ViewSonic’s PJ558D projector features DLP

technology that delivers

amazingly crisp digital images. With 2,500 LUMENS AND AN ULTRA-

HIGH 2000:1 CONTRAST RATIO (TYP) this portable projector lets you

deliver multimedia lessons in the classroom or dynamic presentations

in the boardroom with stunning visual impact. The native 1024x768

XGA resolution, DIGITAL KEYSTONE CORRECTION AND OPTICAL

ZOOM LENS ensure that you’ll get the best possible image in

virtually any setting. Experience the flexibility of the PJ558D thanks

to SUPPORT FOR 720P AND 1080I HD SIGNALS, advanced video

features and multiple inputs. It’s a lightweight, powerful projector

that lets you take your presentations to a new and brighter level in

the office, on the road or in schools.

Bright DLP

projector.

PJ558D

LIGHT, BRIGHT AND

PORTABLE PROJECTOR

WITH KEYSTONE CORRECTION

>Bright in virtually any setting with 2,500 lumens

Packs 2,500 lumens in just 5.4 lb. It’s the bright choice

for mobile presenters

>DLP

technology

Stunning all digital clarity delivers lifelike color, sharp

graphics, and outstanding video.

>Ultimate video source flexibility

Connect a computer or add a video source for dynamic

meetings and presentations

>Supports HD signals including 720p and 1080i

Capable of displaying HDTV signals as well as other

video and data sources*

>Advanced video features

Motion adaptive deinterlacer for superior video

performance

>Whisper-mode extends lamp life

Extend the life of your lamp up to 3,000 hours**

and reduce noise output

>OnView

controls for superior screen adjustablility

Screen geometry and color

adjustments are precisely

made via an easy-to-use,

on-screen menu

>The best warranty

in the business

Covered by a three-year parts

and labor limited

warranty, first-year Express

Exchange

and one-year

limited lamp warranty.***

VISUALLY APPEALING

MULTIMEDIA PRESENTATIONS

PROJECTOR Type 0.55" DDR DMD, DLP

Pixel Format 1024x768 XGA

Lens Manual zoom/manual focus

Zoom Factor 1.2

Keystone Vertical ± 15º

DISPLAY Size 30"–300" (diagonally)

Throw Distance 46.8"–393.6"

Throw Ratio 1.64–1.96:1

Lamp 230W, 2,000 hours**

Brightness 2,500 ANSI lumens

Contrast Ratio 2000:1

Aspect Ratio 4:3 (native), 16:9

AUDIO Speakers 1x2 watts

INPUT SIGNAL Computer and Video NTSC, NTSC 4.43, PAL, SECAM, RGB analog,

HDTV (480i, 480p, 576i, 576p, 720p, 1080i)

Frequency F

: 31–79kHz; F

: 56–85Hz

COMPATIBILITY PC Analog: from VGA up to SXGA (scaled)

Mac

®†

Analog: up to SXGA (may require a Mac adapter)

CONNECTOR RGB (input) 15-pin HD, D-sub cable (x1)

RGB (output) 15-pin HD, D-sub cable (x1)

Composite Video (input) RCA jack (x1)

S-Video (input) Mini-Din 4-pin (x1)

Component Video (input) VGA DB-15 to HDTV/component cable*

Audio (input) Stereo mini-jack (x1)

CONTROL 9-pin D-sub for RS232

POWER Voltage 100–240 VAC, 50/60Hz (universal)

Consumption 250W (typ)

CONTROLS Basic Standby/On, input, menu

OnView

Display mode, brightness, contrast, keystone, aspect ratio,

blank screen, gamma, white peaking, color temperature,

user color, video (sharpness, saturation, tint), display (phase,

tracking, H. position, V. position), advance (auto source

select, rear, ceiling, eco mode, lamp hours, lamp reset,

auto shutdown, OSD timeout, menu position, factory

reset), audio (audio, mute)

OPERATING Temperature 32–104°F (0–40°C)

CONDITIONS Humidity 10–90% (non-condensing)

NOISE LEVEL Normal/Whisper mode 37 dB (typ)/32 dB (typ)

DIMENSIONS Physical (mm) 264mm x 203mm x 96.5mm

(W x H x D) Physical (in.) 10.4" x 3.8" x 8"

WEIGHT Net 5.4 lb. (2.5 kg)

Gross 12 lb. (5.4 kg)

REGULATIONS UL, FCC-B, NOM, C-UL, ICES-003, TUV-S, RoHS

OTHER Vertical digital keystone correction, 3:2 pull down,

whisper mode

PACKAGE CONTENTS Projector, power cord, VGA cable, RCA video cable, S-video

cable, remote control, soft case, lens cap, ViewSonic

Wizard CD, Quick Start Guide

WARRANTY Three-year limited warranty on parts and labor, first-year

Express Exchange

Service. One-year limited warranty

on lamp***

PJ558D

LIGHT, BRIGHT AND PORTABLE PROJECTOR WITH KEYSTONE CORRECTION

For more product information, visit us on the web at ViewSonic.com

ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789

Customer Service and Technical Support: (800) 688-6688 • Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com

*Optional cables required. **Running whisper-mode exclusively can extend lamp life. ***See ViewSonic.com for details. †Adapter may be required. Analog adapter available from ViewSonic. The DLP logo is a trademark of

Texas Instruments. Specifications subject to change without notice. Selection, offers and programs vary by country. See your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the
