Viewsonic N2060w Bruksanvisning

Viewsonic Fjernsyn N2060w

Les nedenfor 📖 manual på norsk for Viewsonic N2060w (24 sider) i kategorien Fjernsyn. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/24

ViewSonic

User

Guide

使用手冊

N2060w

LCD TV

Model No. : VS11287-1G

使用手册

CONTENTS

Important Safety Instructions -------------------------------------------------- 1

Antenna Installation Instructions---------------------------------------------- 3

Cleaning the LCD TV ------------------------------------------------------------ 3

CONNECT PERIPHERAL EQUIPMENT

Front Panel Control Knobs ---------------------------------------------------- 4

Preparation ----------------------------------------------------------------------- 5

OPERATING INSTRUCTIONS

Use of the remote control------------------------------------------------------- 6

remote control--------------------------------------------------------------------- 7

Preparation ----------------------------------------------------------------------- 8

To use the menus ---------------------------------------------------------------- 10

Main menu ------------------------------------------------------------------------- 10

Headphone ------------------------------------------------------------------------ 16

Tips ---------------------------------------------------------------------------------- 16

Appendix

Specification------------------------------------------------------------------------ 17

Troubleshooting

Customer Support --------------------------------------------------------------- 20

Limited Warranty----------------------------------------------------------------- 21

Important Safety Instructions

1. Read these instructions completely before using the equipment.

2. Keep these instructions in a safe place.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this equipment near water. Warning: To reduce the risk of fire or electric

shock, do not expose this apparatus to rain or moisture.

6. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the LCD TV”

in this guide for further instructions.

7. Do not block any ventilation openings. Install the equipment in accordance with the

manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

devices (including ampliﬁers) that produce heat.

9. Do not attempt to circumvent the safety provisions of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A grounding type

plug has two blades and a third grounding prong. The wide blade and the third prong are

provided for your safety. If the plug does not ﬁt into your outlet, consult an electrician for

replacement of the outlet.

10. Protect the power cord from being tread upon or pinched, particularly at the plug, and the

point where if emerges from the equipment. Be sure that the power outlet is located near

the equipment so that it is easily accessible.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer,

or sold with the apparatus. When a cart is used, use caution when

cart/apparatus combination to avoid injury from tip-over.

13. Unplug this equipment when it will be unused for long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Service is required when the unit has

been damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid

is spilled onto or objects fall into the unit, if the unit is exposed to rain or moisture, or if

the unit does not operate normally or has been dropped.

moving the

ViewSonic 1 N2060w

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	Fjernsyn
Modell:	N2060w
Synsvinkel, horisontal:	176 °
Antall HDMI-porter:	1
Innebygde høyttalere:	Ja
Antall høyttalere:	2
Sertifisering:	CE, CB, GOST, SASO, RoHS
Skjermteknologi:	LCD
Vekt (med stativ):	6900 g
Tekst-TV:	1000 sider
On Screen Display (OSD):	Ja
Kontrastforhold:	1000:1
Skjermoppløsning:	1366 x 768 piksler
Produktfarge:	Sølv
HD-type:	HD
Bredde (med stativ):	522 mm
Dybde (med stativ):	191 mm
Høyde (med stativ):	420 mm
Skjermdiagonal:	20 "
Naturlig sideforhold:	16:9
Analogt signalformatsystem:	PAL, SECAM
Strømforbruk (vanlig bruk):	90 W
Driftstemperatur (T-T):	5 - 35 °C
Fjernkontroll medfølger:	Ja
Synsvinkel, vertikal:	176 °
I/O-porter:	1x Coax RF (PAL/SECAM)\n1x SCART (CVBS In/Out, RGB In, Audio In/Out)\n2x Audio L/R in (RCA)\n1x Mini stereo jack (PC/HDMI)\n1x VGA (15-pin D-sub)\n1x Headphone (3.5mm)\n1x Power (3-pin)
Lydsystem:	SRS WOW
Krav til strømforsyning:	100-240V; 50/60Hz
Relativ luftfuktighet under drift (H-H):	10 - 85
Lysstyrke for skjerm:	500 cd/m²
Oppdateringsresponstid:	8 ms
Panelmonterbart grensesnitt:	100 x 100 mm
RMS-rangert strøm/utgangseffekt:	6 W
Display:	LCD
Bildestørrelse, diagonal:	508 mm
Dvalefunksjon:	Ja
