Side 1/91

Model No. VS17690

Model Name: PX703HD | PX703HDH

IMPORTANT: Please read this User Guide to obtain important information on installing and using your product

in a safe manner, as well as registering your product for future service. Warranty information contained in this

User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at

http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right

corner of our website.

PX703HD

PX703HDH

Projector

User Guide

Thank you for choosing ViewSonic®

As a world-leading provider of visual soluons, ViewSonic® is dedicated to exceeding the

world’s expectaons for technological evoluon, innovaon, and simplicity. At ViewSonic®,

we believe that our products have the potenal to make a posive impact in the world, and

we are condent that the ViewSonic® product you have chosen will serve you well.

Once again, thank you for choosing ViewSonic®!

Safety Precautions - General

Please read the following Safety Precautions before you start using the projector.

• Keep this user guide in a safe place for later reference.

• Read all warnings and follow all instructions.

• Allow at least 20“ (50 cm) clearance around the projector to ensure proper

ventilation.

• Place the projector in a well-ventilated area. Do not place anything on the

projector that prevents heat dissipation.

• Do not place the projector on an uneven or unstable surface. The projector may

fall over, causing personal injury or projector malfunction.

• Do not use if the projector is tilted at an angle of more than 10° degrees left or

right, nor at an angle of more than 15° degrees forwards or backwards.

• Do not look straight at the projector lens during operation. The intense light

beam may damage your eyes.

• Always open the lens shutter or remove the lens cap when the projector lamp is

on.

• Do not block the projection lens with any objects when the projector is under

operation as this could cause objects to become heated and deformed or even

cause a fire.

• The lamp becomes extremely hot during operation. Allow the projector to

cool for approximately 45 minutes prior to removing the lamp assembly for

replacement.

• Do not use lamps beyond the rated lamp life. Excessive use of lamps beyond the

rated life could cause them to break on rare occasions.

• Never replace the lamp assembly or any electronic component unless the

projector is unplugged.

• Do not attempt to disassemble the projector. There are dangerous high voltages

inside which may cause death if you should come into contact with live parts.

• When moving the projector, be careful not to drop or bump the projector on

anything.

• Do not place any heavy objects on the projector or connection cables.

• Do not stand the projector on end vertically. Doing so may cause the projector

to fall over, causing personal injury or projector malfunction.

• Avoid exposing the projector to direct sunlight or other sources of sustained

heat. Do not install near any heat sources such as radiators, heat registers,

stoves, or other devices (including amplifiers) that may increase the

temperature of the projector to dangerous levels.

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	videoprosjektor
Modell:	PX703HD
Produkttype:	Projektor med kort stråle
Innebygd skjerm:	Nei
Vekt:	2620 g
Bredde:	312 mm
Dybde:	222 mm
Høyde:	108 mm
Støynivå:	31 dB
Antall lamper:	1 lamper
Strømkilde:	AC
Bruksanvisning:	Ja
Plassering:	Desktop
Wi-Fi:	Nei
Antall farger:	1.073 milliarder farger
Antall USB 2.0-porter:	1
Antall HDMI-porter:	2
DVI-port:	Nei
Smart TV:	Nei
Innebygde høyttalere:	Ja
Hodetelefonutganger:	1
Full HD:	Ja
HDCP:	Ja
HDMI-versjon:	1.4
Antall per pakke:	1 stykker
On Screen Display (OSD):	Ja
Kontrastforhold:	12000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Strømforbruk (standby):	0.5 W
Projektorens lysstyrke:	3500 ANSI lumen
Projektoroppløsning:	WUXGA (1920x1200)
Produktfarge:	Hvit
Støttede grafikkoppløsninger:	640 x 480 (VGA), 1920 x 1200 (WUXGA)
Analogt signalformatsystem:	NTSC, PAL, SECAM
Kabler inkludert:	AC, VGA
Visningsteknologi:	DLP
Skjermstørrelsekompabilitet:	30 - 300 "
Projeksjonsavstand:	0.75 - 9.76 m
Hjørnesteinsrettelse, horisontal:	-40 - 40 °
Horisontalt frekvensområde:	15 - 102 kHz
Støynivå (økonomisk funksjon):	27 dB
Zoomfunksjon:	Ja
Brennviddeområde:	12 - 15.6 mm
Vertikal linseforskyvning:	-5 - 5
Lyskildens tjenestetid:	5000 timer
Lyskildetype:	Lampe
Strømforbruk (vanlig bruk):	300 W
Støttede videofunksjoner:	480i, 480p, 576i, 576p, 1080i, 1080p
Antall VGA (D-Sub)-porter:	1
HDMI-kontakttype:	Full-size
Seriell grensesnittype:	RS-232
Driftstemperatur (T-T):	0 - 40 °C
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
Harmonisert system (HS)-kode:	85286200
forskyvning:	110
OSD-språk:	ARA, CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, INC, IND, ITA, JPN, KOR, POL, POR, RUS, SWE, THA, TUR, VIE
Ethernet/bredbåndsforbindelse:	Nei
Antall OSD språk:	23
RMS-rangert strøm/utgangseffekt:	10 W
Markedsplassering:	Short throw
Lyskildens tjenestetid (økonomisk modus):	20000 timer
Blenderåpning rekkevidde:	1.9 - 2.47
PC inn (D-Sub):	Ja
Vertikal scanningsratio:	23 - 120 Hz
