Side 1/2
europa power breeze
pisa under-cabinet
Tucked neatly out of sight within your cabinetry, Pisa is a minimal alternative to your typical under-
cabinet range hood. Powered by the strength of its 290-CFM blower, Pisa’s low-profile body delivers
stunning design and quality performance. Its retractable visor helps in the capture of air and puts
control at your fingertips. Pisa is perfect for kitchens that require a more discreet look.
ZPI-E30AG290 30” 180 - 290 1.3 - 3.2
MODEL SIZE INTERNAL BLOWER
Min.-Max. CFM Min.-Max. Sones
MAY14.0201 Zephyr Ventilation | 2277 Harbor Bay Parkway Alameda, CA 94502 | 888.880.VENT | zephyronline.com
europa power breeze
size
zPi-e30AG290
30”
PeRFORMANCe
INTERNAL, MIN.-MAX. BLOWER CFM
180 - 290
INTERNAL, MIN.-MAX. SONES 1.3 - 3.2
COlOR
STAINLESS STEEL
SS + Glass
FeAtuRes
CONTROLS
Mechanical Slide
SPEED LEVELS 3
LIGHTING Halogen x 2
DUAL LEVEL LIGHTING Yes
FILTER Aluminum Mesh
RECIRCULATING OPTION Yes
duCt sPeCiFiCAtiONs
VERTICAL - INTERNAL
6” Round
HORIZONTAL - INTERNAL 6” Round
AC POweR 120V, 60Hz at Max. 1.55A
OPtiONAl ACCessORies
RECIRCULATING KIT
ZRC-00PI
OPtiONAl ACCessORies 3 Years Parts, 1 Year Labor
MOuNtiNG heiGht* 24” - 32”
pisa under-cabinet | europa
TOP
FRONT
SIDE
29 15/16”
19
12 1/8”
1 1/2”
9 9/16”
11 1/4”
5/8”
6"
C/L
3 7/16”
2 3/4”
5”
11-15/16” - 18 3/4"
closed open
11 1/8"
13/16”
9 7/8”
1 1/8”
3/8” -
2 1/4"*
*adjustable rear
filler panel
*Mounting height refers to distance between top of cooking surface and bottom of hood.
1
15/16”*
19
7/8”
10 1/8”
CABINET CUT-OUT
*Measured from front of doors in a frameless cabinet
or front of cabinet bottom in a framed cabinet.
Specifications subject to change, check zephyronline.com for up-to-date information.
