Side 1/2
NAPOLI
ISLAND
EUROPA
ZEPHYRONLINE.COM
Strong and sophisticated with up-
wardly-angled walls, Napoli makes an
impression in any kitchen. Upgraded
with Zephyr’s DCBL Suppression Sys-
tem® and Bloom™ HD LED light bulbs,
Napoli is a technological achievement
and a cut above the rest. Now including
an enhanced Quick-Lock installation
system with magnetic duct covers,
Napoli is as easy to install as it is to
enjoy. Now available with an optional
wireless remote control.
TOP
2 1/16”
AC In
C/L
C/L
4 1/2”
9/16”
FRONT
SIDE
STANDARD
min. ducted - 32”
min. recirc. - 36 1/2”
max. - 50”
Z1C-02NA
min. ducted - 49”
min. recirc. - 53 1/2”
max. - 80”
9 13/16”
25 9/16”
12 13/16”
35 7/16”, 41 15/16”
9 9/16”10 5/16”
7 15/16”
TM
C
INTERNAL BLOWER
STANDARD
INTERNAL BLOWER with ACT™
AIRFLOW CONTROL TECHNOLOGY™*
Min. - Max. CFM
Min. - Max. Sones
250 - 715
0.8 - 5.8
250 - 590
0.8 - 4.5
250 - 390
0.8 - 3
250 - 290
0.8 - 1.2
is an exclusive feature built into specific Zephyr hoods which can
limit the maximum blower CFM to meet local code requirements.
*AIRFLOW CONTROL TECHNOLOGY™ (ACT™)
Optional Wireless Remote Control
ZEPHYRONLINE.COM
NAPOLI
ISLAND
EUROPA
Specifications subject to change, check zephyronline.com for up-to-date information.
Zephyr Ventilation | 2277 Harbor Bay Parkway, Alameda, CA 94502 | 888.880.VENT
AUG15.0101
is an exclusive feature built into specific Zephyr hoods which can
limit the maximum blower CFM to meet local code requirements.
DCBL Suppression System® offers 77% less noise, 30% more
CFM, and 77% more energy efficiency for the most advanced
range hood technology.
AIRFLOW CONTROL TECHNOLOGY™ (ACT™)
TM
C
CEILING HEIGHT
EXTENSION
DUCT COVER
STANDARD
DUCT COVER
Ducted Mounting Height*
Recirc Mounting Height*
Ducted Mounting Height*
Recirc Mounting Height*
MODEL
Stainless Steel
Size
Blower CFM (Min. - Max.)
Sones (Min. - Max.)
ACT 590 CFM (Min. - Max.)
ACT 590 Sones (Min. - Max.)
ACT 390 CFM (Min. - Max.)
ACT 390 Sones (Min. - Max.)
ACT 290 CFM (Min. - Max.)
ACT 290 Sones (Min. - Max.)
FEATURES
DCBL Suppression System®
ACT™ Technology
Controls
Speed Levels
Auto Delay-Off
Lighting
Dual-Level Lighting
Filters
Quick-Lock Installation
Recirculating Option
Extension Duct Cover Option
DUCT SPECIFICATIONS
Vertical Internal Blower
Horizontal Internal Blower
AC POWER
OPTIONAL ACCESSORIES
Wireless Remote Control
Recirculating Kit
Extension Duct Cover
Make-Up Air Kit
MOUNTING HEIGHT RANGE*
WARRANTY
ZNA-M90CS
36”
250 - 715
0.8 - 5.8
250 - 590
0.8 - 4.5
250 - 390
0.8 - 3
250 - 290
0.8 - 1.2
Yes
Yes
Electronic LCD
5 + Burst
Yes
Bloom™ HD LED, 3W x4
Yes
Baffle x2
Yes
Yes
Yes, Up to 12’ Ceiling
8” Round
NA
120V, 60Hz at Max. 4A
RC-0001
ZRC-02NA
Z1C-02NA
MUA008A
26” - 34”
3 years parts, 1 year labor
*Mounting height refers to distance between top of a 36” tall cooking surface and bottom of hood.
ZNA-E42CS
42”
250 - 715
0.8 - 5.8
250 - 590
0.8 - 4.5
250 - 390
0.8 - 3
250 - 290
0.8 - 1.2
Yes
Yes
Electronic LCD
5 + Burst
Yes
Bloom™ HD LED, 3W x4
Yes
Baffle x2
Yes
Yes
Yes, Up to 12’ Ceiling
8” Round
NA
120V, 60Hz at Max. 4A
RC-0001
ZRC-02NA
Z1C-02NA
MUA008A
26” - 34”
3 years parts, 1 year labor
8.5’
26” - 34”
26” - 29.5”
NA
NA
8’
26” - 28”
NA
NA
NA
9’
26” - 34”
26” - 34”
NA
NA
9.5’
28” - 34”
28” - 34”
26” - 29”
NA
10’
34” - 34”
34” - 34”
26” - 34”
26” - 30.5”
10.5’
NA
NA
26” - 34”
26” - 34”
11’
NA
NA
26” - 34”
26” - 34”
12’
NA
NA
28” - 34”
28” - 34”
