Side 1/39

User Manual

IDK-1108R-50SVB1

8.4" SVGA Industrial Display Kit

with 4-Wire Resistive Touch

Solution

IDK-1108R-50SVB1 User Manual ii

The documentation and the software included with this product are copyrighted 2025

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated, or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. The information provided in this manual is intended to be accurate and reliable.

However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any

infringements of the rights of third parties that may result from its use.

Acknowledgements

AMI is a trademark of American Megatrends Inc.

IBM and PC are trademarks of International Business Machines Corporation.

Intel® Core™ 2 Quad, Pentium® Dual Core, and Celeron® are trademarks of Intel

Corporation.

WinBond is a trademark of Winbond Corporation.

All other product names or trademarks are properties of their respective owners.

Part No.2006110810 Edition 1

Printed in Taiwan January 2025

Produkspesifikasjoner

Merke:	Advantech
Kategori:	Ikke kategorisert
Modell:	IDK-1108R-50SVB1
Vekt:	250 g
Bredde:	203 mm
Dybde:	8 mm
Høyde:	145.5 mm
Berøringsskjerm:	Ja
Skjermteknologi:	LCD
Berøringsskjermteknologi:	Resistive
Kontrastforhold:	600:1
Skjermoppløsning:	800 x 600 piksler
Skjermdiagonal:	8.4 "
Berøringsskjermtype:	Resistive
Naturlig sideforhold:	4:3
Støttede grafikkoppløsninger:	800 x 600 (SVGA)
Driftstemperatur (T-T):	-20 - 70 °C
Oppbevaringstemperaturomåde (Celsius):	-30 - 70 °C
Relativ luftfuktighet under drift (H-H):	0 - 90
Oppdateringsresponstid:	16 ms
Skjermlysstyrke (typisk):	450 cd/m²
Display antall farger:	16.2 million farger
Størrelseforhold:	4:3
