DIMENSION GUIDE
1 of 21
INDUCTION COOKTOP
IMPORTANT: Dimensional specications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation Guide before
selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Whirlpool
®
appliances are appropriately UL, CUL or CSA approved.
PRODUCT DIMENSIONS
MODEL #
30" (78.2 cm) Cooktop
WCIT7530SB/WCIT7530SS/
WCIT7030SB/WCIT7030SS
36" (91.4 cm) Cooktop
WCIT7536SB/WCIT7536SS
Unit of Measurement in cm in cm
Overall Width with Frame (A) 30
3
/
4
78.2 36
5
/
16
92.2
Depth with Frame (B) 22 55.9 22 55.9
Overall Width without Frame (C) 30
3
/
4
78.2 36
5
/
16
92.2
Depth without Frame (D) 21
5
/
16
54.1 21
5
/
16
54.1
W11731555A
TOP VIEW 30" MODEL
B
A
C
D
A
B
C
D
TOP VIEW 36" MODEL
DIMENSION GUIDE
INDUCTION COOKTOP
IMPORTANT: Dimensional specications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation Guide before
selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Whirlpool
®
appliances are appropriately UL, CUL or CSA approved.
2 of 21
PRODUCT DIMENSIONS
MODEL #
30" (78.2 cm) Cooktop
WCIT7530SB/WCIT7530SS/
WCIT7030SB/WCIT7030SS
36" (91.4 cm) Cooktop
WCIT7536SB/WCIT7536SS
Unit of Measurement in cm in cm
Glass Width (E) 30
3
/
4
78.2 36
5
/
16
92.2
Electric Inlet to Surface (F)
3
15
/
16
9.9 3
15
/
16
9.9
Center to Electric Inlet (G) 9
13
/
16
24.9 12
5
/
16
31.2
Recessed Cooktop Width (H) 28
1
/
2
72.4 33 84.0
FRONT VIEW
BACK VIEW
E
G
F
H
G
DIMENSION GUIDE
INDUCTION COOKTOP
IMPORTANT: Dimensional specications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation Guide before
selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Whirlpool
®
appliances are appropriately UL, CUL or CSA approved.
3 of 21
PRODUCT DIMENSIONS
MODEL #
30" (78.2 cm) Cooktop
WCIT7530SB/WCIT7530SS/
WCIT7030SB/WCIT7030SS
36" (91.4 cm) Cooktop
WCIT7536SB/WCIT7536SS
Opening/Clearance Measurement in cm in cm
Control Panel Height (I) 2
3
/
4
7 2
3
/
4
7
Depth without Frame (J) 21
5
/
16
54.1 21
5
/
16
54.1
Depth with Frame (K) 22 55.9 22 55.9
Recessed Cooktop Height (L) 3
1
/
2
8.94 3
1
/
2
8.94
Cooking Surface Height (M) 3
3
/
4
9.34 3
3
/
4
9.34
Recessed Cooktop Depth (N) 19
7
/
16
49.3 20
5
/
16
51.4
SIDE VIEW
L
M
I
N
K
J
