Installation
GUIDE
Tuscany Freestanding Dual Fuel Ranges
TVDR3604B, TVDR3602G, CTVDR3604B, CTVDR3602G
TVDR4806B, TVDR4804G, TVDR4804I, TVDR4802GI, TVDR4804F
CTVDR4806B, CTVDR4804G, CTVDR4804I, CTVDR4802GI, CTVDR4804F
TVDR6608B, TVDR6606G, TVDR6606I, TVDR6606F
CTVDR6608B, CTVDR6606G, CTVDR6606I, CTVDR6606F
2
Table of Contents
Important Safety Instructions / Warnings .............................................................................................................................................3
Dimensions /Specifi cations ........................................................................................................................................................................ 6
Clearance Dimensions ................................................................................................................................................................................10
Electrical Requirements .............................................................................................................................................................................12
Gas Requirements ........................................................................................................................................................................................13
General Information ....................................................................................................................................................................................14
Installation ......................................................................................................................................................................................................15
Electrical Connection 3-Wire ...............................................................................................................................................................15
Electrical Connection 4-Wire ...............................................................................................................................................................16
Leveling/Adjustments ...........................................................................................................................................................................18
Anti-Tip Device .........................................................................................................................................................................................20
Final Preparation ...........................................................................................................................................................................................22
Service Information .....................................................................................................................................................................................23
3
IMPORTANT - Please Read and Follow
•Before beginning, please read these instructions completely and carefully.
•Do not remove permanently affi xed labels, warnings, or plates from product. This may void the warranty.
• All local and national codes and ordinances must be observed. Installation must conform with local codes or in the absence of
codes, the National Fuel Gas Code ANSI Z223.1 INFPA54.
•The installer must leave these instructions with the consumer who should retain for local inspector’s use and for future reference.
In Canada: Installation must be in accordance with the current CAN/CGA B149.1 & 2 Gas Installation codes and/or local codes.
Electrical installation must be in accordance with the current CSA C22.1 Canadian Electrical Codes
Part 1 and/or local codes.
In Massachusetts: All gas products must be installed by a “Massachusetts” licensed plumber or gasfi tter. A “T” type handle manual
valve must be installed in the gas supply line to the appliance.
An air curtain or other overhead range hood which operates by blowing a downward airfl ow onto the range, shall not be used
with a gas range.
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is the safety alert symbol. This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and the word “WARNING,” “DANGER” or “CAUTION.” These words
mean:
Hazards or unsafe practices which COULD
result in death or severe personal injury.
Hazards or unsafe practices which COULD result
in minor personal injury.
All safety messages will identify the hazard, tell
you how to reduce the chance of injury, and tell
you what can happen if the instructions are not
followed.
WARNING
Hazards or unsafe practices which WILL
result in death or severe personal injury.
