F1656B EN
(031308J)
Viking Installation Guide
Built-In Rangehood Accessories
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
call 1-888-VIKING1 (845-4641)
or visit the Viking Web site at
vikingrange.com
BACKSPLASH
The backsplash is used to cover the wall space
between the top of the backguard or high shelf
and the bottom of the hood.
Place the backsplash in the desired location.
Secure to the wall by placing the screws that are
provided in the holes on the backsplash. When
screws are used to fasten the panel to materials
other than wood, the appropriate type anchor
should be used with the screws.
Backsplash
Screw
holes
WARMING SHELF PANEL
Always install the warming shelf panel
before installing the rangehood.
The warming shelf panel is usually
placed on the wall just below the
rangehood.
1. Place the bottom of the warming
shelf panel in the desired location
and secure to the wall.
2. Hook the bottom of the top
section to the top of the bottom
section and secure to the wall.
3. Install the rangehood so that it will
rest on the top ledge of the
warming shelf panel.
BOTTOM
TOP
Hook top section
to bottom section
Hood should rest on this top ledge
HOOD DUCT COVER
1. Mount duct cover to the ceiling through the screw holes provided. Secure to solid ceiling joists
to support the weight with the screws provided.
2. For wall hood models, after mounting the duct cover to the ceiling, attach the hood to the wall
and then secure the hood to duct cover using the sheet metal screws provided.
3. For island hood models, after mounting the duct cover to the ceiling, secure the hood by
tightening the bolts into the cage-nuts of the duct cover.
WALL RANGEHOOD DUCT COVER ISLAND RANGEHOOD DUCT COVER
Larger holes on
top
Smaller holes
on bottom
sheet metal screws
bolts
Cage nuts
on bottom
2 3
