (3.1 Gen 1) Type-C-porter:	1
Fast fokalobjektiv:	5.5 mm
