PRODUCT MODEL NUMBERS
PRODUCT DIMENSIONS
Top Mount Refrigerator
WRT108FZD WRT318FMD
WRT138FZD WRT519SZD
WRT148FZD WRT549SZD
WRT318FZD
Electrical: A 115-volt, 60-Hz, AC-only, 15-
or 20-amp fused, grounded electrical supply
is required. It is recommended that a
separate circuit serving only your refrigerator
be provided. Use an outlet that cannot be
turned off by a switch. Do not use an
extension cord.
NOTE: Before performing any type of
installation, cleaning, or removing a light
bulb, turn the control (Thermostat,
Refrigerator or Freezer Control depending on
the model) to OFF and then disconnect the
refrigerator from the electrical source. When
you are finished, reconnect the refrigerator
to the electrical source and reset the control
(Thermostat, Refrigerator or Freezer Control
depending on the model) to the desired
setting. See “Using the Controls.”
Water: A cold water supply with water
pressure between 30 and 120 psi (207 and
827 kPa) is required to operate ice maker and
water dispenser. If you have questions about
your water pressure, call a licensed, qualified
plumber.
IMPORTANT: The pressure of the water
coming out of a reverse osmosis system
going to the water inlet valve of the
refrigerator needs to be between 30 and
120 psi (207 and 827 kPa).
Reverse Osmosis Water Supply: If a reverse
osmosis water filtration system is connected
to your cold water supply, the water pressure
to the reverse osmosis system needs to be a
minimum of 40 to 60 psi (276 to 414 kPa).
To ensure proper ventilation for your refrigerator, allow for a " (1.25 cm) space on each and Z\x
between overhead cabinets and refrigerator top. Allow at least 1" (2.5 cm) between back of cabinet
and the wall. If your refrigerator has an ice maker, make sure you leave some extra space at the
back for the water line connections.
If you are installing your refrigerator next to a fixed wall, leave 2" (5 cm) minimum on the hinge side
(depending on your model) to allow for the door to swing open.
NOTE: This refrigerator is intended for use in a location where the temperature ranges from a
minimum of 55°F (13°C) to a maximum of 110°F (43°C). The preferred room temperature range for
optimum performance, which reduces electricity usage and provides superior cooling, is between
60°F (15°C) and 90°F (32°C). It is recommended that you do not install the refrigerator near a heat
source, such as an oven or radiator.
LOCATION REQUIREMENTS
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. W10669181A
4/15
Model
Number Model Size
Reversible
Door
Height -
Overall
“A”
Height -
Top of
Cabinet
“B”
Depth -
Door Open
90°
“C”
Depth -
With
Handles
“D”
Depth -
Without
Handles
“E”
Depth -
Cabinet Only
“F”
Width -
Cabinet
“G”
WRT108FZD
WRT138FZD
WRT148FZD
WRT318FZD
WRT318FMD
18.2 cu. ft. Yes
65 "M\,
(167.3 cm)
65 "C\,
(166 cm)
59 "C\v
(151.8 cm)
33 "Z\x
(85 cm)
31 "C\,
(79.7 cm)
28 "M\,
(73.3 cm)
29 "C\v
(75.6 cm)
WRT519SZD
WRT549SZD
19.2 cu. ft. Yes
65 "M\,
(167.3 cm)
65 "C\,
(166 cm)
59 ”M\,
(152 cm)
34 "Z\x
(87.6 cm)
32 "M\,
(83.5 cm)
28 "M\,
(73.3 cm)
29 "C\v
(75.6 cm)
4
1
A
overall
B
top of
cabine
t
G
not incl.
handle
E
incl.
handle
D
cabinet
F
1
/
2" (1.25 cm)
2" (5.08 cm)
90˚
C
