Side 1/36
F-37418 (12-09) Rev 2
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
3600 NORTH POINT BLVD.
BALTIMORE, MD 21222
TOPS
Open Top
Hot Top
Griddle Top
Work Surface
BASES
Standard Oven
Convection Oven
Cabinet Base
ONE POWERFUL PACKAGE
SERVICE MANUAL
V SERIES HDR
GAS RANGES
- NOTICE -
This manual is prepared for use by trained service technicians and
should not be used by those not properly qualified. If you have
attended a service school for this product, you may still be qualified to
perform the procedures described in this manual. This manual is not
intended to be all encompassing. If you have not attended a service
school for this product, you should read, in its entirety, the repair
procedure you wish to perform to determine if you have the necessary
tools, instruments and skills required to perform the procedure.
Procedures for which you do not have the necessary tools,
instruments and skills should be performed by a trained service
technician.
For additional information on Vulcan- Hart or to locate an authorized parts and service
provider in your area, visit our website at www.VulcanHart.com.
Page 2 of 36
IMPORTANT FOR YOUR SAFETY
THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL GAS
EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND
ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.
POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN THE
EVENT THE SMELL OF GAS IS DETECTED. THIS INFORMATION CAN BE OBTAINED
FROM THE LOCAL GAS SUPPLIER. IN THE EVENT OF A POWER FAILURE, DO NOT
ATTEMPT TO OPERATE THIS DEVICE.
IMPORTANT
IN THE EVENT A GAS ODOR IS DETECTED, SHUT DOWN UNITS AT MAIN SHUTOFF
VALVE AND CONTACT THE LOCAL GAS COMPANY OR GAS SUPPLIER FOR SERVICE.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS IN
THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
WARNING: SHUT OFF THE GAS BEFORE SERVICING THE UNIT.
WARNING: PRIOR TO LIGHTING, CHECK ALL JOINTS IN THE GAS SUPPLY LINE
FOR LEAKS. USE SOAP AND WATER SOLUTION. DO NOT USE AN OPEN FLAME.
A. CHECK ALL JOINTS PRIOR TO THE GAS VALVE (SOLENOID)
BEFORE LIGHTING UNIT.
B. CHECK ALL JOINTS BEYOND GAS VALVE (SOLENOID)
AFTER UNIT IS LIT.
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE
INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
WARNING: ELECTRICAL AND GROUNDING CONNECTIONS MUST COMPLY WITH
THE APPLICABLE PORTIONS OF THE NATIONAL ELECTRICAL CODE AND/OR
OTHER LOCAL ELECTRICAL CODES.
WARNING: APPLIANCES EQUIPPED WITH A FLEXIBLE ELECTRIC SUPPLY CORD
ARE PROVIDED WITH A THREE-PRONG GROUNDING PLUG. IT IS IMPERATIVE
THAT THIS PLUG BE CONNECTED INTO A PROPERLY GROUNDED THREE-PRONG
RECEPTACLE. DO NOT REMOVE THE GROUNDING PRONG FROM THIS PLUG.
IN THE EVENT OF A POWER FAILURE, DO NOT ATTEMPT TO OPERATE THIS DEVICE.
Page 3 of 36
TABLE OF CONTENTS
GENERAL
Introduction
Installation
Operation
Cleaning
Lubrication
Tools
Specifications
REMOVAL AND REPLACEMENT OF PARTS
Electrical Lockout / Tagout Procedure
Gas Lockout / Tagout Procedure
Units Mounted On Casters
Covers and Panels
Manifold Cover
Kick Panel
Component Removal
Oven Control Panel(S Model)
Oven Control Panel (C Model)
Pilot Safety Valve and temperature Control Assembly (S Model)
Pilot Safety Valve (S Model)
Temperature Control (S Model)
Temperature Control (C Model)
Solenoid, Pilot Safety and Manual Gas Shut-Off Valve Assembly (C Model)
Solenoid (C Model)
Pilot Safety Valve (C Model)
Manual Gas Shut-Off Valve (C Model)
Oven Pilot Assembly
Oven Burner Assembly
Oven Burner Nozzle and Gas Orifice
Pilot Quick Disconnect Valve
Top Section Burner (Open Top)
Top Section Burner (Char Broiler)
Top Section Burner (French/Hot Top and Griddle)
Top Section Burner Valve
Fan Control Switch (C Model)
Convection Motor (C Model)
Oven Door Microswitch (C Model)
SERVICE PROCEDURES AND ADJUSTMENTS
Gas Leak Check
Gas Pressure Check
Gas Pressure Regulator Adjustment
Oven Pilot Flame Check and Adjustment
Oven Burner Nozzle and Gas Orifice Check
Air Shutter Adjustment
