VIKING Equipment Co., Inc.
www.vikingairmovers.com
Owner's Manual
Owner's Manual Pressurized Drying System (PDS-12)
Caution! Read These Instructions Before Operation and Save
Specications
Cautionary Note:
Atmospheric dust and carbon particles from the motor
brushes may be introduced through the hoses, leaving a
black residue. Please be advised that all brass air outlets
are live. Any 2 or more unused air outlets should have
the provided tubing connected to each other as a plug-
off system, minimizing carbon residue that may discolor
light colored carpeting.
GENERAL SAFETY WARNINGS
Never restrict airow to the inlet.
This will cause it to overheat and
possibly catch re.
Ensure that children do not have
access to the equipment. Keep
small children and animals away
from the intake vent. Strong
suction may cause severe injury.
• DO NOT block air output
with anything other than the
supplied plug-off system.
• DO NOT block the drying
nozzles or connect the nozzles
with unused hoses.
• DO NOT introduce liquids or
ammable materials into the
intake.
• When using any electrical
equipment, basic precautions
should always be followed.
• NEVER operate electrical
equipment in standing water.
• NEVER service or clean this
unit while it is plugged in.
• NEVER sit or stand on the unit
or use as a shelf.
• NOT intended for outdoor use
• DO NOT disconnect the unit
by pulling on the cord. Grasp
the plug rmly and pull it out
of the wall socket or power
receptacle.
• DO NOT operate the unit with
a cut or frayed power cord.
• To reduce the risk of re or
electric shock, DO NOT use
this machine with any solid-
state speed control device.
• Always use a grounded outlet.
• DO NOT use when you are
tired, distracted or under the
inuence of drugs, alcohol or
medication.
• DO NOT handle plug with wet
hands.
• DO NOT leave device plugged
in when not in use.
• Store this equipment indoors;
DO NOT expose to harsh
weather.
• Use ONLY Manufacturer’s
recommended attachments.
• DO NOT pull or carry by the
cord, use the cord as a handle,
close doors on the cord, or pull
the cord around sharp edges.
• DO NOT run over cord.
• Keep cord and housing away
from heated surfaces.
• Turn the unit off before
unplugging.
• Use ONLY as described in this
manual.
• DO NOT place mouth or other
body parts over the intake
holes.
Model PDS-12
Voltage/Frequency 115 V ~ 50Hz
Amperage 12 A
Tubing Length 100 Feet / 30.5 m
Tubing Diameter
ID: 1/3 inch (8 mm)
OD: 1/2 inch (12 mm)
OPERATING INSTRUCTIONS
(1) Check the PDS-12 intake vent and surrounding
workspace for anything that may potentially block
the intake before plugging in and operating the unit.
(2) Set the machine to desired position for operation.
(3) Cut tubing to the desired length and attach by
inserting into the air outlet fittings.
(4) Drill a 1/2 inch hole in the base of the wall to be
dried, and insert tubing.
(5) Plug the power cord into a GFCI outlet.
(6) Do not use an extension cord in conjunction with
the standard power cord.
Toubleshooting
SYMPTOM PROBLEM SOLUTION
Unit will not turn
on
Not plugged in Plug machine in
proper outlet
Switch is worn Replace Switch
Tripped circuit
breaker
Reset Breaker
Short in power
cord
Replace power cord
or replace cord end
Tripped motor
thermal switch
Unplug machine, cool
machine down and
plug in again
PDS-12 is
making strange
noises
Motor bearing is
worn
Replace motor
Motor runs
but no airow
detected
Intake vent is
obstructed
Turn off PDS-12.
Remove obstruction.
Restart motor
Motor stops
running
Intake vent is
obstructed
Remove obstruction.
Allow motor to cool.
Motor will start
automatically.
Motor brushes
worn
Motor brushes
are normal wear
items and are not
warrantied. They
may be purchased
for a nominal cost
through your Viking
distributor. Average
brush life is 1200-
1500 hours or
50/24hour days.
WARRANTOR:
VIKING EQUIPMENT COMPANY, INC. /
XPOWER MANUFACTURE, INC.
668 S. 6th Ave.,
City of Industry, CA 91746 USA
Toll Free: (800)-252-5201
WARRANTY AND LIMITATION OF LIABILITY
Viking Equipment Co., Inc. / XPOWER Manufacture,
Inc. (the “Company”) warrants to the rst end –user
purchaser hat the equipment and parts thereof, when
shipped, will be free from defects in materials and the
Company’s workmanship. If any such defects exist
or later appear, the Company shall provide prompt
remedial action as stated herein, to correct the defect.
The Company shall have no obligation or liability under
this Warranty unless the customer has obtained a
Return Material Authorization (RMA). To get an RMA
you must present proof of purchase, by the use of the
original sales receipt, Internet Product Registration, or
other reasonable and reliable means. To obtain an RMA,
call Viking Equipment Company / XPOWER Manufacture
at (800) 252-5201 and ask for the Customer Service
Department, which will then issue an RMA number and
will arrange for repair or replacement, at our option,
according to the following schedule:
This warranty covers Viking Pressurized Drying Systems
(PDS-12).
Year One – 100% labor and parts (all components
other than those noted below).
Year Two – Labor only
Year(s) Three through Five – Only materials and
workmanship of the housing are covered
Motor Brushes, Hoses, Brass Barb ttings, gaskets
and other wear items are not warranted.
Warranty service shall only be performed by a service
provider authorized by the Company.
Freight to the Company is the responsibility of the end-
user. The end-user is responsible for normal care and
proper return packaging.
Equipment or Parts thereof, manufactured by others
are warranted hereunder only to the extent of such
manufacturer’s warranty to the Company.
Since after purchase, the Equipment and Parts thereof
are under the sole control of the Purchaser, this Warranty
is subject to, and shall be applicable only if, the following
conditions are met:
a. The Company’s instructions as to usage,
operation and maintenance have been followed;
b. The Equipment and Parts thereof, have been used
under normal indoor operating conditions.
c. The Equipment and Parts thereof have been
correctly operated and maintained and have not
been damaged by misuse, neglect, or accident.
d. The purchaser has not attempted or performed
corrective work or change on the Equipment and/or
Parts thereof.
e. The Company shall have received notice (RMA
Request) of any defect no later than thirty (30) days
after the Purchaser rst had knowledge of the same.
This warranty is in lieu of any and all other
warranties, express, implied or statutory
including, without limitation, warranties of
merchantability and tness for a particular
purpose or use.
LIMITATION OF LIABILITY
THE COMPANY SHALL HAVE NO LIABILITY WHATSOEVER
IN ANY EVENT FOR PAYMENT OF ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING, WITHOUT
LIMITATION, WATER DAMAGE (THE END-USER SHOULD
TAKE PRECAUTIONS AGAINST SAME), LOST PROFITS,
DELAY, OR LOSS OF USE, OR DAMAGES FOR INJURY
TO ANY PERSON OR PROPERTY. BY ACCEPTING THE
EQUIPMENT AND/OR PARTS THEREOF, THE FIRST END-
USER PURCHASER OF SUBSEQUENT USER AGREES
