IMPORTANT: Please read this User Guide to obtain important information on installing

and using your product in a safe manner, as well as registering your product for future

service. Warranty information contained in this User Guide will describe your limited

coverage from ViewSonic Corporation, which is also found on our web site at http://

www.viewsonic.com in English, or in specic languages using the Regional selection

box in the upper right corner of our website. “Antes de operar su equipo lea cu

idadosamente las instrucciones en este manual”

VT3200-L/VT4200-L

Professional LCD TV display

User Guide

Model No.: VS15694/VS15696

Contents

Compliance Information .......................................................................................... i

Declaration of RoHS2 Compliance .........................................................................ii

Product Registration ...............................................................................................iii

Important Safety Instructions .................................................................................iv

Getting Started ................................................................... 1

Package Contents ....................................................................................................1

Installing the LCD TV ............................................................................................... 2

Installing the Stand (For 42”) ..............................................................................2

Installing the Stand (For 32”) ..............................................................................2

Disconnecting the Stand ....................................................................................2

Mounting ViewSonic LCD TV to the wall ............................................................3

Wall Mount Kit Specications (VESA) ................................................................ 4

FRONT View & SIDE View of the Product .............................................................. 5

Rear View of the Product ........................................................................................6

Connecting the LCD TV ........................................................................................... 7

Cable System or VHF/UHF Antenna System .....................................................7

Cable System and VHF/UHF Antenna System ..................................................7

HD Cable Box/HD Satellite Box .........................................................................7

Personal Computer ............................................................................................10

Using the TV Features....................................................... 11

Remote Control and TV Controls ...........................................................................11

Inserting Remote Control Batteries ....................................................................11

Remote Control and TV Controls .......................................................................11

Operation ..................................................................................................................14

Other Information .............................................................. 31

Troubleshooting ....................................................................................................... 31

Specications ...........................................................................................................33

RS232 Protocol ........................................................................................................34

Customer Support ...................................................................................................43

Limited Warranty ......................................................................................................44

Mexico Limited Warranty ........................................................................................45

FCC Statement

This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy, and if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Warning: You are cautioned that changes or modications not expressly approved by the party

responsible for compliance could void your authority to operate the equipment.

Following information is only for EU-member states:

The mark shown to the right is in compliance with the Waste Electrical and Electronic

Equipment Directive 2002/96/EC (WEEE).

The mark indicates the requirement NOT to dispose the equipment as unsorted municipal

waste, but use the return and collection systems according to local law.

If the batteries, accumulators and button cells included with this equipment, display the

chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content of

more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004% Lead.

ENERGY STAR Information:

• ENERGY STAR is a set of power-saving guidelines issued by the U.S. Environmental Protection

Agency (EPA).

ENERGY STAR is a joint program of the U.S. Environmental Protection Agency and the U.S.

Department of Energy helping us all save money and protect the environment through energy

efcient products and practices.

The power consumption will be changed, if the TV set up to be another mode except for default as-

shipped television conguration and settings.

The power consumption may exceed energy consumption beyond the limits required for ENERGY

STAR qualication when the optional function used or the operation mode changed in use.

Dolby Trademark Information:

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol

are trademarks of Dolby Laboratories.

Compliance Information

Produkspesifikasjoner

Merke:	Viewsonic
Kategori:	Fjernsyn
Modell:	VT4200-L
Barnelås:	Ja
Wi-Fi:	Nei
Synsvinkel, horisontal:	170 °
Pakkevekt:	14700 g
Antall USB 2.0-porter:	1
Antall HDMI-porter:	3
Innebygde høyttalere:	Ja
Antall høyttalere:	2
Hodetelefonutganger:	1
Sertifisering:	FCC, UL, RoHS, Mexico-UL-CoC, Mexico Energy
3D:	Nei
Skjermteknologi:	LCD
Vekt (med stativ):	13300 g
Innebygd subwoofer:	Nei
Kontrastforhold:	3000:1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Produktfarge:	Sort
HD-type:	Full HD
Bredde (uten stativ):	974.2 mm
Høyde (uten stativ):	579.1 mm
Vekt (uten stativ):	11900 g
Bredde (med stativ):	974.2 mm
Dybde (med stativ):	210 mm
Høyde (med stativ):	626.3 mm
Skjermdiagonal:	42 "
Naturlig sideforhold:	16:9
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
RS-232-port:	1
Strømforbruk (vanlig bruk):	59 W
Støttede videofunksjoner:	1080i, 1080p, 480i, 480p, 720p
Strøminngang/AC (strøm) inn:	Ja
Driftstemperatur (T-T):	0 - 40 °C
Bærekraftsertifikater:	ENERGY STAR
Innebygd kortleser:	Nei
Fjernkontroll medfølger:	Ja
VESA-montering:	Ja
Dybde (uten stativ):	64.4 mm
Synsvinkel, vertikal:	170 °
Tekst-TV-funksjon:	Ja
Antall S-Video-innganger:	1
PC-lydinngang:	Nei
Av/på-bryter:	Ja
Ethernet/bredbåndsforbindelse:	Nei
Relativ luftfuktighet under drift (H-H):	20 - 80
Lysstyrke for skjerm:	350 cd/m²
Oppdateringsresponstid:	6.5 ms
Panelmonterbart grensesnitt:	200 x 200 mm
RMS-rangert strøm/utgangseffekt:	20 W
PC inn (D-Sub):	Nei
Kabellåsport:	Ja
IC-inngang:	Nei
Vanlig grensesnitt pluss (CI+):	Nei
Av/på-timer:	Ja
Skjermformatsjusteringer:	16:9
