Side 1/79

PJD7830HDL/PJD7835HD

DLP Projector

User Guide

Model No.

VS15996/VS15994

IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specic languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic

With over 25 years as a world leading provider of visual solutions,

ViewSonic is dedicated to exceeding the world’s expectations for

technological evolution, innovation, and simplicity. At ViewSonic, we

believe that our products have the potential to make a positive impact

in the world, and we are confident that the ViewSonic product you have

chosen will serve you well.

Once again, thank you for choosing ViewSonic !

Compliance Information

FCC Compliance Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2) this

device must accept any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy, and if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modifications not expressly approved

by the party responsible for compliance could void your authority to operate the

equipment.

Industry Canada Statement

CAN ICES-3 (B)/NMB-3(B)

CE Conformity for European Countries

The device complies with the EMC Directive 2004/108/EC and Low Voltage

Directive 2006/95/EC.

Following information is only for EU-member states:

The mark is in compliance with the Waste Electrical and Electronic

Equipment Directive 2012/19/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment

including any spent or discarded batteries or accumulators as unsorted

municipal waste, but use the return and collection systems available.

If the batteries, accumulators and button cells included with this equipment,

display the chemical symbol Hg, Cd, or Pb, then it means that the battery

has a heavy metal content of more than 0.0005% Mercury or more than,

0.002% Cadmium, or more than 0.004% Lead.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	videoprosjektor
Modell:	PJD7835HD
Produkttype:	Standard stråleprojektor
Innebygd skjerm:	Nei
Vekt:	2800 g
Bredde:	362 mm
Dybde:	231 mm
Høyde:	109 mm
Strømkilde:	AC
Bruksanvisning:	Ja
Bluetooth:	Nei
Plassering:	Desktop, Ceiling
Wi-Fi:	Nei
Pakkevekt:	4.6 kg
Antall farger:	1.073 milliarder farger
Antall USB 2.0-porter:	1
Antall HDMI-porter:	2
DVI-port:	Nei
Fokus:	Manuell
Innebygde høyttalere:	Ja
Passordbeskyttelse:	Nei
Strømforbruk (maks.):	315 W
Sertifisering:	CB, TUV-GS, UL, CCC, CE, FCC, C-tick, RoHS, REACH, SVHC, WEEE, ErP, EAC, UkrSEPRO/EMC DOC, ULCOC, TUV-S Mark (Argentina), PSB, KCC, KC, SASO, CECP
Full HD:	Ja
Optisk zoom:	1.3 x
3D:	Ja
HDMI-versjon:	1.4
On Screen Display (OSD):	Ja
Horisontal synkronisering (min):	15 kHz
Kontrastforhold:	2200:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Maksimal utgangseffekt (RMS):	16 W
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	3500 ANSI lumen
Projektoroppløsning:	1080p (1920x1080)
Billader:	Nei
Produktfarge:	Sort
Pakkedybde:	165 mm
Pakkehøyde:	380 mm
Pakkebredde:	520 mm
Minnekortenhet:	SD
Naturlig sideforhold:	16:9
Kabler inkludert:	AC, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	- "
Projeksjonsavstand:	0.7 - 9.7 m
Horisontalt frekvensområde:	15 - 100 kHz
Zoomfunksjon:	Ja
Brennviddeområde:	- mm
Zoom-type:	Manuell
RS-232-port:	1
Lyskildens tjenestetid:	3500 timer
Antall VGA (D-Sub)-porter:	1
HDMI-kontakttype:	Full-size
Lydinngang (V/H) inn:	1
Komponentvideo (YPbPr/YCbCr) inn:	1
Mikrofon, linje-inn-støpsel:	Nei
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	RoHS
Innebygd kortleser:	Ja
Fjernkontroll medfølger:	Ja
Hurtigstartsguide:	Ja
PC-lydinngang:	Ja
Ethernet/bredbåndsforbindelse:	Nei
Relativ luftfuktighet under drift (H-H):	10 - 90
Komposittvideo inn/sammensatt video inn:	1
Lydutgang (venstre/høyre):	1
RMS-rangert strøm/utgangseffekt:	16 W
Horisontal synkronisering (maks):	100 kHz
Markedsplassering:	Presentasjon
Lyskildens tjenestetid (økonomisk modus):	8000 timer
Projeksjonsfaktor:	1.1 - 1.5:1
Mobil HD-lenke (MHL):	Ja
Innebygd TV-mottaker:	Nei
Vertikal scanningsratio:	24 - 120 Hz
Zoom-forhold:	1.5:1
AC-adapter bunt:	Ja
