Side 1/85

PX701-4K/PX701-4KE/PX728-4K/PX748-4K

Projector

User Guide

Model No. VS18244/VS18338/VS18339

Model Name: PX701-4K/PX701-4KE/PX728-4K/PX748-4K

IMPORTANT: Please read this User Guide to obtain important information on installing and using your product

in a safe manner, as well as registering your product for future service. Warranty information contained in this

User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at

http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right

corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”

Thank you for choosing ViewSonic®

As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding

the world’s expectations for technological evolution, innovation, and simplicity.

At ViewSonic®, we believe that our products have the potential to make a positive

impact in the world, and we are confident that the ViewSonic® product you have

chosen will serve you well.

Once again, thank you for choosing ViewSonic®!

Safety Precauons

Please read the following Safety Precautions before you start using the projector.

• Keep this user guide in a safe place for later reference.

• Read all warnings and follow all instrucons.

• Allow at least 20“ (50 cm) clearance around the projector to ensure proper

venlaon.

• Place the projector in a well-venlated area. Do not place anything on the

projector that prevents heat dissipaon.

• Do not place the projector on an uneven or unstable surface. The projector may

fall over, causing personal injury or projector malfuncon.

• Do not use if the projector is lted at an angle of more than 10° degrees le or

right, nor at an angle of more than 15° degrees forwards or backwards.

• Do not look straight at the projector lens during operaon. The intense light

beam may damage your eyes.

• Do not block the projecon lens with any objects when the projector is under

operaon as this could cause objects to become heated and deformed or even

cause a re.

• Do not aempt to disassemble the projector. There are dangerous high voltages

inside which may cause death if you should come into contact with live parts.

• When moving the projector, be careful not to drop or bump the projector on

anything.

• Do not place any heavy objects on the projector or connecon cables.

• Do not stand the projector on end vercally. Doing so may cause the projector to

fall over, causing personal injury or projector malfuncon.

• Avoid exposing the projector to direct sunlight or other sources of sustained

heat. Do not install near any heat sources such as radiators, heat registers,

stoves, or other devices (including ampliers) that may increase the temperature

of the projector to dangerous levels.

• Do not place liquids near or on the projector. Liquids spilled into the projector

may cause it to fail. If the projector does become wet, disconnect it from the

power supply and call your local service center to have the projector serviced.

• When the projector is under operaon, you may sense some heated air and odor

from its venlaon grill. It is a normal operaon and not a defect.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	videoprosjektor
Modell:	PX701-4K
Produkttype:	Standard stråleprojektor
Innebygd skjerm:	Nei
Vekt:	2800 g
Bredde:	312 mm
Dybde:	222 mm
Høyde:	108 mm
Støynivå:	31 dB
Strømkilde:	AC
Plassering:	Desktop
Wi-Fi:	Nei
Antall farger:	1,07 milliarder farger
Antall USB 2.0-porter:	1
Antall HDMI-porter:	2
DVI-port:	Nei
Smart TV:	Nei
Fokus:	Automatisk
Innebygde høyttalere:	Ja
Full HD:	Ja
HDCP:	Ja
Digital zoom:	2 x
Optisk zoom:	1.1 x
3D:	Nei
HDMI-versjon:	2.0b
Antall per pakke:	1 stykker
On Screen Display (OSD):	Ja
Kontrastforhold:	12000:1
AC-inngangsspenning:	100-240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	3200 ANSI lumen
Projektoroppløsning:	2160p (3840x2160)
Produktfarge:	Hvit
Støttede grafikkoppløsninger:	640 x 480 (VGA), 1920 x 1200 (WUXGA), 3840 x 2160
Separat H/V-synkronisering:	Ja
Analogt signalformatsystem:	NTSC, PAL, SECAM
Kabler inkludert:	AC
Visningsteknologi:	DMD
Skjermstørrelsekompabilitet:	30 - 300 "
Projeksjonsavstand:	1 - 10.96 m
Hjørnesteinsrettelse, vertikal:	-40 - 40 °
Horisontalt frekvensområde:	15 - 129 kHz
Støynivå (økonomisk funksjon):	27 dB
Zoomfunksjon:	Ja
Brennviddeområde:	15.843 - 17.445 mm
Lyskildens tjenestetid:	6000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	290 W
Støttede videofunksjoner:	720p, 1080i, 1080p, 2160p
HDMI-kontakttype:	Full-size
Strøminngang/AC (strøm) inn:	Ja
Seriell grensesnittype:	RS-232
Driftstemperatur (T-T):	0 - 40 °C
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Harmonisert system (HS)-kode:	85286200
forskyvning:	120
OSD-språk:	ARA, CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, IND, ITA, JPN, KOR, POL, POR, RUS, SWE, THA, TUR, VIE
PC-lyd ut:	Ja
HDR-teknologi (High Dynamic Range):	Hybrid Log-Gamma (HLG)
Ethernet/bredbåndsforbindelse:	Nei
Antall OSD språk:	23
RMS-rangert strøm/utgangseffekt:	10 W
Markedsplassering:	Spilling
Lampens effekt:	203 W
Lyskildens tjenestetid (økonomisk modus):	20000 timer
Blenderåpning rekkevidde:	2 - 2.05
Projeksjonsfaktor:	1.5-1.65
Mobil HD-lenke (MHL):	Nei
Kabellåsport:	Ja
Vertikal scanningsratio:	23 - 240 Hz
Kabellåstype:	Kensington
Zoom-forhold:	1.1:1
HDR (High Dynamic Range) støttes:	Ja
Matrisetype:	DMD
Oppdateringshyppighet:	240 Hz
