Viewsonic PJD6551W Bruksanvisning

Viewsonic videoprosjektor PJD6551W

Les nedenfor 📖 manual på norsk for Viewsonic PJD6551W (95 sider) i kategorien videoprosjektor. Denne guiden var nyttig for 5 personer og ble vurdert med 4.4 stjerner i gjennomsnitt av 3 brukere

Last ned PDF

Side 1/95

PJD6252L/PJD6551W/PJD7326/

PJD7526W/PJD7720HD

DLP Projector

User Guide

Model No. VS16443/VS15913/VS16444/VS16445/VS16483

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

ZZZYLHZVRQLFFRP LQ(QJOLVKRULQ VSHFL¿FODQJXDJHV XVLQJWKH 5HJLRQDOVHOHFWLRQ

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Compliance Information

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the follow-

ing two conditions: (1) this device may not cause harmful interference, and (2) this

device must accept any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses, and can radiate radio frequency energy, and

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interfer-

ence will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one

or more of the following measures:

y Reorient or relocate the receiving antenna.

y Increase the separation between the equipment and receiver.

y Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

y Consult the dealer or an experienced radio/TV technician for help.

Warning:<RXDUHFDXWLRQHGWKDWFKDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHG

by the party responsible for compliance could void your authority to operate the

equipment.

For Canada

CAN ICES-3 (B)/NMB-3(B)

CE Conformity for European Countries

The device complies with the EMC Directive 2014/30/EU and Low Voltage

Directive 2014/35/EU.

Following information is only for EU-member states:

The mark is in compliance with the Waste Electrical and Electronic

Equipment Directive 2012/19/EU (WEEE).

The mark indicates the requirement NOT to dispose the equipment

including any spent or discarded batteries or accumulators as unsorted

municipal waste, but use the return and collection systems available.

If the batteries, accumulators and button cells included with this equipment,

display the chemical symbol Hg, Cd, or Pb, then it means that the battery

has a heavy metal content of more than 0.0005% Mercury or more than,

0.002% Cadmium, or more than 0.004% Lead.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	videoprosjektor
Modell:	PJD6551W
Produkttype:	Standard stråleprojektor
Innebygd skjerm:	Nei
Vekt:	2500 g
Bredde:	316 mm
Dybde:	103.7 mm
Høyde:	228 mm
Støynivå:	- dB
Antall lamper:	1 lamper
Strømkilde:	AC
Plassering:	Desktop, Ceiling
Wi-Fi:	Nei
Pakkevekt:	4200 g
Antall farger:	1.073 milliarder farger
Antall USB 2.0-porter:	1
Antall HDMI-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Strømforbruk (maks.):	295 W
Sertifisering:	TUV-S Mark, BIS, FCC, CE EMC, CB, CCC, REACH, SVHC, WEEE, ErP, NOM, cTUVus
Optisk zoom:	1.1 x
3D:	Nei
On Screen Display (OSD):	Ja
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	3300 ANSI lumen
Projektoroppløsning:	WXGA (1280x800)
Produktfarge:	Sort
Pakkedybde:	450 mm
Pakkehøyde:	225 mm
Pakkebredde:	410 mm
Naturlig sideforhold:	16:10
Støttede grafikkoppløsninger:	1280 x 800 (WXGA), 1920 x 1080 (HD 1080)
Kabler inkludert:	AC, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	30 - 300 "
Projeksjonsavstand:	1 - 10.98 m
Hjørnesteinsrettelse, horisontal:	-40 - 40 °
Hjørnesteinsrettelse, vertikal:	-40 - 40 °
Horisontalt frekvensområde:	15 - 100 kHz
Zoomfunksjon:	Ja
Brennviddeområde:	- mm
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	5000 timer
Lyskildetype:	Lampe
Antall VGA (D-Sub)-porter:	3
HDMI-kontakttype:	Full-size
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	5 - 40 °C
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
Antall S-Video-innganger:	1
PC-lydinngang:	Ja
PC-lyd ut:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 85
Komposittvideo inn/sammensatt video inn:	1
RMS-rangert strøm/utgangseffekt:	10 W
Batterier medfølger:	Ja
Markedsplassering:	Presentasjon
Lampens effekt:	190 W
Lyskildens tjenestetid (økonomisk modus):	10000 timer
Projeksjonsfaktor:	1.55 - 1.7:1
Fjern (IR)-utgang:	1
Mobil HD-lenke (MHL):	Ja
Kabellåsport:	Ja
Vertikal scanningsratio:	24 - 120 Hz
Kabellåstype:	Kensington
Videobehandling:	30 bit
