Side 1/81

PJD5132/PJD5232L/PJD5134/

PJD5234L/PJD5533w

DLP Projector

User Guide

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for

future service. Warranty information contained in this User Guide will describe your

limited coverage from ViewSonic Corporation, which is also found on our web site at

http://www.viewsonic.com in English, or in specific languages using the Regional

selection box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Model No. VS14926/VS14929/VS14928/VS14930/VS14117

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses, and can radiate radio frequency energy, and if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

y Reorient or relocate the receiving antenna.

y Increase the separation between the equipment and receiver.

y Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

y Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modications not expressly approved by the

party responsible for compliance could void your authority to operate the equipment.

For Canada

CAN ICES-3(B)/NMB-3(B)

CE Conformity for European Countries

The device complies with the EMC Directive 2004/108/EC and Low Voltage

Directive 2006/95/EC.

Following information is only for EU-member states:

The mark is in compliance with the Waste Electrical and Electronic Equipment Directive

2002/96/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment including any spent

or discarded batteries or accumulators as unsorted municipal waste, but use the return

and collection systems available.

If the batteries, accumulators and button cells included with this equipment, display

the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal

content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than

0.004% Lead.

Compliance Information

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	videoprosjektor
Modell:	PJD5234
Produkttype:	Standard stråleprojektor
Innebygd skjerm:	Nei
Vekt:	2100 g
Bredde:	294 mm
Dybde:	202 mm
Høyde:	95 mm
Støynivå:	32 dB
Strømkilde:	AC
Bruksanvisning:	Ja
Plassering:	Desktop
Wi-Fi:	Nei
USB-kontakttype:	USB Type-B
Pakkevekt:	3300 g
Antall USB 2.0-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Full HD:	Nei
HDCP:	Nei
3D:	Ja
Støyreduksjon:	Ja
On Screen Display (OSD):	Ja
Kontrastforhold:	15000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	2800 ANSI lumen
Projektoroppløsning:	XGA (1024x768)
Produktfarge:	Sort
Pakkedybde:	165 mm
Pakkehøyde:	320 mm
Pakkebredde:	388 mm
Naturlig sideforhold:	4:3
Støttede grafikkoppløsninger:	1600 x 1200 (UXGA)
Analogt signalformatsystem:	NTSC M, PAL 60, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
Kabler inkludert:	AC, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	24 - 300 "
Projeksjonsavstand:	1 - 12 m
Hjørnesteinsrettelse, vertikal:	-40 - 40 °
Støynivå (økonomisk funksjon):	29 dB
Brennviddeområde:	- mm
RS-232-port:	1
Lyskildens tjenestetid:	5000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	245 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	3
Lydinngang (V/H) inn:	2
Komponentvideo (YPbPr/YCbCr) inn:	2
Seriell grensesnittype:	RS-232
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
Driftshøyde:	0 - 3048 m
Antall S-Video-innganger:	1
Støttede Windows operativsystemer:	Ja
Ethernet/bredbåndsforbindelse:	Nei
Relativ luftfuktighet under drift (H-H):	10 - 90
Komposittvideo inn/sammensatt video inn:	1
Lydutgang (venstre/høyre):	1
RMS-rangert strøm/utgangseffekt:	2 W
Batterier medfølger:	Ja
Markedsplassering:	Presentasjon
Lampens effekt:	190 W
Lyskildens tjenestetid (økonomisk modus):	6000 timer
Projeksjonsfaktor:	1.97 - 2.17:1
Kabellåsport:	Ja
Kabellåstype:	Kensington
Støttede forhold:	4:3
Støttede Mac operativsystemer:	Ja
3D Ready:	Ja
HD-Ready:	Ja
