Side 1/89

PJD5126_PJD5226_

PJD5226w_PJD6223_

PJD6253_PJD6353_PJD6383_

PJD6553w_PJD6653w_

PJD6683w

DLP Projector

User Guide

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://www.



the upper right corner of our website. “Antes de operar su equipo lea cu idadosamente

las instrucciones en este manual”

/ VS14555/VS14553/VS14195/VS14554/VS14550

Model No. VS14295/VS14551/VS14552/VS14191/VS14193

Compliance Information

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses, and can radiate radio

frequency energy, and if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

 

 

 

connected.

 !

Warning:

"#$$

party responsible for compliance could void your authority to operate the equipment.

For Canada

 %&'*++-

 /%034%*++-

CE Conformity for European Countries

&467++89+;&<!6

7++=>?&

Following information is only for EU-member states:

@A&&&6

7++7>=&DA&&&E

@3G$

discarded batteries or accumulators as unsorted municipal waste, but use the return and

collection systems available.

If the batteries, accumulators and button cells included with this equipment, display the

chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of

++++?J4$K+++7JK+++8J<

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	videoprosjektor
Modell:	PJD6683W
Produkttype:	Standard stråleprojektor
Innebygd skjerm:	Nei
Vekt:	2990 g
Bredde:	294 mm
Dybde:	242 mm
Høyde:	84 mm
Støynivå:	32 dB
Strømkilde:	AC
Plassering:	Desktop
Wi-Fi:	Nei
USB-kontakttype:	Mini-USB B
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Antall farger:	1.073 milliarder farger
Matrisestørrelse:	0.55 "
Antall USB 2.0-porter:	1
Antall HDMI-porter:	1
DVI-port:	Nei
Innebygde høyttalere:	Ja
Antall innebygde høyttalere:	1
Hodetelefonutganger:	1
Sertifisering:	CB, cUL, FCC, UL, GOST-R, SASO, TUV-GS, NOM, PSB, CCC, CECP, RoHS, WEEE
Full HD:	Ja
HDCP:	Ja
3D:	Ja
Forhåndsinnstilte moduser:	Kino
Kontrastforhold:	4000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	1 W
Projektorens lysstyrke:	3000 ANSI lumen
Projektoroppløsning:	WXGA (1280x800)
Produktfarge:	Sort
Analogt signalformatsystem:	NTSC, NTSC 4.43, NTSC M, PAL, PAL 60, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM, SECAM B, SECAM D, SECAM G, SECAM K, SECAM L
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	30 - 300 "
Projeksjonsavstand:	- m
Hjørnesteinsrettelse, vertikal:	± 40 °
Horisontalt frekvensområde:	31 - 100 kHz
Støynivå (økonomisk funksjon):	29 dB
Brennviddeområde:	- mm
RS-232-port:	1
Lyskildens tjenestetid:	5000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	350 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Antall VGA (D-Sub)-porter:	3
Komponentvideo (YPbPr/YCbCr) inn:	1
Mikrofon, linje-inn-støpsel:	Ja
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Driftshøyde:	0 - 3000 m
Lampetype:	OSRAM
Antall S-Video-innganger:	1
PC-lydinngang:	Ja
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 90
RMS-rangert strøm/utgangseffekt:	10 W
Markedsplassering:	Presentasjon
Lampens effekt:	240 W
Lyskildens tjenestetid (økonomisk modus):	6000 timer
Projeksjonsfaktor:	1.86 - 2.04:1
Størrelseforhold:	16:10
Vertikal scanningsratio:	48 - 120 Hz
3D Ready:	Ja
Forstørring:	1.1 x
HD-Ready:	Ja
